Simply View Image for Python Debugging

This extension offers a powerful and versatile solution for visualizing images, plots, and tensors during Python debugging. It is designed to enhance your debugging workflow with a rich set of features.

Features

Image Viewer

A built-in, enhanced image viewer with the following capabilities:

Image Values

Display pixel values directly on the image.

Heatmap

Visualize images as heatmaps with customizable color maps and value clipping.

Labels

View label images with color mapping (e.g., 0=black, 1=red, etc.).

Plot Viewer

Visualize plots from various sources, including:

matplotlib.pyplot.Figure
matplotlib.pyplot.Axis
Plotly Figures (requires saving backend, see here).

Tensor Viewer

Inspect tensors from PyTorch and NumPy.

numpy.ndarray is treated as a tensor if it has 4 channels or 3 channels but does not qualify as a single image. Requires scikit-image.

Watch View

Monitor image, plot, or tensor variables and refresh the view at each breakpoint.

Supports custom Python expressions (use with caution to avoid side effects).

Additional Features

Hover over variables to view their shape (unrelated to the image viewer, but useful nonetheless).
Open local image files (supports PNG, JPG, BMP, TIFF) in the viewer.
_{I find this feature useful for label images, as they often have small values (0, 1, etc.), which the default viewer does not enhance.}
A colorbar for heatmap images with adjustable value clipping.
Interactive Python cell support: Use the Variables tab and click the arrow next to a variable name to view the image.

Settings

Setting	Description	Default Value
`svifpd.autoFetchImages`	Controls whether images are automatically fetched. `true`: Automatically fetch images at each step. `false`: Fetch images only when the "Fetch Image" button is clicked. `"pinned"`: Automatically fetch pinned images.	`true`
`svifpd.restrictImageTypes`	Restricts the types that are considered images. `true`: Only numpy is checked. `false`: All types are checked. This setting is useful for improving performance in some cases.	`true`

Q&A

Memory Issues

Problem: Memory usage increases significantly when using the extension.

Solution: Enable the restrictImageTypes setting (default: true).

Extension Links

Acknowledgment

This extension builds upon the foundational work of john-guo. While none of the original code remains, his project served as a valuable inspiration for this extension. Thank you, John!

View Image for Python Debugging

Elazar Cohen
