Unity Color Preview

Inline color previews for Unity's Color and Color32 constructors in C# with configurable highlighting and named color support.

Demo

Features

Inline color swatches for occurrences of:
- new Color(r, g, b) or new Color(r, g, b, a) where values are floats in [0, 1]
- new Color32(r, g, b) or new Color32(r, g, b, a) where values are bytes in [0, 255]
- Named Unity colors like Color.red, Color.white, Color.clear, etc.
Configurable color highlighting with background or underline styles
Quick replace presentations to switch between Color and Color32 forms
Customizable presentation preferences and precision settings

Demo

Type code like this in a C# file:

var tint = new UnityEngine.Color(0.75f, 0.25f, 0.5f, 0.8f);
var ui = new UnityEngine.Color32(128, 64, 255, 200);
var primary = Color.red;
var transparent = Color.clear;

You will see color decorations inline and can use the color picker to edit: Preview

Color Highlighting

Enable highlighting to see colors directly in your code:

Highlight Demo

Requirements

VS Code ≥ 1.85.0

Extension Settings

This extension contributes the following settings:

Setting	Description	Default
`unityColorPreview.showHighlightColor`	Highlight occurrences with the detected color as background or underline	`false`
`unityColorPreview.highlightOpacity`	Opacity of the highlight overlay when highlighting colors (0-1)	`0.25`
`unityColorPreview.highlightStyle`	Rendering style for highlights: background fill or underline	`background`
`unityColorPreview.showOverviewRulerColor`	Show color marks in the editor overview ruler for detected colors	`false`
`unityColorPreview.preferredFormat`	Preferred constructor format in the quick color presentations	`Color`
`unityColorPreview.floatPrecision`	Number of decimal places for float components in Color presentations (0-6)	`3`
`unityColorPreview.includeAlphaByDefault`	List alpha-including presentations before non-alpha ones	`true`
`unityColorPreview.enableNamedColors`	Detect and preview named colors like Color.red, Color.white, Color.clear	`true`

Configuration Examples

Enable color highlighting with custom opacity:

{
  "unityColorPreview.showHighlightColor": true,
  "unityColorPreview.highlightOpacity": 0.3,
  "unityColorPreview.highlightStyle": "background"
}

Use Color32 as preferred format with higher precision:

{
  "unityColorPreview.preferredFormat": "Color32",
  "unityColorPreview.floatPrecision": 4,
  "unityColorPreview.includeAlphaByDefault": false
}

Disable named colors and overview ruler:

{
  "unityColorPreview.enableNamedColors": false,
  "unityColorPreview.showOverviewRulerColor": false
}

Known Issues

Does not parse variables or expressions, only direct constructor literals.

Release Notes

See CHANGELOG.md.

Contributing

Contributions welcome! See CONTRIBUTING.md.
