Jupyter Agentic Bridge

Expose the live Jupyter notebook open in your editor as MCP tools, so an agent can read, edit, execute, and inspect the same notebook you see.

Install

1. Install Jupyter Agentic Bridge from the VS Code Marketplace or Open VSX:

   marketplace.visualstudio.com/items?itemName=alendit.jupyter-agent-bridge

   open-vsx.org/extension/alendit/jupyter-agent-bridge

   You can also search for alendit.jupyter-agent-bridge in VS Code or an Open VSX-compatible extension gallery.

2. Open a .ipynb notebook in your editor.

3. Run Jupyter Agentic Bridge: Create MCP Config.

4. Choose the host you want to connect:

   • Claude Code
   • Codex
   • Copilot
   • Copy to Clipboard
   • Cursor

5. Restart or reload the selected host so it picks up the generated MCP config.

If the bridge is not already running, run Jupyter Agentic Bridge: Start Bridge.

Features

• Live notebook access through MCP tools against the notebook already open in the editor.
• Stale-safe notebook editing with source fingerprints, diff previews, and live reveal support.
• Blocking and async execution flows with kernel status, interruption, restart, and readiness checks.
• Agent-readable output transfer for text, errors, images, and Plotly figures when the notebook emits static snapshots.
• Optional MCP extras including resources, reusable prompts, and app-style review and preview surfaces.

Usage

The normal workflow is incremental. Let the agent discover the notebook, narrow the target area, edit only the cells it needs, execute the right code cells, and then inspect the outputs or kernel state.

A typical flow looks like this:

1. list_open_notebooks
2. get_notebook_editor_state when the request refers to the user's current focus, selection, or viewport
3. get_notebook_outline or list_notebook_cells
4. search_notebook, find_symbols, or read_notebook on a small range
5. patch_cell_source, replace_cell_source, insert_cell, or move_cell
6. execute_cells for short blocking work, or execute_cells_async followed by get_execution_status or wait_for_execution for long-running work
7. read_cell_outputs, get_diagnostics, get_execution_status, or summarize_notebook_state

Use list_notebook_cells for lightweight navigation previews and fingerprints. Use read_notebook with cell_ids or range when you need full source for editing, review, or patch planning; prefer that over raw .ipynb reads for notebook cell contents.

If your agent uses repository instructions, add a short hint in AGENTS.md so it prefers the notebook tools over raw .ipynb edits. For example:

For notebook work, prefer the jupyter-agent-bridge MCP tools before reading or editing raw .ipynb files.

Advanced Usage

Profiles

• core is the default profile. It includes the full notebook tool catalog for discovery, editing, execution, navigation, kernel control, and workflows.
• full adds MCP-only extras such as read-only resources and MCP Apps companion views. Set JUPYTER_AGENT_BRIDGE_PROFILE=full only when you want those extras.

Discovery And Navigation

Use these tools to orient the agent without pulling the whole notebook into context:

• list_open_notebooks
• open_notebook
• get_notebook_editor_state
• get_notebook_outline
• list_notebook_cells
• search_notebook
• find_symbols
• go_to_definition
• reveal_notebook_cells
• set_notebook_cell_input_visibility

Use get_notebook_editor_state before acting on phrases like "this cell", "the selected cells", "what I'm looking at", or "continue from here". It reports the active notebook URI, active cell, selected cell ranges, visible cell ranges, source selection when available, and source fingerprints for targeted stale-safe follow-up actions.

Editing And Review

Use these tools for live notebook edits:

• insert_cell
• replace_cell_source
• patch_cell_source
• format_cell
• move_cell
• delete_cell

Source inputs follow normal JSON string semantics and are stored verbatim after decoding. That means:

• use actual newline characters for multiline cell content
• use \\n only when you want a literal backslash followed by n
• replace_cell_source, patch_cell_source, and preview_cell_edit return source fingerprints plus a canonical source preview so callers can verify what the bridge interpreted

For safer edits and human review:

• preview_cell_edit returns a non-mutating diff preview
• open_cell_edit_review opens an MCP Apps review surface in capable hosts
• open_cell_code_preview opens a code-first cell preview with notebook navigation actions

Most edit requests can carry notebook-version and source-fingerprint guards for stale-safe mutation flows.

Edit and execution tools also accept an optional reveal_cell boolean. It defaults to true and scrolls the affected cell into view so the user can follow along. Pass false to suppress that automatic reveal. For explicit viewport positioning or output focus, use reveal_notebook_cells.

Execution, Kernel Control, And Outputs

For execution:

• execute_cells
• execute_cells_async
• get_execution_status
• wait_for_execution
• run_notebook_workflow

Use execute_cells when you want the tool call itself to block until execution finishes or times out. Use execute_cells_async when work may take a while or when the agent should keep doing other tasks while the kernel runs.

wait_for_execution.timeout_ms only limits how long the MCP call waits for a newer execution snapshot. It does not cancel the kernel execution. Use interrupt_execution when you need to stop the underlying run.

For kernel state:

• get_kernel_info
• wait_for_kernel_ready
• interrupt_execution
• restart_kernel
• select_kernel
• select_jupyter_interpreter

For outputs and result inspection:

• read_cell_outputs
• open_cell_output_preview
• export_cell_output_snapshot
• list_variables
• summarize_notebook_state

When notebook or output payloads are too large for prompt context, use output_file_path on read_notebook or read_cell_outputs.

For Plotly figures in VS Code notebooks, prefer import plotly.io; plotly.io.renderers.default = "vscode+png" (equivalently plotly_mimetype+png) and install kaleido in the notebook environment if Plotly needs static image rendering support. That lets the notebook emit an image/png snapshot the MCP can return in an agent-readable format. When the Plotly vendor bundle already embeds an image representation such as image/png or image/svg+xml, read_cell_outputs now surfaces that representation as a normal image output as well. Text and structured JSON results keep an image index placeholder instead of duplicating the raw base64 bytes.

Optional MCP Extras

When the host supports them, the MCP frontend also exposes:

• read-only MCP resources for passive notebook discovery
• typed structuredContent and outputSchema
• reusable prompts such as triage_notebook, safe_edit_cell, execute_and_inspect, and recover_kernel
• MCP Apps companion views for session selection, notebook triage, cell review, async execution monitoring, and output preview

These are additive helpers. The MCP tool surface remains the primary interface.

Notes

Jupyter Agentic Bridge: Create MCP Config writes machine-local config files such as:

• .mcp.json
• .codex/config.toml
• .vscode/mcp.json
• .cursor/mcp.json

The extension also writes the workspace-local bridge port file at .jupyter-agent-bridge/bridge/port.

These files are local operational state. Keep them untracked and regenerate them per machine.

Development

Release And Publishing

For release cuts, the repo helper now accepts either an explicit semver or a bump keyword:

• npm run cut-release -- patch
• npm run cut-release -- minor --push github
• npm run cut-release -- 0.4.0

When you pass major, minor, or patch, the script reads the current package.json version, computes the next semver for that part, and then runs npm version with the resolved target.

Pushing a v* tag to GitHub runs the release workflow. The workflow builds and tests once, packages one VSIX artifact, then publishes that same artifact in parallel to:

• Open VSX with the OVSX_PAT GitHub Actions secret
• VS Code Marketplace with the VSCE_PAT GitHub Actions secret

Create VSCE_PAT from an Azure DevOps personal access token whose organization is All accessible organizations and whose custom scope includes Marketplace: Manage.

Architecture

For architecture, runtime topology, and lower-level bridge details, read docs/ARCHITECTURE.md.
