Agent Flow Builder

Agent Flow Builder is a Visual Studio Code extension that lets you visually design complex AI agent workflows using a drag-and-drop editor — and automatically generates production-ready Node.js / JavaScript code from your flow. No boilerplate, no manual wiring: just connect blocks, configure your agents, and the extension writes the code for you.

It supports OpenAI, Google Gemini, and Anthropic Claude out of the box, with built-in capabilities for text generation, structured JSON output, image generation, vision, text-to-speech, speech-to-text, web search, and advanced reasoning/thinking models.

Design visually. Generate code automatically. Run anywhere Node.js runs.

Table of Contents

1. Getting Started
2. Supported Providers & Models
3. Core Features
   • Visual Flow Editor
   • Variable Management
   • Flow Control
4. Component Types
5. Multimedia Capabilities
6. Code Generation & Execution
7. Requirements & Installation

Getting Started

First, install the extension from the VS Code Marketplace.

1. Open the Agent Flow Builder view in VS Code.
2. Create a new flow or open an existing .agent file.
3. Drag and drop components from the palette onto the canvas.
4. Connect components to define the execution flow.
5. Configure each component using the settings panel.

Supported Providers & Models

The extension supports these AI providers:

• OpenAI.
• Google Gemini
• Anthropic

Core Features

Visual Flow Editor

• Drag & Drop Interface: Easily place nodes on an infinite canvas.
• Clean Flow Visualization: Auto-layout and connection lines help visualize complex logic.
• Zoom & Pan: Navigate large workflows with ease.
• Clipboard Support: Copy/Paste blocks (or groups of blocks) to duplicate logic.
• Undo/Redo: Full history support for safe editing.

Variable Management

• Start Variables: Define global variables in the START block with types (String, Number, Boolean, Array, Object) and default values.
• State Management: Variables are automatically prefixed with state. in the generated code.
• Dynamic Context: Agents can read and write to the shared state, allowing data to pass between steps.

Flow Control

• Sequential Execution: Default linear flow.
• Branching (If/Else): Create logic paths based on variable values or agent outputs.
• Loops: Create cyclic flows to retry tasks or process lists (automatically detected).
• Parallel Execution: Run multiple agents simultaneously (configurable in supported patterns).
• Error Handling: Route errors directly in the flow using dedicated error connections.

Customizable Labels & Internal Code

• Rename Blocks: Click a block and edit its name in the settings panel.
• Custom Code: Use the Code / Function Caller block to execute arbitrary JavaScript within the flow (e.g., for data formatting, math, or external API calls).

Component Types

Multimedia Capabilities

The builder goes beyond text-only agents:

• Image Generation: create images from text descriptions.
• Vision (Image Analysis): Analyze images.
• Text-to-Speech (TTS): Convert agent text responses into audio files.
• Speech-to-Text (STT): Transcribe audio files into text for processing.

Code Generation & Execution

The extension generates a pure Node.js module.

• Automatic Exports: The main function is exported module.exports = { runMyFlow };.
• State Preservation: The execution context is maintained via a state object passed through the chain.
• Error Handling: Wraps agent calls in try/catch blocks for robustness.

To run the generated code, simply import the function in your Node.js application:

const { runMyFlow } = require('./my_agent_flow.js');

async function main() {
  const result = await runMyFlow({ state: {}, conversationHistory: [] });
  console.log(result);
}
main();

Requirements & Installation

To fully utilize all generated agents, your project requires the following SDKs. The extension includes an Environment Validator that checks for these dependencies.

Required Environment Variables

Create a .env file in your project root with your API keys:

OPENAI_API_KEY=sk-...
GEMINI_API_KEY=...
ANTHROPIC_API_KEY=sk-...

SDK Dependencies

Install the necessary packages via npm:

# Core utils
npm install dotenv zod zod-to-json-schema wav

# AI SDKs (install based on providers used)
npm install openai
npm install @google/generative-ai @google/genai
npm install @anthropic-ai/sdk

• Note: wav is required specfically for Gemini TTS feature to handle audio formatting.
