SWF Debugger for Visual Studio Code
Enables debugging applications in the Adobe AIR and Adobe Flash Player runtimes. Supports source files written in ActionScript, MXML, or Haxe.
Extension created and maintained by Josh Tynjala. By becoming a patron, you can directly support the ongoing development of this project.
Requirements
- Visual Studio Code 1.82
- Java JDK 11 or newer
- Adobe AIR or Adobe Flash Player
Adobe AIR
To debug Adobe AIR applications, download the Adobe AIR SDK for Windows or macOS, which is available from HARMAN's website:
For Adobe AIR version 32.0 or older, download it from Adobe's website instead:
Adobe Flash Player
To debug .swf files in Adobe Flash Player, download the Flash Player projector content debugger for Windows, macOS, or Linux, which may still be available from Adobe's website at the following locations.
Be sure to make the Flash Player the operating system's default program for the .swf file extension. If it's not the default program, it's possible manually specify the executable path using the runtimeExecutable attribute in launch.json instead.
Getting Started
Depending on which language/framework builds the .swf file, the steps to configure the SWF debug extension may vary.
ActionScript and MXML
This extension offers tight integration with the ActionScript & MXML langauge extension. Many attributes in the workspace's launch.json file can be omitted because they will be populated automatically based on the project's asconfig.json file.
ActionScript & MXML projects built using any of the following SDKs or tools may be debugged using the SWF debug extension:
- Adobe AIR SDK & Compiler
- Adobe Animate
- Apache Flex SDK
- Adobe Flex SDK
- Apache Royale
- Feathers SDK
To get started, create a new launch configuration. All launch configurations for the current worksace are stored in its .vscode/launch.json file.
The following example launch.json contains a swf launch configuration with the minimum set of attributes required to launch a debug session for an ActionScript & MXML project:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF"
}
]
}
Using the contents of the project's asconfig.json file, the SWF debug extension automatically detects which runtime should be used (either Adobe AIR or Flash Player). Additionally, it will detect the location of the compiled .swf file, and (if it exists) the location of the Adobe AIR application descriptor file. The extension can also determine if an Adobe AIR project targets desktop or mobile.
Start a debug session
To start debugging, open the Debug menu in Visual Studio Code, and select Start Debugging (or use the F5 keyboard shortcut).
Build before debugging (AS3 & MXML)
To build an ActionScript & MXML project before starting a debug session, add the preLaunchTask attribute. In most cases, use the compile task specified in the following example:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"preLaunchTask": "ActionScript: compile debug - asconfig.json"
}
]
}
OpenFL
When using OpenFL to target Adobe AIR or Flash Player, certain additional SWF launch configuration attributes need to be set manually.
Most importantly, the program attribute must be set to either the path of an Adobe AIR application descriptor or the path of a .swf file.
Find the correct paths inside the project.xml file that configures OpenFL. In particular, this information is available on the <app> element:
<app main="com.example.MyProject" file="MyProject" path="bin"/>
The path attribute is the main output folder where binaries are created. The file attribute is used to name the compiled .swf file.
Building the project above for Adobe Flash Player creates bin/flash/bin/MyProject.swf. Specify this path using the program attribute, as shown below:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"program": "${workspaceFolder}/bin/flash/bin/MyProject.swf"
}
]
}
When building the same project for Adobe AIR, the .swf file is created at bin/air/bin/MyProject.swf instead. OpenFL also creates the Adobe AIR application descriptor at bin/air/application.xml.
Notice that application.xml and MyProject.swf are not located in the same folder. However, inside application.xml, it references MyProject.swf file instead of bin/MyProject.swf:
<content>MyProject.swf</content>
Use the rootDirectory attribute to specify that the app's content is not located in the same folder that contains the application descriptor.
Set the profile attribute to either desktop or mobileDevice, depending on which platform should be simulated.
Finally, the SWF debugger needs the location of the adl executable from the Adobe AIR SDK. Pass the absolute path to the runtimeExecutable attribute.
The following example launch.json file combines all of these values to configure Adobe AIR debugging for an OpenFL project:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"profile": "desktop",
"program": "${workspaceRoot}/bin/air/application.xml",
"rootDirectory": "${workspaceRoot}/bin/air/bin",
"runtimeExecutable": "/absolute/path/to/AIR_SDK/bin/adl"
}
]
}
On macOS, use adl as the excutable name. On Windows, use adl.exe.
When setting up Lime and OpenFL, you may have already set up the path to the Adobe AIR SDK, which is stored in ~/.lime/config.xml. It's a good idea to use the same SDK for debugging.
Start a debug session
To start debugging, open the Debug menu in Visual Studio Code, and select Start Debugging (or use the F5 keyboard shortcut).
Build before debugging (OpenFL)
To build an OpenFL project before starting a debug session, add the preLaunchTask attribute.
When targeting Adobe Flash Player, run the lime: build flash -debug task:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"program": "${workspaceFolder}/bin/flash/bin/MyProject.swf",
"preLaunchTask": "lime: build flash -debug"
}
]
}
When targeting Adobe AIR, run the lime: build air -debug task:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"profile": "desktop",
"program": "${workspaceRoot}/bin/air/application.xml",
"rootDirectory": "${workspaceRoot}/bin/air/bin",
"runtimeExecutable": "/absolute/path/to/AIR_SDK/bin/adl",
"preLaunchTask": "lime: build air -debug"
}
]
}
Haxe
When using Haxe to target Adobe AIR or Flash Player, certain compiler options must be used to enable debugging, and additional SWF launch configuration attributes need to be set manually.
To compile a .swf file with Haxe that may be used with the SWF debug extension, add -debug and -D fdb to the project's .hxml file, as shown in the example below:
-cp src
-main com.example.MyProject
-swf bin/MyProject.swf
-swf-version 30
-swf-header 960:640:60:ffffff
-debug
-D fdb
To debug in Adobe Flash Player, set the program attribute in launch.json to the path specified by the -swf Haxe compiler option:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"program": "${workspaceFolder}/bin/MyProject.swf"
}
]
}
To debug in Adobe AIR, set the program attribute in launch.json to the path of an Adobe AIR application descriptor.
Set the profile attribute to either desktop or mobileDevice, depending on which platform should be simulated.
Finally, the SWF debugger needs the location of the adl executable from the Adobe AIR SDK. Pass the absolute path to the runtimeExecutable attribute.
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"profile": "desktop",
"program": "${workspaceRoot}/bin/MyProject-app.xml",
"runtimeExecutable": "/absolute/path/to/AIR_SDK/bin/adl"
}
]
}
On macOS, use adl as the excutable name. On Windows, use adl.exe.
Additional Examples
For Adobe AIR mobile projects, a number of additional attributes are available to customize which type of device to simulate. For example, the following launch configuration simulates an iPhone with "Retina" display:
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"screensize": "iPhoneRetina",
"screenDPI": 326,
"versionPlatform": "IOS"
}
]
}
Similarly, the following launch configuration might be used to simulate an Android phone.
{
"version": "0.2.0",
"configurations": [
{
"type": "swf",
"request": "launch",
"name": "Launch SWF",
"screensize": "768x1280:768x1232",
"screenDPI": 318,
"versionPlatform": "AND"
}
]
}
For a larger list of common mobile devices, see launch.json configuration settings for simulating common mobile devices in Adobe AIR.
Launch configuration attributes
The following lists of attributes may be customized in launch.json for the configurations of type swf. They are divided by request type — either launch or attach.
Launch request
If the value of the request attribute is set to launch, the following attributes may be customized:
args
Custom command line arguments to pass to an Adobe AIR application. The are accessible at runtime using the arguments property of flash.events.InvokeEvent.
exdir
The directory where the application's unpackaged native extensions (ANEs) are located. Unpackaged native extensions are unzipped for debugging. The ActionScript & MXML extension unpackages native extensions automatically. Unpackaging should be done manually for Haxe projects.
Populated automatically for ActionScript & MXML projects
profile
The Adobe AIR application profile to simulate. May be set to desktop, extendedDesktop, mobileDevice, or extendedMobileDevice.
Populated automatically for ActionScript & MXML projects
program
Path to an Adobe AIR application descriptor or a .swf file. To launch a .swf file embedded in HTML, set to the path of an .html file or to an http/https URL.
Populated automatically for ActionScript & MXML projects
rootDirectory
Specifies the root directory of the Adobe AIR application. If not specified, the directory containing the application descriptor file is used.
runtimeArgs
Optional arguments to pass to the runtime executable.
runtimeExecutable
Path to the Adobe AIR debug launcher, the Flash Player projector content debugger, or a web browser.
screenDPI
The screen density (sometimes called DPI or PPI) of the mobile device to simulate. Customizes the value returned by flash.system.Capabilities.screenDPI. Typically used in combination with screensize.
screensize
The normal and full-screen dimensions of the simulated mobile device. Typically used in combination with screenDPI.
versionPlatform
The platform string to simulate in the AIR Debug Launcher. Customizes the value returned by flash.system.Capabilities.version. May be set to IOS, AND, WIN, or MAC.
Attach request
If the value of the request attribute is set to attach, the following attributes may be customized:
applicationID
If the platform attribute is set, specifies the Adobe AIR application ID used to uninstall and launch on a mobile device connected with USB.
Populated automatically for ActionScript & MXML projects
bundle
If the platform attribute is set, specifies the path to an .apk or .ipa file to install on a mobile device connected with USB.
Populated automatically for ActionScript & MXML projects
connect
By default, the SWF debugger will listen for connections from mobile devices over wi-fi. If the connect attribute is true, the debugger will try to connect to the runtime over USB instead.
port
If the connect attribute is true, the SWF debugger will connect to the mobile device on the specified port.
platform
The debugger will connect to a mobile device running the specified platform. Supported values include "android", "ios", and "ios_simulator". This field may be combined with applicationID and bundle.
