Azure DevOps Markdown PR Review

⚠️ Unofficial community extension. Not affiliated with, endorsed by, or supported by Microsoft, the Azure DevOps team, GitHub, or any SCM vendor. Issues and feature requests should be filed against this repository, not Microsoft or GitHub support.

A Visual Studio Code extension that lets you review markdown design and architecture documents in pull requests using a fully rendered markdown view — and create PR comment threads by selecting text directly in the rendered content.

Closes the regression introduced when teams migrated from Word-based design-doc review to PR-based review of markdown in source control, where SCM tools only support commenting on raw markdown lines.

---

Why this exists

When a .docx design doc was reviewed by passing the file around, reviewers used Word's review track to comment on rendered prose, see diagrams as diagrams, and call out specific phrases in context.

The same design doc, written in markdown and reviewed via a pull request, forces the reviewer onto a raw-markdown diff view: formatting is erased, mermaid diagrams are walls of source, and selecting "the second paragraph of section 3" means scrolling lines of syntax. This extension restores the rendered-document review workflow for a single reviewer — markdown is rendered, mermaid is rendered, text selection works as you expect, and posting a comment creates a real PR thread.

---

Supported source-control providers

Provider	Status	Notes
Azure DevOps	✅ Supported	PR URL form https://dev.azure.com/{org}/{project}/_git/{repo}/pullrequest/{n}
GitHub	🛣️ Planned	Tracked in [issue #18](https://github.com/abeltrano/markdown-pr-review/issues/18)
GitLab	❌ Not planned	File an issue if you need it
Bitbucket	❌ Not planned	File an issue if you need it

---

Telemetry

This extension collects no telemetry. It does not call out to any analytics service, does not emit usage events, and does not include the @vscode/extension-telemetry package. The only outbound network traffic is direct REST calls to the SCM provider whose PR you have opened (Azure DevOps today). If this policy ever changes it will be flagged prominently in the release notes and you will be able to opt out via telemetry.telemetryLevel per the VS Code telemetry contract.

---

Install

From the Visual Studio Marketplace (recommended once published)

1. Open the Extensions sidebar in VS Code (Ctrl+Shift+X).
2. Search for Markdown PR Review.
3. Click Install.

Or from the command line:

code --install-extension abeltrano.md-pr-review

Sideload a .vsix (fallback / pre-release builds)

1. Download the latest md-pr-review-*.vsix from the Releases page (or build one locally — see Development).
2. In VS Code: Extensions sidebar → ... menu → Install from VSIX… → pick the file.
3. Reload VS Code if prompted.

Or from the command line:

code --install-extension .\md-pr-review-*.vsix

---

Quick start

1. Sign in. On first use you will be prompted to sign in via the Microsoft account provider (the same one VS Code uses for Azure / Microsoft sign-in). If MSAL is unavailable you can supply a Personal Access Token — see Required Azure DevOps PAT scopes.
2. Open a PR. Press Ctrl+Shift+P → run Markdown PR Review: Open Pull Request…. Paste the PR URL, for example https://dev.azure.com/contoso/MyProject/_git/MyRepo/pullrequest/12345.
3. Pick a markdown file. The Markdown PR Review activity-bar view lists all .md / .markdown / .mdx files in the PR. Click one to open it in the rendered viewer.
4. Comment on text. Select any text in the rendered view; the Comment Input panel populates with a quoted preview. Type and press Post. The thread appears in the rendered view immediately and on the PR web page as a real thread.
5. Read existing threads. Every thread already on the PR shows up as a clickable marker beside the line it was anchored to.

That's the whole loop. See Commands and keybindings for shortcuts once you've done it a few times.

---

Required Azure DevOps PAT scopes

If you fall back to PAT auth (most users won't need to — interactive Microsoft sign-in is preferred), generate the token at User settings → Personal access tokens in Azure DevOps and grant the minimum scopes:

Scope	Why
Code → Read	Listing PR files and reading their content.
Pull Request Threads → Read & write	Reading existing comment threads and posting new ones.

No other scopes are required. Use a short expiry (30–90 days) and scope the PAT to the specific organization you review in. The token is stored in VS Code's SecretStorage (OS-level keychain), never in settings or workspace state.

---

Commands and keybindings

Command	Default key	Notes
Markdown PR Review: Open Pull Request…	—	Accepts a full PR URL or a bare PR number (see settings below).
Markdown PR Review: Refresh Threads	Ctrl+Alt+R	Re-fetches threads on the active PR.
Markdown PR Review: Add Comment to Selection	Ctrl+Alt+C	Focuses the comment input sidebar for the current selection.
Markdown PR Review: Refresh to Head Commit	F5	Re-opens the PR at the latest head commit.
Markdown PR Review: Close Session	—	Clears the active PR session.

Keybindings only fire when the rendered editor is focused (activeCustomEditorId == 'markdownPrReview.renderedView').

---

Settings

All settings live under Markdown PR Review in VS Code Settings.

Setting	Default	Description
markdownPrReview.defaultOrganization	""	Default ADO organization. Set with defaultProject to allow bare-PR-id input.
markdownPrReview.defaultProject	""	Default ADO project. Must accompany defaultOrganization.
markdownPrReview.staleCommitPollSeconds	30	How often to poll for new commits on the active PR. Range 15–60.

---

What is rendered

• CommonMark (paragraphs, headings, lists, blockquotes, tables, fences) per markdown-it defaults.
• Mermaid diagrams — fenced as ```mermaid ``` are rendered to SVG client-side. Selection within the SVG is not supported for comment anchoring (you can still anchor a comment to the diagram block as a whole).
• Code fences with the language hint shown.
• Raw HTML is escaped (rendered as text). This is intentional for v0.4 — a sanitizer pass is a future enhancement.

Comments themselves are rendered as plain text in the popover to keep the webview bundle small.

---

Known limitations (v0.4)

These are documented in docs/requirements.md §2.2 as out of scope:

• Multi-PR: only one PR session is active at a time. Opening a new PR closes the previous session.
• Editing/deleting comments: post-only. Edit or resolve threads in the SCM provider's web UI.
• Reply to a specific comment: posting always creates a new thread anchored to the selection.
• Right-side panel of resolved threads: only active threads show markers; resolved threads must be reviewed in the SCM web UI.
• GitHub / Bitbucket / GitLab: Azure DevOps only today. GitHub support is tracked in [issue #18](https://github.com/abeltrano/markdown-pr-review/issues/18).
• Side-by-side base/head view: the rendered view always shows the head version with diff gutter bars indicating change state.
• Comment markdown rendering inside popovers: comments display as plain text (whitespace preserved) for now.
• HTML passthrough: raw HTML blocks are escaped.

---

Troubleshooting

Where is the log?

Open the Output panel (View → Output), then pick ADO Markdown PR Reviewer from the dropdown. Every REST call, every selection mapping, and every error is recorded here with a timestamp and a component tag. Errors include a stable code (E_ADO_AUTH, E_ADO_PERM, etc.) so you can grep the log.

When a user-facing error appears, the Open Output button on the notification jumps straight to this channel.

"Azure DevOps rejected your credentials" (E_ADO_AUTH)

Sign in via the Microsoft account provider was successful but the returned token does not authorize the requested ADO resource. On the next REST call you will be re-prompted exactly once. If the second attempt also fails, the extension falls back to offering a Personal Access Token via Secret Storage.

"Your account does not have permission" (E_ADO_PERM)

403 from ADO. Check that you have Read on the repository and Contribute to pull requests for posting comments.

"Azure DevOps returned 404" (E_ADO_NOT_FOUND)

Most often a typo in the PR URL or a project/repo you cannot see. The Open Output action shows the exact URL that returned 404.

Mermaid diagrams render as source

Check that the fence info string is exactly mermaid (lowercase, no extra characters). If rendering still fails, the log records the mermaid error message.

Stale PR notification keeps appearing

The default 30 s poll interval will detect new commits within that window. Increase markdownPrReview.staleCommitPollSeconds if you find it intrusive, or use the Close Session command to stop polling.

---

Capability matrix by version

Capability	v0.1	v0.2	v0.3	v0.4
Open ADO PR by URL	✅	✅	✅	✅
Rendered markdown view	✅	✅	✅	✅
Mermaid diagram rendering	✅	✅	✅	✅
Select-to-comment round-trip	✅	✅	✅	✅
Existing thread markers + inline popover	—	✅	✅	✅
Multi-file picker with directory grouping	—	✅	✅	✅
Diff gutter bars (added / modified / deleted)	—	—	✅	✅
Status bar with PR + thread count	—	—	—	✅
Stale-commit watcher (auto-detect new head)	—	—	—	✅
401 silent retry	—	—	—	✅
User-facing error codes + Open Output action	—	—	—	✅

---

Repository layout

.
├── package.json                  # Extension manifest
├── tsconfig.json                 # TypeScript strict mode
├── esbuild.js                    # Bundler config (host + 2 webviews)
├── .mocharc.cjs                  # Test config (mocha + tsx)
├── docs/
│   ├── requirements.md           # REQ-IDs (source of truth)
│   ├── design.md                 # Architecture, components, contracts
│   └── validation-plan.md        # Test cases TC-001…TC-165
├── src/                          # Extension host code
└── test/unit/                    # Mocha unit tests (90 currently)

---

Development

npm install
npm run compile     # tsc --noEmit && esbuild (dev)
npm run watch       # esbuild rebuilds on save
npm test            # mocha against test/unit/**/*.test.ts
npm run build       # tsc + production esbuild
npm run package     # build + vsce package

Press F5 in VS Code (with the Run Extension launch config) to debug in a fresh VS Code window.

---

License

MIT. See LICENSE.

---
