SystemVerilog - Language Support

Eirik Prestegårdshus

|
57,970 installs
| (10) | Free
Language support for Verilog and SystemVerilog.
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

SystemVerilog - Language Support

This VS Code extension provides features to read, navigate and write SystemVerilog code much faster.

Features

  • Elaborate syntax highlighting
  • Go to symbol in document (Ctrl+Shift+O)
  • Go to symbol in workspace folder (indexed modules/interfaces/programs/classes/packages) (Ctrl+T)
  • Go to definition (works for module/interface/program/class/package names and for ports too!) (Ctrl+LeftClick)
  • Find references (works for module/interface/program/class/package names and for ports too!) (Ctrl+LeftClick)
  • Quick-start on already indexed workspaces
  • Code snippets for many common blocks
  • Instantiate module from already indexed module
  • Linter capabilites with simulators (more info on the wiki)
  • Fast real-time error identification through an integrated SystemVerilog parser and IntelliSense (fully accurate to IEEE Standard 1800-2017)
  • If you find a bug or would like a feature, request it as an Issue or submit a Pull Request

Examples

Syntax Highlighting

Syntax Highlighting Example

Go To Definition

Go To Definition Example

Find References

Find References Example

Module Instantiation

Module Instantiation Example

Recommendations

  • If you have netlists in your workspace you can exclude them in the settings with systemverilog.excludeIndexing, e.g.: **/syn/**
  • When running in workspaces with a large number of files, the systemverilog.documentSymbolsPrecision setting may need to be reduced down to 'full_no_references'. Doing this will turn off the 'find references' feature which will dramatically speedup the parsing.
  • When you have large files, the systemverilog.maxLineCountIndexing setting can be tuned to prevent full parsing of these files, which will improve extension performance.
  • Disclaimer: This is not a functional tool that will compile and simulate HDL, but it will make it easier and more user-friendly to write and navigate SystemVerilog and Verilog.

Settings

  • systemverilog.includeIndexing: Array, Files included for indexing (glob pattern). Examples:
    • Include files within the workspace's rtl folder (* at front of pattern denotes path is relative to workspace root): **/rtl/**/*.{sv,v,svh,vh}
    • Add all files with a '.svp' extension: **/*.svp
    • Add files only when in a specific workspace: /abs/path/to/workspace/rtl/**/*.{sv,v,svh,vh}
  • systemverilog.disableIndexing: Boolean, Disable indexing
  • systemverilog.excludeIndexing: String, Exclude files from indexing based on glob
  • systemverilog.forceFastIndexing: Boolean, Use fast regular expression parsing
  • systemverilog.enableIncrementalIndexing: Boolean, Enable incremental indexation as files are opened
  • systemverilog.parallelProcessing: Integer, Number of files to process in parallel during indexing
  • systemverilog.forceFastIndexing: Boolean, force indexer to bo basic parsing. Good for when the extension takes too long to initialize.
  • systemverilog.enableIncrementalIndexing: Boolean, Enable incremental indexation as you open files.
  • systemverilog.maxLineCountIndexing: Boolean, When indexing a file, if the line count is larger than this number, fast indexing will be used to improve symbol lookup performance, as fewer symbols will be parsed.
  • systemverilog.documentSymbolsPrecision: String, The level of detail the parser should use when looking for symbols:
    • full: detect blocks, ports, parameters, classes, methods, typedefs, defines, labels, instantiations, assertions, and references across files.
    • full_no_references: detect blocks, ports, parameters, classes, methods, typedefs, defines, labels, instantiations, and assertions.
    • declarations: detect blocks, ports, parameters, classes, methods, typedefs, and defines.
    • fast: detect only common blocks (module, class, interface, package, program) without hierarchy.
  • systemverilog.antlrVerification: Boolean, Use ANTLR parser to verify code in real-time
  • systemverilog.verifyOnOpen: Boolean, Run ANTLR verification on all files when opened.
  • systemverilog.launchConfigurationVerilator: String, Command to run when launching verilator
    • Default: verilator --sv --lint-only --language 1800-2012 --Wall
    • If not in path, replace verilator with the appropriate command
  • systemverilog.launchConfigurationVCS: String, Command to run when launching VCS
    • Default: vcs
    • If not in path, replace vcs with the appropriate command
  • systemverilog.launchConfigurationVerible: String, Command to run when launching Verible
    • Default: verible-verilog-lint
    • If not in path, replace verible-verilog-lint with the appropriate command
  • systemverilog.excludeCompiling: String, Files excluded from compiling when saved based on glob
  • systemverilog.compileOnSave: Boolean, Compile files when saved
    • Default: true
  • systemverilog.compilerType: String, Dropdown list to select a compiler type
    • Default: Verilator
  • systemverilog.trace.server: String, Dropdown to select verbosity of LSP message tracing
  • systemverilog.compileOnOpen: Boolean, Compile all files when opened
    • Default: false

Customizations

Use the provided settings in a user or workspace settings.json as appropriate. Here are a few examples:

{
  "editor.bracketPairColorization.enabled": true, // turn on bracket pair coloring
  "editor.guides.bracketPairs": "active", // turn on bracket pair guides
  // Change theme default colors for specific tokens
  // To find tokens use: https://code.visualstudio.com/api/language-extensions/syntax-highlight-guide#scope-inspector
  "editor.tokenColorCustomizations": {
    // Customize per theme or globally
    "[Theme Name]": {
      "textMateRules": [
        {
          // Workaround: Extension marks escaped identifiers as regular expressions to prevent bracket matching,
          //             so recoloring it back to identifier color
          "scope": ["string.regexp.identifier.systemverilog"],
          "settings": {
            "foreground": "#e06c75"
          }
        }
      ]
    }
  },
  // Customize formatting command to suite preferences
  "systemverilog.formatCommand": "verible-verilog-format --assignment_statement_alignment=preserve --case_items_alignment=infer --class_member_variables_alignment=infer --formal_parameters_alignment=preserve --formal_parameters_indentation=indent --named_parameter_alignment=flush-left --named_parameter_indentation=indent --named_port_alignment=flush-left --named_port_indentation=indent --net_variable_alignment=preserve --port_declarations_alignment=preserve --port_declarations_indentation=indent",
  // Add additional file extensions to associate with SystemVerilog and include them in the indexing
  "files.associations": {
    "*.svi": "systemverilog",
    "*.svp": "systemverilog",
    "*.pkg": "systemverilog"
  },
  "systemverilog.includeIndexing": ["**/*.{sv,v,svh,vh,svi,svp,pkg}"]
}

Known Issues

  • Initial indexing might hog CPU/RAM when looking through files in very large workspaces

Future

  • Tree view of module hierarchy
  • References document
  • Back-end Language server for SystemVerilog
  • Update workspace state to save to storagePath

Contributing

  • If you want to contribute with the project please fork this repository, clone it, make changes (preferably in a branch other than master) and finally create a Pull Request (more details here).
  • To debug the extension locally first install the required dependencies (in the repository's root directory):
npm install
  • Then compile the project at least once (this will generate the SystemVerilog lexer and parser in src\compiling\ANTLR\grammar\build):
npm run compile
  • Finally, run the "Client + Server" run configuration:

Debug configuration

Release Notes

See the changelog for more details

0.13.2

  • modified formatter command parser to support windows paths by joecrop
  • module instantiator now detects parameters correctly by joecrop

0.13.1

  • Improved remote ssh performance by eirikpre

0.13

  • input/output/input now have different icons in the outline tree by joecrop
  • Format module instance and dropdown list of modules for auto-instantiator by joecrop
  • support more file extensions and no extension in antlr parser by joecrop
  • Bump minimist from 1.2.5 to 1.2.6 by dependabot
  • Include indexing docs by joecrop

0.12.1

  • Update VS Code engine to 1.56.0 to support Node.js 14
  • Update several dependencies to address CVEs
  • Update ESLint to version 8 and implement some suggested fixes
  • Update Prettier and apply suggested formatting changes
  • Remove React-related ESLint dependencies
  • Remove direct dependency on antlr4 package as it is a submodule of antlr4ts
  • Remove on Markdown activation
  • Rename .eslintrc to .eslintrc.json to fix ESLint editor integration
  • Add -Xexact-output-dir to compile command to fix MacOS build
  • Update README.md with a suggested configuration section and add missing settings
  • Enable bracket matching and coloring to function with SystemVerilog textual brackets
  • Fix port-net-parameter highlighting corner case
  • Enhance Github Actions test workflow
  • Fix coverage collection

0.12

  • Implemented 'find references' feature, thanks to joecrop
  • Ports and parameters are now recognized as symbols, thanks to joecrop
  • Illegal/reserved words contained with symbols is now supported, thanks to joecrop
  • Added more consistent syntax highlighting for UDP tables, thanks to sw23
  • Added support for verible_verilog_lint as a compiler/linter, thanks to joecrop
  • Fixed 'npm run compile' on MacOS, thanks to sw23
  • Added 'Contributing' section to documentation, thanks to gasrodriguez

0.11

  • Syntax Highlighting Overhaul, thanks to jecassis
  • Smaller extension footprint, thanks to jecassis
  • Support for external formatter, thanks to jecassis
  • Documentation upgrade, thanks to jecassis
  • Dev update with ESLint, Prettier and tests update, thanks to jecassis

0.10

  • Folders outside the workspace can now be included with systemverilog.includeIndexing
  • It now saves the indexed database between runs, allowing quickstart on previous workspaces

0.9

  • Increased the number of symbols the parser understands.
  • Extensive bug squashing

0.8

  • Compile an opened document using Verilator simulator, display errors/warnings as Diagnostics in documents, thanks to oehaddouchi
  • Compile documents on save feature using Verilator simulator
  • Added output channel SystemVerilog
  • Added an LSP, set it to communicate with the extension's client
  • Keep track of the recently used modules in the indexer
  • Added diagnostic support for VCS compiler

0.7

  • Instantiate module from already indexed module, thanks to oehaddouchi
  • Update to documentSymbolProvider

0.6

  • Stability and performance upgrade
  • PCRE Regexes

0.5

  • HoverProvider added, thanks to toastedcornflakes
  • Improvements to DocumentSymbolProvider to better support Hover

0.4

  • Added setting to exclude folders from indexing

0.3

  • DefinitionProvider fetching from indexed modules implemented
  • Indexing is now more safe, and will work for large workspaces

0.2

  • Alpha 2 release with expanded syntax highlighting and snippets
  • Indexing of every module/interface/program/class in workspace

0.1

  • Alpha 1 release with syntax highlighting, and go to symbols
