RAGLaB

Interactive GUI Studio and Diagnostic Workbench for Retrieval-Augmented Generation (RAG) Engineering

+-----------+     +----------+     +------------+     +-----------------+     +-----------+     +-----+
| Documents | --> | Chunking | --> | Embeddings | --> | Vector Database | --> | Retrieval | --> | LLM |
| (.md,.txt)|     | (RAGLaB) |     | (Vectors)  |     |(pgvector,Chroma)|     |  (Top-K)  |     |(Gen)|
+-----------+     +----------+     +------------+     +-----------------+     +-----------+     +-----+

Retrieval-Augmented Generation (RAG) pairs Large Language Models with external, verifiable reference materials. Source files are segmented into discrete text chunks, embedded into vector space, stored in a vector index, retrieved by semantic relevance to a query, and provided as prompt context.

Downstream model precision and hallucination prevention depend directly on chunking quality. Arbitrary text splits, severed sentences, and noisy segments degrade similarity search and truncate critical facts. RAGLaB provides an interactive, lightweight, 100% local workbench within your IDE to inspect, partition, test, and tune document structures before ingestion.

Table of Contents

• Key Highlights
• Interactive GUI Feature Tour
• Feature Usage Guide
  • 1. Launching RAGLaB Studio
  • 2. Document Inspector
  • 3. Chunking Studio and Visualizer
  • 4. Local Retrieval Simulator and Headroom Gauge
  • 5. Workspace Technology Scanner
  • 6. Activity Bar Sidebar
• Available Commands
• Configuration Settings
• Chunking Strategy and Engineering Guide
• Supported File Formats
• Decoupled Architecture
• Development, Testing and Packaging
• Strategic Roadmap
• Contributing
• Security and Privacy
• License

Key Highlights

• Complete Graphical User Interface (GUI): Profile document metrics, slide chunk parameters, navigate partitions, and audit repository dependencies through an integrated visual workbench.
• Privacy First and Fully Local: Zero network requests, zero telemetry, and zero third-party API dependencies. Every computation runs locally on your workstation.
• Hierarchical Boundary-Aware Chunking: Intelligently segments prose along paragraph (\n\n), sentence (. ! ?), and word boundaries. Words and semantic clauses remain intact.
• Interactive Visualizer and In-Place Search: Step through chunks sequentially with arrow keys, jump to arbitrary indices, and perform instant full-text searches with highlighted matches.
• RAG Stack Dependency Scanner: Audits project dependency manifests (requirements.txt, package.json, pyproject.toml) and directory layouts to report vector databases, embedding engines, and RAG folders.
• Lightweight Footprint: Constructed with vanilla TypeScript and native editor design tokens. The packaged extension distribution is under 100 KB.

Interactive GUI Feature Tour

Feature Usage Guide

1. Launching RAGLaB Studio

RAGLaB can be opened through three convenient entry points:

• Activity Bar Icon: Click the beaker icon on the left Activity Bar labeled RAGLaB, then click Launch Visual Workbench.
• Command Palette: Press Ctrl+Shift+P (or Cmd+Shift+P on macOS), search for RAGLaB, and select RAGLaB: Open Studio Dashboard.
• Context Menu: Right-click any supported text document (.md, .txt, .json, .csv) in your File Explorer or Editor and select RAGLaB: Analyze Document or RAGLaB: Create Chunks.

2. Document Inspector

1. Open the Document Inspector tab in RAGLaB Studio.
2. Select your preferred text input source:
   • Interactive Drop Zone: Drag and drop any .md, .txt, .json, or .csv file directly onto the upload target.
   • Select File from Disk: Opens a native file dialog to choose any .md, .txt, .json, or .csv file.
   • Load Active File: Reads content directly from the file currently open in your editor.
   • Load Sample Document: Populates the inspector with a pre-configured technical document on RAG architectures for immediate testing.
   • Scratchpad: Type or paste arbitrary text directly into the scratchpad area and click Analyze Text.
3. Review key document statistics:
   • Characters: Exact character count.
   • Words: Total words segmented by whitespace.
   • Estimated Tokens: Word-based heuristic calculated as ~words x 1.3.
   • Lines and Blank Lines: Total line count alongside empty line distribution.
   • Average Words per Line: Measure of textual density.
4. If formatting issues are detected (e.g. excessive empty lines), a notification banner highlights recommendations.
5. Click Send to Chunking Studio to transfer the parsed text directly into the chunking workbench.

3. Chunking Studio and Visualizer

1. Open the Chunking Studio tab.
2. Select your Architecture Strategy:
   • Parent-Document (Small-to-Big) [Highest Accuracy]: Partitions text into large parent context blocks (for the LLM prompt) and small child units (for vector search). Eliminates vector dilution while preventing context starvation.
   • Markdown & Structural Hierarchy [AST Integrity]: Preserves Markdown tables and fenced code blocks as atomic units (never severed), while attaching hierarchical heading breadcrumbs ([Document > Section > Subsection]).
   • Recursive Boundary-Aware [Balanced]: Hierarchically splits across paragraphs (\n\n), sentences (. ! ?), and words.
3. Configure parameters using sliders, steppers, or Quick Presets:
   • Factoid (250 / 25): Compact partitions optimized for precise entity lookups and FAQ matching.
   • Standard RAG (500 / 50): Balanced partitions suitable for general technical documentation and articles.
   • Deep Context (1000 / 100): Broad partitions for narrative prose, legal briefs, and summaries.
   • For Parent-Document mode, adjust Parent Context Size (default: 1,200 chars).
   • Parameter Validation: If overlap equals or exceeds chunk size, or if parent size is less than child size, an inline alert prevents execution until corrected.
4. Click Generate Chunks.
5. Examine the generated distribution:
   • Total chunk count.
   • Character, word, and token distribution (Min, Average, Max).
   • Quality indicators flagging sub-sized or oversized segments.
6. Inspect segments in the Chunk Explorer:
   • In Parent-Document mode, toggle between Child Search Unit (the exact vector search slice) and Parent LLM Context (the full context block with the child slice highlighted).
   • In Markdown mode, review the Hierarchy Breadcrumb pill and atomic preservation badges.
   • Use Previous and Next buttons or keyboard arrow keys (Left / Right) to browse segments sequentially.
   • Enter terms into the search bar to highlight occurrences in yellow and view matching chunk totals.
   • Use Copy Chunk for the active segment, Copy All Chunks for a concatenated overview, or Save to File (.json) to write the dataset directly to your workspace.

4. Local Retrieval Simulator and Headroom Gauge

Located beneath the chunk preview in the Chunking Studio:

1. Enter a natural language query (for example: "How does vector chunking preserve context?").
2. Click Retrieve Top Chunks or press Enter.
3. The local retrieval engine scores all chunks using TF-IDF and returns the Top-3 Ranked Matches with match percentages.
4. In Parent-Document mode, each card displays the matching child score alongside the Parent Context token size.
5. Click any ranked match card to instantly navigate to that chunk in the explorer with matching terms highlighted.
6. Review the LLM Context Headroom Gauge:
   • Calculates the collective token footprint of retrieved chunks (or unique parent context blocks).
   • Displays percentage consumption against standard 4K and 8K context windows, ensuring prompt templates and system directives have ample headroom.

5. Workspace Technology Scanner

1. Open the Workspace Scanner tab.
2. Click Scan Workspace.
3. RAGLaB parses repository configuration manifests (requirements.txt, package.json, pyproject.toml) and directory trees safely without running code.
4. Review findings:
   • RAG Readiness: Displays an active status pill when vector databases, embedding engines, or orchestrators are detected.
   • Category Filters: Filter cards by All, Vector DBs, Embeddings, Orchestration, or Frameworks.
   • Technology Cards: Indicates detection status ([Active] with source filename vs [Not Found]).
   • Supported technologies include: pgvector, Chroma, FAISS, Qdrant, Pinecone, Weaviate, Milvus, PostgreSQL, Sentence Transformers, OpenAI, HuggingFace, LangChain, LlamaIndex, Haystack, FastAPI, Flask, Express, Python, and TypeScript.
   • RAG Directories: Highlights ingestion folders such as documents/, embeddings/, retrieval/, and data/.
   • Copy Report: Copies the full repository audit summary to your clipboard.

6. Activity Bar Sidebar

The RAGLaB Sidebar lives in the primary Activity Bar:

• Launch Visual Workbench: Opens the full multi-tab studio.
• Analyze Document Structure: Prompts for a file and opens its structural profile.
• Partition & Chunk Document: Opens chunking options for the selected file.
• Preview Active Document: Generates an immediate chunk preview of the active editor file.
• Scan RAG Tech Stack: Performs a workspace technology scan.

Available Commands

Every capability is accessible via the Command Palette (Ctrl+Shift+P / Cmd+Shift+P):

Configuration Settings

Configure global defaults in VS Code Settings (Ctrl+, / Cmd+,) under Extensions > RAGLaB:

Chunking Strategy and Engineering Guide

RAGLaB equips engineers with three distinct architectural chunking strategies directly in the GUI:

1. Parent-Document (Small-to-Big) Strategy [Highest Accuracy]

Solves the fundamental contradiction between vector search precision and LLM context completeness:

• Vector Search prefers small chunks (100–250 tokens) to produce sharp, focused embedding vectors without semantic dilution.
• The LLM needs large chunks (800–2,000 tokens) to retain definitions, conditions, caveats, and full narrative context.
• Workflow: Large Parent Chunks (1,200–1,500 chars) are created for context, and small Child Chunks (250–300 chars) are created for indexing. When a Child Chunk is retrieved, its full Parent Chunk is supplied to the LLM prompt.

Document Text
  |
  +--> Parent Chunk [#1](https://github.com/aroshwijesinghe/RAGLab/issues/1) (1,200 chars) [Passed to LLM Prompt]
  |      |-- Child Chunk 1.1 (250 chars) [Indexed in Vector DB]
  |      |-- Child Chunk 1.2 (250 chars) [Indexed in Vector DB]
  |      \-- Child Chunk 1.3 (250 chars) [Indexed in Vector DB]
  |
  \--> Parent Chunk [#2](https://github.com/aroshwijesinghe/RAGLab/issues/2) (1,200 chars) [Passed to LLM Prompt]
         |-- Child Chunk 2.1 (250 chars) [Indexed in Vector DB]
         \-- Child Chunk 2.2 (250 chars) [Indexed in Vector DB]

2. Markdown & Structural Hierarchy Strategy [AST Integrity]

Protects structured documents from boundary fracture:

• Table Preservation: Markdown tables (| col1 | col2 |) are treated as atomic units and are never severed across chunk borders.
• Code Block Preservation: Fenced code blocks (```python ... ```) remain whole to avoid syntax fragmentation.
• Contextual Breadcrumb Hierarchy: Parses headings (#, ##, ###) and prepends breadcrumbs ([Document > Installation > Config]) to chunk metadata so isolated chunks carry their domain origin.

3. Recursive Boundary-Aware Splitting [Balanced]

Processes prose hierarchically along natural language boundaries:

Raw Text Input
  |
  +--> 1. Paragraph Boundaries (\n\n)
  |      Preserves thematic sections when length fits within target size.
  |
  +--> 2. Sentence Boundaries (. ! ? \n)
  |      Preserves grammatical completeness when paragraphs exceed target size.
  |
  +--> 3. Word Boundaries (whitespace)
         Prevents mid-token truncation so words are never severed.

Strategy Selection Matrix

Overlap Engineering Guidelines

• Maintain an overlap ratio between 10% and 20% of your target chunk size (for example, 50 characters for a 500-character chunk).
• Overlap guarantees that compound ideas, dependent clauses, and entities spanning chunk cutoffs remain represented in adjacent retrieval units.

Supported File Formats

RAGLaB accepts text-native document formats for maximum tokenization accuracy and zero binary extraction corruption:

Decoupled Architecture

RAGLaB follows a modular separation of concerns:

src/
|-- extension.ts             # Entry point and subscription lifecycle
|-- commands/                # Command bridges between VS Code and workbench panels
|   |-- analyzeDocument.ts
|   |-- createChunks.ts
|   |-- previewChunks.ts
|   |-- analyzeWorkspace.ts
|   +-- openDashboard.ts
|-- services/                # Pure business logic isolated from UI concerns
|   |-- documentAnalyzer.ts  # Lexical and token calculation
|   |-- chunkingService.ts   # Boundary-aware text partitioning
|   |-- statisticsService.ts # Distribution mathematics
|   +-- workspaceAnalyzer.ts # Manifest parsing and folder audit
|-- models/                  # TypeScript interface contracts
|   +-- types.ts
|-- utils/                   # Pure helper functions
|   |-- textUtils.ts         # Formatting, token heuristics, and HTML escaping
|   +-- fileUtils.ts         # File system operations and size limits
|-- views/                   # Activity Bar sidebar implementation
|   +-- sidebarProvider.ts
+-- webview/                 # Studio panels, scripts, and layout controllers
    |-- dashboardPanel.ts
    |-- chunkViewerPanel.ts
    +-- templates/
        |-- dashboard.ts
        +-- chunkViewer.ts

Development, Testing and Packaging

Environment Prerequisites

• Node.js: >= 18.0.0
• npm: >= 9.0.0
• VS Code: >= 1.85.0

Build and Verification Commands

# Clone repository
git clone https://github.com/aroshwijesinghe/RAGLab.git
cd RAGLab

# Install dependencies
npm install

# Compile TypeScript bundle
npm run compile

# Run automated unit test suite (52 tests)
npm test

# Package VSIX distribution bundle
npx vsce package --no-dependencies

Press F5 in VS Code to start the Extension Development Host and debug live.

Strategic Roadmap

• [x] V0.1 (Current):
  • Document profiling with character, word, line, and token metrics.
  • Smart boundary-aware chunk partitioning with sliding overlap.
  • Interactive multi-tab RAGLaB Studio webview with official branding.
  • Real-time full-text search with marked match highlights.
  • Workspace technology scanner and folder audit.
  • Activity Bar sidebar view with immediate launch controls.
  • Local TF-IDF retrieval simulator and LLM context headroom gauge.
• [ ] V0.2 (Upcoming):
  • Local ONNX-powered vector embedding generation.
  • Cosine similarity matrix between adjacent chunks.
  • Embedding dimension analysis and token cost calculator.
• [ ] V0.3 (Planned):
  • PostgreSQL + pgvector live database connection manager.
  • Interactive SQL vector query runner.
• [ ] V0.4 (Planned):
  • Synthetic evaluation of retrieval precision and recall.
  • End-to-end prompt assembly preview.
• [ ] V1.0 (Vision):
  • Multi-vector database connector and automated pipeline optimization.

Contributing

Contributions are welcomed:

1. Fork the repository on GitHub.
2. Create a feature branch (git checkout -b feature/boundary-enhancement).
3. Verify all automated tests pass (npm test).
4. Commit using conventional commit format (git commit -m "feat: enhance sentence splitting for abbreviations").
5. Push to your branch and submit a Pull Request.

Security and Privacy

• 100% Local Execution: All computations execute inside the local VS Code extension process.
• Zero External Network Requests: Content and project structures are never transmitted externally.
• Zero Telemetry: No tracking scripts, analytics, or behavioral cookies are present.
• Read-Only Operations: File operations are strictly read-only by default; source files are never altered without user confirmation.

License

Distributed under the MIT License. See LICENSE for terms.
