Simple DB

A powerful VS Code extension for viewing, filtering, and exploring SQLite and MongoDB databases with an intuitive interface and smart filtering capabilities.

✨ Features

• SQLite Support: Connect to SQLite database files (.db, .sqlite, .sqlite3)
• MongoDB Support: Connect to MongoDB instances using connection strings
• Smart Filters:
  • Numbers: Use operators like >100, <50, >=10, <=20, 10-20 (range)
  • Dates: Filter with >2024-01-01, <2024-12-31, 2024-01-01 to 2024-12-31 (range)
  • Text: Simple substring matching
• Interactive Data Grid:
  • Click column headers to sort
  • Per-column filtering with search icon
  • Pagination for large datasets
  • Syntax-highlighted values (numbers, strings, booleans, null)
• Tree View Explorer: Browse databases and their tables/collections in the sidebar
• Persistent Connections: Automatically save and restore database connections
• Auto-Open SQLite Files: Automatically detect and open .db files when clicked

📸 Screenshots

Database Explorer

Database Explorer sidebar with connections and table tree view

Data Grid and Filtering

Interactive data grid with sorting and filtering

Smart filtering for number columns with operators

Date filtering with ranges and comparison operators

Query Features

Predefined sample queries for quick database exploration

AI-powered natural language query interface

SQL query editor with execution interface

Query results displaying aggregated data

Advanced Filtering

Column-specific filter menu

Available filter types and options

Multi-column sorting capabilities

🚀 Installation

Install from the VS Code Marketplace:

ext install apertacodex.simple-db

Or search for "Simple DB" in the Extensions view (Ctrl+Shift+X).

📖 Usage

Adding Database Connections

1. Open the Database Explorer in the VS Code sidebar (database icon)
2. Click the database icon (➕) to add a SQLite database
3. Click the server icon to add a MongoDB connection
4. Or simply open any .db file - it will be added automatically!

Viewing and Filtering Data

1. Expand a database connection in the explorer
2. Click on a table/collection to view its data
3. Click the filter icon (🔍) on any column header to filter:
   • For numbers: Type >100, <50, >=10, 10-20, etc.
   • For dates: Type >2024-01-01, 2024-01-01 to 2024-12-31, etc.
   • For text: Type any substring to search
4. Press Enter or click the 🔍 button to apply the filter
5. Click column headers to sort ascending/descending
6. Use pagination controls at the bottom to navigate large datasets

Filter Examples

Number Filters:

• >100 - Greater than 100
• <50 - Less than 50
• >=10 - Greater than or equal to 10
• 10-20 - Between 10 and 20 (range)
• !=5 - Not equal to 5

Date Filters:

• >2024-01-01 - After January 1, 2024
• <2024-12-31 - Before December 31, 2024
• 2024-01-01 to 2024-12-31 - Date range
• 2024-06 - Contains "2024-06" (partial match)

Configuration

The extension stores database connections in VS Code settings under simpleDB.connections.

Dependencies

• sqlite3: SQLite database driver
• mongoose: MongoDB object modeling tool

Development

• npm run compile: Compile TypeScript to JavaScript
• npm run watch: Watch for changes and recompile automatically

📝 Changelog

[0.0.164] - 2024-12-24

Added:

• Database icon for marketplace listing
• 3 professional screenshots showcasing features
• Enhanced README with badges and better documentation
• Categories and keywords for improved discoverability

Improved:

• Smart filter UI with search button icon (🔍)
• Date filters now support ranges and comparison operators
• Number filters support multiple operator types
• Filter help text shows supported operators

[0.0.163] - 2024-12-24

Added:

• Smart filtering system with operator support
• Number filters: >, <, >=, <=, =, !=, ranges
• Date filters: comparison operators and date ranges
• Filter submission via Enter key or button click
• Per-column filter inputs with type detection

Improved:

• Filter UI with dedicated input fields per column
• Better filter user experience with visual feedback

[0.0.1] - Initial Release

Added:

• SQLite database support (.db, .sqlite, .sqlite3)
• MongoDB connection support
• Interactive data grid with pagination
• Column sorting (ascending/descending)
• Global search across all columns
• Tree view explorer for databases and tables
• Persistent connection storage
• Auto-open SQLite files on click
• Syntax highlighting for different data types

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

🤝 Contributing

Contributions are welcome! Feel free to submit issues and pull requests on GitHub.

💬 Support

If you encounter any issues or have suggestions, please open an issue on GitHub.
