Pandoc Manuscript Tools

Local VS Code tools for this repository's Pandoc Markdown manuscript syntax.

Features

• Go to definition for @sec:*, @fig:*, @tbl:*, and @eq:* references.
• In a file named reply_to_reviewers.md, definitions from the workspace-root manuscript.md are also available for navigation, hover summaries, completions, and undefined-reference diagnostics.
• Find all references for Pandoc labels and reference tokens.
• Hover cards for labels, references, display math blocks, and inline math spans with MathJax-rendered SVG previews. Math hovers work in Markdown, MDX, and LaTeX (.tex) editors.
• Hover previews for local SVG, EMF, and WMF image references in Markdown/MDX. SVG previews inline local <image href> assets before rendering, and EMF/WMF previews are shown through SVG preview sources.
• Optional paragraph translation hovers that show whether Google Translate or Microsoft Translator handled the current translation.
• Optional paragraph-level hover previews for Markdown paragraphs that contain inline math.
• A Pandoc-aware Outline provider that treats $$ {#eq:label} as a valid display-math closing delimiter.
• Whole-line highlighting for Pandoc fenced_divs blocks, with subtle background colors that alternate by nesting depth.
• Inline highlighting for Pandoc bracketed spans such as [Get out]{custom-style="Emphatically"}.
• Inline folding for quoted line annotations such as (Line `quoted text`); moving the cursor into the code span temporarily reveals the excerpt for editing.
• Inline folding for the attribute block in [revised text]{custom-style="Revision Char"} spans; other custom styles remain visible.
• Completion suggestions after @ using labels found in the current Markdown document.
• Diagnostics for undefined references and duplicate labels in the current Markdown document.
• A DOCX build button in the editor title for saved Markdown files inside a detected Pandoc manuscript template project when uv is installed.

Try It Locally

1. Open this repository folder in VS Code.
2. Run npm install once so the MathJax renderer is available.
3. Press F5 to launch an Extension Development Host.
4. In the Extension Development Host, open the manuscript repository folder.
5. Open manuscript.md and try:
   • Ctrl-click @eq:loss or @tbl:results.
   • Run Find All References on {#eq:loss}.
   • Hover over an equation block or inline math span such as $f(x)$ to see the rendered MathJax SVG preview.
   • Hover over an image reference such as ![icon](https://github.com/cesaryuan/vscode-pandoc-manuscript-tools/raw/HEAD/assets/document-icon.svg) or ![icon](https://github.com/cesaryuan/vscode-pandoc-manuscript-tools/raw/HEAD/assets/document-icon.emf) to see the rendered image preview.
   • Add a Pandoc fenced div such as ::: note or :::: {#special .sidebar} and confirm the block is highlighted in the editor.
   • Add a Pandoc bracketed span such as [Get out]{custom-style="Emphatically"} and confirm the span is highlighted inline.
   • Add (Line `A quoted manuscript sentence`) and confirm the quoted text folds to an ellipsis until the cursor enters the code span.
   • Add [revised text]{custom-style="Revision Char"} and confirm only the {custom-style="Revision Char"} block folds to an ellipsis.
   • Click the editor-title build button in manuscript.md to run the DOCX build and open output/docx/manuscript.docx.
   • Check the Outline after ## Mathematical Formulation.

For build and packaging commands, see DEVELOPMENT.md.

Commands

• Pandoc Manuscript Tools: Rebuild Index
• Pandoc Manuscript Tools: Build DOCX and Open in Word

Settings

• pandocManuscriptTools.enableDiagnostics: report undefined references and duplicate labels.
• pandocManuscriptTools.includeWorkspaceReferences: preload workspace Markdown files for the index cache; reference lookups stay scoped to the active document except for the built-in reply_to_reviewers.md → manuscript.md definition link.
• pandocManuscriptTools.includeLabelSymbols: show equation, figure, and table labels in the Outline.
• pandocManuscriptTools.highlightFencedDivs: highlight Pandoc fenced_divs blocks with whole-line background colors.
• pandocManuscriptTools.highlightBracketedSpans: highlight Pandoc bracketed spans with inline background colors.
• pandocManuscriptTools.foldLineExcerptCodeSpans: fold the quoted code span in annotations such as (Line `quoted text`) until the cursor enters it.
• pandocManuscriptTools.foldRevisionCharSpanAttributes: fold {...} only when the span's custom-style value is exactly Revision Char.
• pandocManuscriptTools.enableInlineMathParagraphHover: show a paragraph-level hover preview for Markdown paragraphs that contain inline math.
• pandocManuscriptTools.inlineMathParagraphHoverMaxCharacters: maximum paragraph length, in characters, that can show an inline-math paragraph hover preview.
• pandocManuscriptTools.enableParagraphHoverTranslation: show a translation for eligible English paragraph hovers, using Google Translate when available and Microsoft Translator as a fallback.
• pandocManuscriptTools.paragraphHoverTranslationMaxCharacters: maximum English paragraph length, in characters, that can request a paragraph hover translation.
• pandocManuscriptTools.paragraphHoverTranslationTargetLanguage: target language code for paragraph hover translations, for example zh or zh-TW.

Notes

This extension is intentionally a small language-service layer rather than a full Markdown parser. It scans the Pandoc-crossref syntax used by this manuscript template and avoids code fences and YAML front matter to reduce false positives.

The math hover uses MathJax's Node component loader to convert TeX into SVG and embeds the SVG as a hover image. Raw TeX is shown only as a fallback when rendering fails. Display math and inline math are rendered separately, and inline math is not treated as a cross-reference source. Paragraph-level inline math hovers are disabled by default because they produce larger hover cards. Paragraph translations may make network requests; the extension probes Google Translate on startup, falls back to Microsoft Translator if Google is unavailable, and shows the engine used for each translated hover. If the preview is unavailable, run npm install in this folder and reload the Extension Development Host.

Image hovers resolve local Markdown and HTML image references for .svg, .emf, and .wmf files. SVG previews are embedded as self-contained data URIs so nested local <image href> references can use relative paths, absolute paths, or file:// URLs. EMF and WMF previews use the bundled libemf2svg renderer and are returned as SVG so hover and side-preview rendering use the same inline-SVG display path. Metafile previews may differ from Windows GDI for complex clipping, raster operations, gradients, or unavailable fonts.

The DOCX build button is shown only when the active saved Markdown file belongs to a workspace folder that looks like this Pandoc manuscript template: it has scripts/build.py or scripts/build, the DOCX post-processing scripts, and pandoc/pandoc-docx.yml. The command runs uv run <build-script> docx <markdown-file> from the detected project root, then opens the generated file from output/docx/.
