CAP Tools

The all-in-one VSCode extension for SAP BTP, CAP/CDS, Cloud Foundry & HANA development

Install from Marketplace · Report Bug · Request Feature

Why CAP Tools?

Working with SAP BTP, CAP/CDS and Cloud Foundry involves a lot of repetitive terminal work — logging in, switching orgs, copy-pasting HANA credentials, setting up debug tunnels for each microservice. CAP Tools replaces all of that with a clean VSCode sidebar.

Before	After
`cf login` → `cf target` → `cf env my-app` → copy JSON → edit settings.json	One click in the Credentials tab
`cds debug app-a &` → `cds debug app-b &` → edit launch.json × N	Multi-select in the Debug tab → sessions start automatically
Manually refresh to know which apps are running	Live CF Explorer in your Activity Bar

Features

🐛 Multi-App Debug Launcher

Debug multiple CAP services simultaneously with zero configuration.

Select any number of started apps from the list
Extension allocates ports, writes launch.json, starts cds debug tunnels
VSCode debugger auto-attaches — no manual steps
Live session status: TUNNELING → ATTACHING → ATTACHED
Stop individual sessions or kill all at once

🔑 HANA Credential Extractor

Extract HANA credentials from cf env and deliver them where you need them.

Browse spaces and apps within your org
Extract from multiple apps in one shot
Three output modes:
- Write directly to .vscode/settings.json (SQLTools-ready)
- Download as hana-credentials.json
- Copy to clipboard

🌲 CF Explorer (Tree View)

Browse your Cloud Foundry landscape from the Activity Bar.

Hierarchy: Org → Space → App
Started apps shown in green, stopped apps dimmed
Right-click context menu: Debug, Extract Credentials, Open URL, View Environment, Copy Name

⚙ Settings & Cache Sync

Background cache sync across all CF regions (configurable interval)
Auto-reads SAP_EMAIL / SAP_PASSWORD from your shell environment
Persistent org ↔ local folder mappings across restarts
17 built-in CF regions + custom endpoint support

Installation

From VS Marketplace (recommended)

ext install dongtran.sap-tools

From VSIX

code --install-extension sap-tools-<version>.vsix

Prerequisites

Tool	Required	Purpose
CF CLI	✅	Interact with Cloud Foundry
@sap/cds-dk	✅ For debug	`cds debug` command
SQLTools	Optional	Credential auto-sync

Shell Environment

Set your SAP credentials in your shell profile (.zshrc, .bashrc, etc.):

export SAP_EMAIL="your.email@company.com"
export SAP_PASSWORD="your-password"

CAP Tools reads these automatically — no prompts, no copy-pasting.

Quick Start

Click the CAP Tools icon in the Activity Bar (hexagon ⚡)
Select your CF region and click Connect
Pick your organization from the list
Browse to your local project folder (used for debug file mapping)
You're in the Dashboard — switch between Debug / Credentials / Settings tabs

Debug: launch all services in 30 seconds

Dashboard → Debug tab → check apps → ▶ Start Debug Sessions

Extract HANA credentials

Dashboard → Credentials tab → select space → select apps → Extract

Extension Settings

Setting	Default	Description
`sapTools.defaultRegion`	`ap11`	Default CF region on startup
`sapTools.cacheSyncInterval`	`240`	Background sync interval (minutes)
`sapTools.autoSync`	`true`	Auto-sync cache on startup
`sapTools.sqlToolsIntegration`	`true`	Write credentials to SQLTools settings
`sapTools.debugBasePort`	`9229`	Starting port for debug sessions
`sapTools.explorerDepth`	`6`	Max folder depth when scanning for local apps

Architecture

src/
├── extension.ts              # Entry point & message router
├── types/index.ts            # All shared TypeScript types
├── core/
│   ├── cfClient.ts           # CF CLI wrapper
│   ├── cacheManager.ts       # VSCode globalState cache with TTL
│   ├── processManager.ts     # cds debug process lifecycle
│   ├── shellEnv.ts           # Read SAP_EMAIL/SAP_PASSWORD from shell
│   └── regionList.ts         # 17 built-in CF regions
├── features/
│   ├── debug/                # Multi-app debug orchestration
│   ├── credentials/          # HANA credential extraction & delivery
│   └── explorer/             # CF TreeView provider
└── webview/
    ├── mainPanel.ts          # WebviewView provider (state machine)
    ├── mainRenderers.ts      # HTML renderers (XSS-safe via esc())
    └── mainScript.ts         # Client-side JS (event delegation)

Security: All CF-sourced data (org names, app names, URLs) is HTML-escaped before rendering. Inline event handlers are avoided in favor of data attributes + event delegation. Content Security Policy is enforced on all webview content.

Contributing

git clone https://github.com/dongitran/cap-tools.git
cd cap-tools
pnpm install

pnpm watch          # build in watch mode
pnpm typecheck      # type check
pnpm lint           # ESLint
pnpm test           # unit tests (vitest)

Press F5 in VSCode to launch the Extension Development Host.

CI/CD

Every pull request runs:

Type check (tsc --noEmit)
Lint (eslint)
Unit tests with coverage
Production build + bundle size check (<5 MB)
VSIX packaging

Releases are triggered by pushing a version tag (v*.*.*) and automatically publish to the VS Marketplace.
