BlocklyPy Commander for LEGO Robots

A powerful Visual Studio Code extension designed to supercharge your development with LEGO® Hubs, supporting both Pybricks and official HubOS v3 firmware. Seamlessly connect, program, debug, and analyze your LEGO robotics projects directly from your favorite editor.

✨ Key Features

🔌 Hub Connectivity & Control

• Universal Connection: Connect to your LEGO Hubs (Pybricks, HubOS v3) effortlessly via Bluetooth or USB.
• Program Lifecycle Management: Start and stop programs on your connected hub directly from VS Code.
• Advanced Slot Management (HubOS):
  • Clear Slots: Erase individual program slots or wipe all slots clean.
  • Move Slots: Reorganize your stored programs with ease.
• Interactive REPL (Pybricks): Engage in live coding with a Read-Eval-Print Loop session for immediate feedback.
• Real-time Hub Monitoring: Get live insights into device activity and performance, invaluable for diagnostics and optimization.
• Smart Connection Features:
  • Auto-Connect: Automatically reconnects to your last-used hub upon startup.
  • Stop Scanning on Window Blur: A configurable setting to conserve resources by pausing Bluetooth scans when VS Code is not in focus.

🚀 Code Development & Deployment

• Effortless Compile & Run: Write your Python scripts, then compile and upload them to your hub with a single command, followed by automatic execution.
• Integrated Debugging: Unlock the power of VS Code's debugger for your Pybricks projects. Set breakpoints, step through code, and inspect variables to understand and fix issues faster.
• MicroPython Notebook Support: Run and manage .ipynb cells directly on your connected device, enabling interactive data exploration and code execution.
• Rapid Project Creation with Templates:
  • Intelligent Snippets: Quickly insert common Pybricks code structures using snippets like pybricks, primehub, inventorhub.
  • Command Palette Integration: Use "Insert Pybricks Template" to add boilerplate code to your current file or "New Pybricks Python File" to create a fresh, templated file.
  • Templates come pre-configured with essential imports and auto-detected device configurations.
• Seamless Auto-Start: Include a magic header comment (e.g., # LEGO autostart) in your Python files to automatically upload and run your script on the hub every time you save.

📊 Monitoring & Diagnostics

• Real-time Datalogging & Plotting: Visualize live sensor data and program outputs from your hub.
  • Dynamic Charts: Plot data in real-time by parsing special plot: commands from your device's standard output.
  • CSV Export: Automatically save incoming sensor data to a .csv file for later analysis.
• Granular Device Notification Filtering: Filter and plot specific device notifications, offering deep insights for advanced debugging and analysis.
• Comprehensive Error Reporting: See detailed compilation and runtime errors directly in VS Code, allowing for quick identification and resolution.
• Program Status & Output Console: Receive real-time updates on program status and view all messages outputted by your hub in a dedicated console.

📂 File Format Support & Analysis

This extension is a versatile tool for opening, displaying, analyzing, and converting major LEGO robotics file formats, simplifying project onboarding, backup, and code inspection.

• Extensive Platform & File Type Support:
  • SPIKE Prime / Essentials / Robot Inventor:
    • SPIKE v2 (.llsp) and v3 (.llsp3) for both word-blocks and icon-blocks.
    • Robot Inventor (.lms).
  • EV3 Mindstorms:
    • EV3 Classroom (.lmsp), EV3 Lab (.ev3), EV3 iPad (.ev3m).
    • EV3 Lab Compiled Binary (.rbf).
  • WeDo 2.0:
    • LEGO WeDo 2.0 project files (.proj).
  • Pybricks:
    • Pybricks Python (.py), with robust multi-file support.
• Powerful Analysis Tools for LEGO Files:
  • Pseudocode Representation: Transform complex block programs into easy-to-read text-based pseudocode.
  • Graphical Preview: Get an instant visual overview of your block-based code.
  • Module Dependency Visualization: Understand your code's structure and interdependencies with an intuitive graph.
  • Python Code Conversion: (Experimental) Convert block code directly into compatible Pybricks Python code.
• Direct Code Views:
  • Show Python Code: View the underlying Python code generated from .llsp3 files.
  • Show Python Preview: Render dependency visualization for any Python file in a dedicated, side-by-side view.

🤝 Convenience & Help

• Configurable Settings: Easily toggle extension settings and experimental feature flags to customize your workflow.
• Contextual Help Portal: Access the official Pybricks Help Portal directly. The extension intelligently navigates to relevant documentation based on your currently selected Python type or keyword.

🚀 Getting Started

1. Install the "BlocklyPy Commander" extension from the VS Code Marketplace.
2. Connect your LEGO Hub: Simply activate the extension and follow prompts to connect via Bluetooth (or USB if supported).
3. Create Your First Project:
   • Open the VS Code Command Palette (Ctrl+Shift+P).
   • Search for "New Pybricks Python File" and select your specific hub type to generate a new, templated Python script.
   • Alternatively, open any Python file and type pybricks (or primehub, inventorhub, etc.) to use a template snippet.
4. Run Your Code: Press F5 or use the dedicated Run button in the VS Code interface to deploy and execute your program on the connected hub.

📦 Pybricks Pip Package

The extension can optionally help you install or upgrade the pybricks pip package in your currently selected Python environment.

• Automatic Prompt: The first time you open the Pybricks Help Portal (Open Pybricks Help Portal command), the extension checks whether the pybricks package can be imported. If it is missing, you will be prompted to install it. If it is present, you may choose to upgrade.
• Manual Install/Upgrade: Use the Install Pybricks Pip Package command at any time from the Command Palette or the Commands tree view.
• One-Time Behavior: After the prompt is shown once (or if the package is already installed), it will not appear again unless you manually invoke the install command.

Tip: Ensure the correct Python interpreter is selected (status bar or VS Code Python: Select Interpreter) before installing so that the pybricks package ends up in the environment you use for development.

🌟 Guide: Fun First Things to Explore

• Connect to a SPIKE Prime/Essential/Robot Inventor hub running Pybricks or HubOS.
• Experiment with the auto-connect feature for seamless workflow.
• Compile and upload both Pybricks Python files and standard LEGO Python files.
• Try the auto-start feature using the # LEGO autostart header.
• Monitor runtime errors and print statements from the hub in real-time.
• Utilize local Python modules by importing them within your main script.
• Visualize code structure with the dependency graph for complex projects.
• Explore blockly previews for SPIKE Hub v2/v3 files.
• Examine pseudocode for a simplified representation of block programs.
• Convert and run Pybricks Python code generated from block programs.
• Observe instant updates when modifying SPIKE source files in the LEGO app.
• Open and analyze files from various platforms: Robot Inventor, SPIKE Essential, EV3 (Classroom, Lab, iPad), and WeDo 2.0.
• Download and inspect compiled .rbf binaries from EV3 hubs.
• Experiment with datalogging and real-time charts to visualize sensor data.

🤖 Auto Start

When a device is connected, your script can be configured to start automatically by adding a special header comment at the top of your Python file. This enables a seamless workflow—just save your file, and it will be uploaded and run on the hub automatically.

Example for Pybricks Hubs:

# LEGO autostart

from pybricks.hubs import PrimeHub
hub = PrimeHub()
hub.speaker.beep()

Example for LEGO HubOS devices (specifying a slot):

# LEGO slot:0 autostart

print('autostarted')

📈 Data Logging & Plotting

The extension features a powerful datalogging view capable of plotting incoming data in real-time. This is achieved by parsing special "plot:" commands from the standard output of the connected device.

To utilize this feature:

1. Ensure your device is connected and executing code that outputs data in the expected plot: format.
2. Run a program that includes these plotting commands.
3. The datalogging view will automatically update, displaying your data as it arrives.
4. Activate the "Auto-Save Plot Data" setting to automatically save all incoming sensor data to a .csv file.

Plotting Commands Reference:

• plot: start col1,col2,... - Initializes a new plot with the specified column names.
• plot: col1: value1, col2: value2, ... - Adds a new data point, explicitly setting values for named columns. Missing values can be omitted.
• plot: value1,value2,... - Adds a new data point with values provided in the order of the columns defined by plot: start. Empty entries (e.g., 10,,30) represent missing values.
• plot: end - Terminates the current plotting session.

Plotting Columns Definitions:

To define a plotting column, use the format:

column_name [axis:<type>] [range:min..max]

• column_name: The label for your data column (e.g., yaw, pitch, roll).
• axis:<type>: (Optional) Specify the axis name, any series sharing an axis will have a common scale.
  If a single axis series uses x, it will replace the default server-side timestamp x-scale.
  If a single axis series uses x[time], it will replace the default server-side timestamp x-scale using a second-based time-axis.
• range:min..max: (Optional) Define the expected value range.

Example:

time axis:x[time], gyro range:0..100 axis:yaw, pitch axis:pitchroll, roll axis:pitchroll

This defines:

• time as the x-axis (time),
• gyro as an orientation axis with values from 0 to 100,
• pitch and roll as additional orientation axes.

How it Works:

• The extension continuously monitors lines beginning with "plot:".
• The "start" command defines plot columns and initializes a data buffer.
• Subsequent data lines are processed, filling in column values and managing missing data points.
• Complete data rows are then sent to the webview for real-time visualization.
• Incomplete rows are buffered and flushed upon completion or a timeout.

Example Pybricks Script with Plotting:

from pybricks.hubs import PrimeHub
from pybricks.tools import wait
hub = PrimeHub()

print("plot: start gyro")
while True:
    print(f"plot: {hub.imu.heading()}")
    wait(100)
print("plot: end") # This line will never be reached in this example, demonstrating continuous plotting

🐞 Debug Code

The extension provides experimental support for launching VS Code debug sessions with a Pybricks hub connected. This feature significantly aids in identifying and resolving issues within your robotics code.

Important Usage Notes:

1. Set Breakpoints: Place breakpoints in your Python code before starting the debug session.
2. Launch Debug Session: Initiate the debug session from VS Code.
3. Step & Continue: Once the debugger hits a breakpoint, you can step through your code line by line, inspect variables, and continue execution to the next breakpoint.

Disclaimer: This is an early preview feature. While generally stable, minor issues might occur. The code is only paused at explicitly set breakpoints.

🏗️ Pybricks Templates

Jumpstart your projects with pre-configured templates tailored for different LEGO hubs. These templates include common imports, hub initialization code, and even auto-detect connected devices.

Ways to Use Templates:

• Snippets: Type pybricks, primehub, inventorhub, etc., directly in your Python file to insert relevant boilerplate.
• Command Palette: Use the "Insert Pybricks Template" command to add a template to your current file.
• New File Creation: Use the "New Pybricks Python File" command to create a brand new file pre-populated with a chosen template.

Supported Hubs: SPIKE Prime, SPIKE Essential, MINDSTORMS Robot Inventor, City Hub, Technic Hub.

⚠️ Limitations

• Only custom modules located in the same folder as the main script are currently supported.
• Complex package structures and relative imports are not yet supported.
• Runtime error locations might occasionally be inaccurate, especially after rapidly switching tabs or modifying files.

🙏 Acknowledgements

This project builds upon the foundational work of Song-Pei Du (dusongpei) and the pioneering efforts of the Pybricks authors, Laurens Valk and David Lechner.

Special thanks to the LEGO® group for their comprehensive HubOS documentation.

📄 License

This project is licensed under the MIT License.

📸 Screenshots

Below are a selection of screenshots demonstrating the extension's key features:

• Overview of Features:
• Connecting to a Device:
• Interactive REPL Session:
• Debugging a Program:
• Inserting a Template via Snippet:
• Inserting a Template via Command Palette:
• Real-time Datalogging Plot:
• Error Reporting:
• Pseudocode Preview:
• BlocklyPy to Python Conversion:
• Python Code Preview:
• Autodetect Templates:
