Caramelo

Visual spec-driven development for VS Code. LLM-agnostic. Compatible with GitHub Spec Kit.

Features • Installation • Quick Start • Providers • Jira • Contributing

Why Caramelo?

Spec Kit brings spec-driven development to AI coding — but it only works through slash commands in chat. Kiro offers a visual experience — but locks you into a single LLM.

Caramelo fills the gap: a visual UI for spec-driven development that works with any LLM — Claude, Ollama, OpenAI, Groq, LM Studio, or any OpenAI-compatible endpoint.

Features

Visual Workflow

• Unified sidebar — providers, constitution, specs, progress, and task checklist in one panel
• Sequential phase flow with approval gates: Requirements → Design → Tasks
• Constitution editor — visual form with AI generation (describe your project, LLM suggests principles)
• Workflow DAG — interactive graph showing all specs and their phase statuses
• Progress ring — overall completion percentage (phases 50% + tasks 50%), 100% only when all tasks done
• Stale alerts — downstream phases flagged when upstream is regenerated
• Inline task checklist — toggle tasks directly in the sidebar with immediate file sync

LLM Agnostic

• Any provider: GitHub Copilot, Claude, OpenAI, Gemini, Ollama, Groq, LM Studio, or any OpenAI-compatible endpoint
• Multiple providers configured simultaneously — switch by clicking the dot indicator
• Auto-detect models — available models fetched from provider API, or enter manually
• Inline editing — click provider name, model, or auth settings to edit directly in the sidebar
• Custom auth headers — configurable header name and prefix for corporate proxies (e.g. Azure API Manager)
• Model validation — test request on model change, red indicator on failure
• Multiple instances — add several providers of the same type with custom aliases
• Secure credential storage via VS Code's native SecretStorage
• Streaming output — see documents being written in real time in the editor
• Output Channel — watch LLM reasoning during task execution

Spec Kit Compatible

• Uses specs/ directory — fully interoperable with Spec Kit CLI
• Auto-syncs templates from GitHub Spec Kit releases
• Generates intermediate artifacts: research.md, data-model.md, contracts/
• Constitution as LLM context — project principles included in every generation
• Offline-first — bundled fallback templates, no internet required

Editor Integration

• CodeLens buttons — Approve, Regenerate, Next Phase persistent in documents
• Phase progress bar — visual step indicator at the top of every spec document
• Caramelo editor menu — grouped contextual actions under a single cat icon (adapts to dark/light themes)
• Task CodeLens — Run Task / Run All Tasks inline in tasks.md
• Parallel task execution — tasks marked [P] run concurrently
• Non-intrusive progress — status bar spinner instead of notification popups
• Auxiliary files — research.md, data-model.md, analysis.md, checklists shown under each phase

Quality Tools

• Clarify — LLM identifies ambiguities, presents questions as QuickPick dialogs
• Analyze — cross-artifact consistency check with severity-coded findings
• Auto-fix — CodeLens buttons on analysis.md to fix individual or all findings with LLM
• Checklists — content-specific quality verification items per phase

Jira Integration

• Import issues as specs — create specs directly from Jira Cloud issues
• Issue picker — QuickPick with dynamic search and issue preview
• Jira badge — spec cards show linked issue key with click-to-open
• Full context — issue title, description, acceptance criteria, and comments used for generation

Installation

From VS Code Marketplace

Search for "Caramelo" in the Extensions panel, or install from the Marketplace page.

From VSIX

code --install-extension caramelo-0.0.10.vsix

From Source

git clone https://github.com/fsilvaortiz/caramelo.git
cd caramelo
npm install
npm run build

Press F5 in VS Code to launch the Extension Development Host.

Quick Start

1. Add a provider — Expand the Providers section. Click a preset (Ollama, Claude, OpenAI, Gemini, Groq, LM Studio, Copilot, Jira). Enter credentials if needed — models are fetched from the API or entered manually. For corporate proxies, expand "Custom auth header" to set the header name and prefix.

2. Set up your constitution — Click the Constitution bar in the Workflow panel. Describe your project and click "Generate with AI" to let the LLM suggest principles, or fill in manually.

3. Create a spec — Expand "New Spec" in the Workflow panel, enter a name and description, click "Create". Or click "From Jira" to import an issue.

4. Generate phases — Click "Generate" on each phase (Requirements → Design → Tasks). Watch the document stream in real time. Review and approve each before the next unlocks.

5. Execute tasks — Click "Implement" on the Tasks phase, or open tasks.md and use "Run Task" / "Run All Tasks" buttons. Watch LLM reasoning in the Output Channel.

6. Quality checks — Use the Caramelo menu (cat icon in editor toolbar) to Clarify ambiguities, Analyze consistency, Fix issues, or Generate checklists.

Providers

LLM Providers

Jira Integration

Expand the Providers section, click a preset button, enter credentials. Models are fetched automatically from the provider's API when available, or enter the model name manually. All editing (name, model, auth headers) is done inline in the sidebar — click any field to edit it.

Workflow

Constitution (project principles)
       │
       ├──→ [Feature 1]
       │     ├── Requirements (spec.md)
       │     ├── Design (plan.md + research.md + data-model.md + contracts/)
       │     ├── Tasks (tasks.md)
       │     └── Implementation (task execution)
       │
       └──→ [Feature 2]
             └── ...

Each phase must be approved before the next unlocks:

• Generate — LLM creates the document using templates + constitution + prior phases
• Approve — mark as complete, unlock the next phase
• Regenerate — re-run (marks downstream phases as stale)
• Edit manually — modify before approving

Auxiliary Files

Configuration

VS Code settings (settings.json):

{
  "caramelo.providers": [
    {
      "id": "ollama",
      "name": "Ollama",
      "type": "openai-compatible",
      "endpoint": "http://localhost:11434/v1",
      "model": "llama3"
    }
  ],
  "caramelo.activeProvider": "ollama"
}

API keys and Jira tokens are stored securely in VS Code's SecretStorage, never in settings files.

Advanced settings

Invalid values for authHeader / authPrefix (e.g. containing spaces, colons, or CR/LF) are rejected at runtime and the default is used instead.

Troubleshooting

The LLM request hangs or times out

Caramelo aborts a streaming request if no data arrives for caramelo.sse.timeoutMs milliseconds (5 min by default). If you run large local models (Ollama, LM Studio) and hit this, raise the setting:

{ "caramelo.sse.timeoutMs": 900000 }

Setting it below 5000 ms is ignored — the default is used.

"401" / "403" on generate

The provider rejected your API key. Open the Providers panel, click the auth field next to the provider, and paste a fresh key. Keys are stored in VS Code SecretStorage, not settings.json. For corporate proxies, also verify authHeader / authPrefix match what your gateway expects.

The provider dot is green but generations fail

Since v0.0.10 the dot reflects the result of a real one-token streaming ping, not just whether you clicked it. If a previously green dot turns red, click it again to re-test — the Caramelo output channel and the warning notification will say what failed (auth, model not found, timeout, network).

Dot legend:

My providers disappeared when I opened a different folder

Up to v0.0.9 caramelo.providers and caramelo.activeProvider were stored per workspace. From v0.0.10 they live in User Settings, and the extension migrates them once on startup. If you preferred per-workspace overrides, you can still set them in .vscode/settings.json — VS Code's normal scope precedence applies.

"Connection error" or "Auth failed" when adding a Jira provider

Caramelo now pings /rest/api/3/myself both when you click Test and when you click Add Jira Provider, so adding will fail cleanly if the email, URL, or API token are wrong. Generate a token at https://id.atlassian.com/manage-profile/security/api-tokens and use the full https://<tenant>.atlassian.net URL.

A phase is stuck on "pending" even though the file exists

Opening the workflow sidebar should now auto-upgrade phases whose markdown has content to pending-approval and persist that change to .caramelo-meta.json. If it does not, delete the stale .caramelo-meta.json inside that spec directory — it will be rebuilt.

Seeing leaked tokens in DevTools / extension host output

You shouldn't — the extension logs through a redacting logger that strips Bearer/Basic tokens, Authorization headers, and credentials embedded in URLs. Debug logs are only emitted when CARAMELO_DEBUG=1 is set in the environment that launches VS Code.

If you still see a leak, please open an issue with the redacted payload.

Contributing

See CONTRIBUTING.md for guidelines.

License

MIT
