Angular schematics extension for Visual Studio Code

Visual Studio Code extension allowing you to launch Angular schematics (CLI commands) with a Graphical User Interface, directly inside VS Code!

Why?

Productivity!

This extension will save you time:

No more typo errors = no more cleaning mess
No more documentation search, all options available are proposed and described
Many options are inferred (like the path and the project)
Generated files will auto open!
Promote good practices for component types

Differences with Angular Console

If you've heard about Angular Console, you may ask what's the difference with this extension (which was released first).

While this extension is specific to VS Code, Angular Console was first designed as a desktop app, and then ported to VS Code. As a consequence, some useful features like inferred options and auto-opening generated files are not possible in Angular Console (at least for now).

So it's up to you: test both and see which one saves you more time.

Sponsorship

I started this project to help my students learning Angular. Now, according to Visual Studio Code Marketplace, this extension helps more than 230 000 developers like you to be more productive.

But I'm still the only maintainer, and everything is done during my free time. The lib may seem easy to use, but it's a lot of work. So if your company earns money with projects using this extension, it would be nice to consider becoming a sponsor.

By the same author

@ngx-pwa/local-storage: 1st Angular library for local storage
Popular Angular posts on Medium
Follow updates of this lib on Twitter
Angular onsite trainings (based in Paris, so the website is in French, but my English bio is here and I'm open to travel)

Getting started

Follow instructions on Visual Studio Code marketplace, or just search for "Angular schematics" by "Cyrille Tuzi" directly inside VS Code extensions panel.

Then, you can launch Angular CLI commands from 4 places:

the files Explorer context menu: right-click on any directory, then choose an "Angular: Generate..." command
the dedicated Angular Schematics view (icon in the Activity bar on the left)
the Command Palette
from a shortcut (see configuration below)

The quickest way to launch your Angular CLI commands is the first, with a right-click inside the files Explorer context menu. Why? Because the destination path and project will be automatically inferred to the directory you just right-clicked.

Requirements

VS Code

Current version of this extension officially requires Visual Studio Code version >= 1.41. But it may work on some older VS Code versions too.

If you use an older version of VS Code and run into issues, you can still install (official instructions here):

v2 of the extension for VS Code 1.39 & 1.40,
v1 of the extension for VS Code < 1.39.

Angular CLI

This extension is only enabled inside an Angular CLI project (ie. with an angular.json file in workspace).

We follow Angular LTS support, ie. currently your project should use Angular >= 7. But the extension may still work in older versions.

Project root

The project opened must be the root directory of the Angular project. It won't work from a parent directory, as the CLI itself requires to be in the Angular directory.

If your Angular project is inside your backend project, and you want both opened in VS Code:

open the root directory of the Angular project,
then in VS Code menu: "File" > "Add Folder to Workspace" > open the directory of your backend project.

Custom shell

On macOS or Linux, if you use a custom shell (like zsh) and your Angular CLI installation is tied it, it must be configured accordingly in your VS Code settings (terminal.integrated.shell.osx or terminal.integrated.shell.linux).

Component good practices

This extension helps you to follow good practices, by suggesting different component types and behaviors.

Special component behaviors

Exported component

Components have a local scope by default, meaning they are only usable inside the module where they are declared. So if you want to use a component in another module (for example if you are doing a reusable UI component), you have to export it.

Learn more about Angular modules and their scopes.

Pure component (also known as a presentation component)

A pure component is a component which relies only on its @Inputs for data, ie. its role is only presentation / UI (~ view), as opposed to an impure component, which relies on external asynchronous operations (like a HTTP request via a service) for data, ie. a page (~ controller).

Learn more about architecture in Angular projects.

Component without selector

Components associated to a route (ie. pages) or instantiated at runtime (like dialogs/modals) relies on specific features (like the ActivatedRoute service to get URL params). Thus, they should not be called via a HTML tag and so should not have a selector.

Entry component

This behavior is not required anymore with Ivy (ie. Angular >= 9 with default config or Angular 8 with Ivy explicitly enabled). It's only required in non-Ivy mode (ie. Angular <= 7, Angular 8 with default config or Angular 9 with Ivy explicitly disabled).

Most of the time, Angular automatically manages the internal code to instantiate components, because they are either associated to a route (ie. pages) or used somewhere in a template (ie. presentation components).

But dialogs (like in Angular Material), modals (like in Ionic) and Angular Elements are invoked at runtime, so it was required to register them in entryComponents.

Component with Shadow DOM encapsulation

When creating an Angular Element, i.e. a reusable native Web Component, the native encapsulation called ShadowDom must be used.

Note it's only available in Angular >= 7, and it won't work in Internet Explorer / Edge (pre-Chromium).

Component types

Having different component types is particullary helpful for projects following a good architecture, ie. distinguishing components behaviors (explained above), or for tools with special components (like pages and modals in Ionic).

Learn more about architecture in Angular projects.

Default component types

By default, the extension will propose you these component types:

Component: no special behavior
Page: component associated to a route (--skip-selector) & modals/dialogs (Angular >=9)
Pure: presentation / UI component (--change-detection OnPush)
Exported: pure component reused outside of their modules, ie. component lib (--exported --change-detection OnPush)
Element: Angular Element, ie. a native Web Component (--entry-component --view-encapsulation ShadowDom)
Runtime: component like modals or dialogs (--skip-selector --entry-component) (Angular <=8)

Customize component suffixes (Angular >= 9)

Angular CLI >= 9 introduces a new type option for component generation, to change the component's suffix.

For example, ng g hello --type page will generate the hello.page.ts file with a HelloPage class (instead of the hello.component.ts file with a HelloComponent class).

To customize component types, your root tslint.json config must be changed like this:

"component-class-suffix": [true, "Component", "Page", "Modal"].

Now the extension will ask which component type you want based on this suffixes list, and set the --type option automatically.

Note --type is set automatically only for your custom suffixes in tslint.json, not for the default component types, as otherwise lint would fail.

Link a custom suffix to a component type

Some common suffixes will automatically pre-select the recommended behaviors:

Pure, UI, Presentation, Presentational, Dumb > --change-detection OnPush
Page, Container, Smart, Routed, Route > --skip-selector
Exported, Lib > --exported --change-detection OnPush
Element > --entry-component --view-encapsulation ShadowDom
Dialog, SnackBar, BottomSheet, Modal, Popover, Entry > --skip-selector (Angular >=9) or --skip-selector --entry-component (Angular <=8)

The list above includes common suffixes in Angular, Material and Ionic. If you think some other common suffixes are missing, please open a Pull Request with new defaults.

For uncommon suffixes, you can add a custom configuration in VS Code preferences:

pure: "ngschematics.componentTypes.pure": ["Custom"]
no selector: "ngschematics.componentTypes.page": ["Custom"]
exported & pure: "ngschematics.componentTypes.exported": ["Custom"]
entry & shadow: "ngschematics.componentTypes.element": ["Custom"]
no selector & entry: "ngschematics.componentTypes.runtime": ["Custom"] (Angular <=8 only)

Default suffix

If you want to use the default Component suffix only for your pure presentation components, configure your VS Code preferences like this:

"ngschematics.componentTypes.pure": ["Component"]

This is a good practice but not the default configuration, as Component is the default suffix, and changing the changeDetection option has consequences that you need to be aware of.

Other features

Default options

schematics option of angular.json allows to save default options for schematics commands.

For example, if you want all your generated components templates to be inline, in all your projects, just add in angular.json:

{
  "schematics": {
    "@schematics/angular:component": {
      "inlineTemplate": true
} } }

Or only in a specific project:

{
  "projects": {
    "yourprojectname": {
      "schematics": {
        "@schematics/angular:component": {
          "inlineTemplate": true
} } } } }

If you want different values from the official defaults, the following options should be configured like above to ease the generation process:

@schematics/angular:component
- inlineTemplate
- inlineStyle
- style
all schematics
- skipTests

Other schematics

By default, this extension supports (if they are installed):

@schematics/angular (official Angular CLI commands)
@angular/material
@ionic/angular-toolkit
@ngrx/schematics
@nrwl/schematics
@nstudio/schematics
@ngxs/schematics
@nativescript/schematics
@ngx-formly/schematics
primeng-schematics
@ngx-kit/collection
ngx-spec
./schematics/collection.json

Scanning all packages to find all potential schematics would be too slow. If you want to use other schematics, just add their package name in ngschematics.schematics in your VS Code preferences.

For example: "ngschematics.schematics": ["@angular/material"]

If you are a library author, feel free to open a Pull Request to add your schematics in the default list.

Custom schematics

If you created your own Angular schematics but didn't published them yet, this extension can load them too. By default, the extension will look into ./schematics/collection.json.

If your schematics collection path is different, you can add a relative path in the VS Code preferences. For example: "ngschematics.schematics": ["./path/to/collection.json"]

Keyboard shortcuts

You can add keyboard shortcuts to the following actions:

ngschematics.generateComponent
ngschematics.generateService
ngschematics.generateModule
ngschematics.generate

But again, it's not the easiest way to use this extension: a right-click in the files Explorer menu is better as the extension will infer the destination path and project.

Icons

The icons in the Angular Schematics view will be nicer if you use the Material Icon Theme extension.

Release Notes

Changelog available here.

License

MIT
