Slurm Dev Containers

Develop inside Apptainer containers that run as Slurm jobs on HPC clusters, similar to the Dev Containers extension, which needs Docker.

You describe the container in .slurm-devcontainer/slurm-devcontainer.json. With one command the extension:

1. submits a Slurm job (or reuses the running one) that starts the container on a compute node;
2. opens the project inside the container at /workspaces/<project> in a new VS Code window.

Status: early MVP. Feedback and bug reports are welcome. See TODO.md for planned features.

How it works

 your computer                      login node                         compute node (Slurm job)
┌──────────────────┐  ssh <alias>  ┌──────────────────┐               ┌──────────────────────────────┐
│ VS Code          │──────────────▶│ sbatch / squeue  │──── sbatch ──▶│ apptainer instance (image)   │
│  + this extension│               └──────────────────┘               │ sshd (as you, random port)   │
│  + Remote-SSH    │════════ ssh -J <alias> node:port ═══════════════▶│   └─ every session runs      │
└──────────────────┘                                                  │      inside the container    │
                                                                      └──────────────────────────────┘

• The extension runs on your computer. It runs sbatch/squeue/scancel on the login node through your normal ssh <alias>.
• The job starts an Apptainer instance and the compute node's own sshd binary, running as your user on a free port. Every session on that sshd is forced into the container, so VS Code's server and your terminals run inside it.
• Remote-SSH connects to that sshd through the login node (ProxyJump). The connection uses a host entry that the extension writes into its own file, ~/.ssh/slurm-devcontainer/config.
• The extension remembers each dev container (login node + project path). Connect to Container... works from any window, and later connects reuse the running job or start a new one.

Requirements

On your computer

• VS Code with the Remote - SSH extension.
• An OpenSSH client (ssh, ssh-keygen).
• ssh <alias> to the login node must work without a password prompt. The extension runs ssh in batch mode. Use an SSH key, or a ControlMaster connection if your cluster requires 2FA (see below).

On the cluster

• Slurm commands (sbatch, squeue, scancel) on the login node.
• Apptainer (or Singularity) on the compute nodes, with support for apptainer instance.
• An sshd binary on the compute nodes (default /usr/sbin/sshd). No root access or system sshd configuration is needed.
• The login node must be able to reach compute nodes on TCP ports 20000–50000.
• A home directory shared between login and compute nodes.

Many clusters meet these requirements, but some sites forbid user-level sshd processes in jobs. Check your site's policy if connections fail.

Getting started

1. Connect VS Code to the cluster login node with Remote-SSH and open your project folder.
2. Run Slurm Dev Containers: Add Configuration File... and adjust the image and resources.
3. Run Slurm Dev Containers: Open Folder in Container.
   • The first time, the extension asks whether it may add one line to ~/.ssh/config on your computer (see Files). You can also copy the line and add it yourself.
   • A notification shows the job state while the job is pending. When it is running, a new window opens inside the container.
4. Later, run Slurm Dev Containers: Connect to Container... from any window, even without a connection to the cluster. It reconnects to the running job or starts a new one.

Configuration

.slurm-devcontainer/slurm-devcontainer.json (JSON with comments) uses a subset of devcontainer.json:

{
	"name": "my-project",
	"image": "docker://mcr.microsoft.com/devcontainers/python:3.12",
	"workspaceFolder": "/workspaces/${localWorkspaceFolderBasename}",
	"containerEnv": { "DATA_DIR": "/scratch/${localEnv:USER}" },
	"mounts": ["source=/scratch/${localEnv:USER},target=/scratch,type=bind"],
	"customizations": { "vscode": { "extensions": ["ms-python.python"] } },
	"slurm": { "partition": "gpu", "time": "08:00:00", "cpusPerTask": 8, "mem": "32G", "gpus": 1 },
	"apptainer": { "modules": ["apptainer"], "runArgs": ["--containall", "--nv"] }
}

Variables: ${localWorkspaceFolder} and ${localWorkspaceFolderBasename} refer to the project folder on the cluster. ${containerWorkspaceFolder} is the folder inside the container. ${localEnv:VAR} and ${localEnv:VAR:default} read your environment on the login node.

The project folder is mounted at workspaceFolder. The container image itself is read-only.

Isolation

Containers are isolated by default, as you know it from Dev Containers. The defaults are:

"apptainer": {
	"runArgs": ["--containall"],   // keep it when adding flags, e.g. ["--containall", "--nv"]
	"persistentWorkdir": true
	// "persistentWorkdirPath": "~/containers/${localWorkspaceFolderBasename}"  // optional
}

What is hidden: your real home directory (including SSH keys and dotfiles), the host's /tmp, the admin-configured bind paths, the host's processes (own PID namespace), and the host environment.

The persistent workdir: with --containall, Apptainer would keep the container's home and /tmp on a small temporary filesystem (64 MiB by default). That is too small for the VS Code server, whose download goes through /tmp, and it is lost after every job. persistentWorkdir passes Apptainer's --workdir with a directory on the cluster, by default ~/.slurm-devcontainer/work/<project>. It holds the container's /tmp, /var/tmp and home. The container home appears at your normal home path but starts empty (ls -a ~ shows .vscode-server after the first connect). The VS Code server and extensions are downloaded once and kept across jobs.

• Downloading the server needs internet access on the compute node. Otherwise set "remote.SSH.localServerDownload": "always" so VS Code downloads it on your computer.
• Proxies: --containall also clears the environment. If your site uses a proxy, pass it in: "containerEnv": { "https_proxy": "${localEnv:https_proxy}" }.
• Your own --workdir: set "persistentWorkdir": false if you pass --workdir in runArgs. The extension reports the conflict otherwise.
• Resetting: delete the work folder, then remove and re-add the container with Remove Container from List... so the configured extensions are installed again.

What is not isolated:

• The network: the container shares the node's network. Separating it would also cut off VS Code's connection.
• The project folder is mounted read-write. Anything in it, including .git, can be changed or deleted.
• Mounts you add under mounts.
• Git credentials from VS Code: VS Code forwards Git credential requests from the integrated terminal to your computer, so git push inside the container may use your local credentials. Set "git.terminalAuthentication": false (and possibly "git.useIntegratedAskPass": false) to prevent this.

Turning isolation off

Set "runArgs": [] (plus any flags you need, without --containall) and "persistentWorkdir": false. The container then behaves like plain Apptainer, which is built to blend into an HPC system rather than to isolate you from it. It swaps the software environment (the image's OS, libraries and tools) but keeps:

• your user: whoami shows your cluster user, with your normal permissions. There is no root, and no vscode user, even if the image defines one. A /home/vscode you may see comes from the image. This applies to isolated containers too.
• the node's hostname and network: a shell prompt shows the compute node's name. Check cat /etc/os-release to see that you are inside the container. This also applies to isolated containers.
• parts of the host file system: your home (at its real path), /tmp, /var/tmp, and any bind path entries your admins configured in apptainer.conf, often shared data or scratch file systems. Files there are protected only by their normal permissions.

Commands

Settings

Files written by the extension

On your computer

• ~/.ssh/slurm-devcontainer/config holds one Host slurm-devcontainer-<cluster>-<project> entry per dev container. The compute node and port are updated on every connect.
• ~/.ssh/slurm-devcontainer/id_ed25519 is a key pair used only to log into the containers' sshd.
• ~/.ssh/slurm-devcontainer/known_hosts holds the pinned host key of the job sshd, one per cluster. It is fetched over your trusted login connection.
• ~/.ssh/config gets the line Include ~/.ssh/slurm-devcontainer/config at the top, only if you click "Add Line". Remote-SSH can only find the container hosts through this line. No other change is ever made to your SSH config.

On the cluster (in your home directory)

• ~/.slurm-devcontainer/ssh/ holds the sshd host key and an authorized_keys file containing only the extension's public key.
• ~/.slurm-devcontainer/work/<project>/ is the container's persistent workdir (/tmp, /var/tmp and home), with persistentWorkdir: true (the default) and no persistentWorkdirPath.
• ~/.slurm-devcontainer/sessions/<project>/ holds the generated job.sh, sshd_config and enter.sh, plus job.log and the current connection details.

Logins with 2FA or passwords

The extension cannot answer password or 2FA prompts. Let one interactive login be shared by all ssh connections with ControlMaster, in ~/.ssh/config on your computer:

Host my-cluster
  HostName login.cluster.example.org
  User jdoe
  ControlMaster auto
  ControlPath ~/.ssh/cm-%r@%h:%p
  ControlPersist 8h

Log in once in a terminal (ssh my-cluster). Afterwards the extension and Remote-SSH reuse that connection. ControlMaster is not available with the Windows OpenSSH client.

Troubleshooting

• The job fails or never becomes ready. Run Show Job Log.... Common causes are an image that cannot be pulled, a missing module load, or a site that does not allow user-level sshd.
• "Could not resolve hostname slurm-devcontainer-…": the Include line is missing from ~/.ssh/config or is not at the top (before any Host/Match block).
• Connection times out after the job started. The login node probably cannot reach the compute node's port. Ask your admins whether login→compute connections on high ports are allowed.
• Remote-SSH asks for the platform of the host. Choose "Linux".
• nvidia-smi not found in the container. GPUs need both "slurm": { "gpus": 1 } (or "sbatchArgs": ["--gres=gpu:1"] on sites that expect --gres) and --nv in apptainer.runArgs. To check the cluster itself, run srun -p <gpu-partition> --gpus=1 --pty bash, then nvidia-smi and apptainer exec --containall --nv docker://ubuntu:24.04 nvidia-smi.
• Extensions fail to install in the container. Compute nodes often have no internet access. Set "remote.downloadExtensionsLocally": true so VS Code downloads extensions on your computer and uploads them.
• The extension's output channel is Output → Slurm Dev Containers, and it contains the details of every step.

Related projects

• gmertes/vscode-remote-hpc: a script-based setup that connects VS Code's Remote-SSH to a Slurm compute node via an sshd started in a batch job. It uses the same connection idea, without containers.

Development

npm install
npm run compile      # type-check, lint, bundle
npm run test:unit    # unit tests (no VS Code instance needed)

Press F5 in VS Code to start an Extension Development Host.
