Embeds the local DeepSeek Harness (DSH) web UI in the VS Code auxiliary sidebar (right rail, alongside Copilot Chat). By default, every VS Code window starts and owns one dsh web child with the current workspace as cwd, then renders it in a compact full-screen iframe.
Requirements
| Item |
Requirement |
| VS Code |
≥ 1.90, desktop only |
| DSH CLI |
globally installed dsh |
| DSH profile |
configured; dsh web starts |
Install
- Dev: open this repo →
F5 → Run Extension
- Package:
npm i -g @vscode/vsce && vsce package --no-dependencies → code --install-extension dsh-vs-sidebar-0.3.1.vsix
Usage
Ctrl+Alt+B opens the auxiliary sidebar → DeepSeek Harness (DSH) tab- Commands: Open DSH in Browser · Restart DSH Server · Stop DSH Server · Focus DSH Sidebar
- With
dsh.autoStart on, the server is started at VS Code startup even if the sidebar is never opened
Configuration
| Key |
Default |
Description |
dsh.port |
3080 |
Port to probe/start the DSH web server on |
dsh.host |
127.0.0.1 |
Fixed loopback bind required by the current DSH Web profile |
dsh.autoStart |
true |
Start one DSH child for this VS Code window (false = reuse only the configured user-managed endpoint); also starts at VS Code startup |
dsh.closePolicy |
onVscodeExit |
When to stop the extension-owned server (see below) |
dsh.closePolicy values:
| Value |
Behavior |
onVscodeExit |
Stop the owned server only when VS Code exits (default) |
onViewClose |
Also stop the owned server when the sidebar view is closed |
never |
Never stop automatically — use the Stop DSH Server command |
A reused (non-owned) instance is never stopped by any policy or command.
Compatibility
- VS Code ≥ 1.90 (
secondarySidebar); explicit activationEvents; extensionKind: [workspace]
- Windows / macOS / Linux
- Each managed DSH child receives an authenticated loopback bridge URL/token; supported DSH builds POST configuration paths back to the owning extension host, which opens them through
vscode.window.showTextDocument in that exact window. DSH_TEXT_EDITOR=vscode remains only as an older-DSH CLI fallback; reused external servers keep their own editor policy
- The iframe receives
dsh_embed=vscode, which supported DSH builds use to hide their internal sidebar, details column, and resize handles; Open in Browser keeps the normal full layout
- PATH fallback when VS Code is GUI-launched with a trimmed PATH:
%APPDATA%\npm (Windows); existing npm-global bins (POSIX)
- Cleanup:
taskkill /T /F tree-kill (Windows — force-terminated, not a graceful stop); detached spawn + kill(-pid) process-group SIGTERM (POSIX)
- Untrusted / virtual workspaces unsupported (spawns local processes, touches workspace files) — declared via
capabilities
- Container/view IDs
dsh-sidebar / dsh.webview are persistent contracts — never change them in a release (resets the user's sidebar layout)
- UI language follows VS Code (zh/en): manifest via
package.nls.*.json, runtime via vscode.l10n (l10n/bundle.l10n.*.json)
- CI:
node src/serverManager.js self-test on ubuntu / macos / windows
Implementation
| File |
Responsibility |
src/extension.js |
activation, view provider, commands, workspace/config tracking, close policy |
src/serverManager.js |
probe / reuse / start / registry / cleanup |
src/webviewHtml.js |
iframe + status pages |
src/types.js |
contract constants (port, boot marker, view ID) |
Key behaviors:
- Probe
GET / for the __DSH_BOOT__ marker (3s timeout, 3 retries — a busy DSH is never misjudged as absent)
- Default
autoStart mode never adopts another window's process: occupied ports are scanned forward (up to 50) and each extension host owns its child; dsh-instances.json is retained only for stale-entry cleanup and diagnostics
- cwd = current workspace (multi-root: active editor's folder; none: inherit parent cwd, no home fallback)
- Remote (WSL / Remote-SSH):
vscode.env.asExternalUri port forwarding
- Browser commands use the same externalized URL as the iframe, including remote sessions and connection-error fallback pages
- Only the iframe URL gains the
dsh_embed=vscode compact-layout marker; browser URLs remain unmodified
- Workspace switch: stop only the owned instance for the old root, re-probe for the new one
onStartupFinished activation: with dsh.autoStart on, the server starts at VS Code startup (null-safe when no webview is open)- With the default
onVscodeExit policy, extension deactivation cancels pending startup, waits for the serialized lifecycle queue, and tree-kills any child that appeared; closing one VS Code window does not affect another window's child
- Lifecycle transitions (connect / stop / workspace rebind / config reconcile) run through one serialized queue, so a dispose arriving during connect cannot kill a process a rebind just started
dsh.stopServer and the close policy stop only owned processes; a reused external instance is never killed- Registry pruning only removes dead entries and never kills a live process;
onVscodeExit stops an owned child during extension-host shutdown, while never intentionally lets it survive until explicitly stopped
FAQ
- "DeepSeek official API" key is read-only in DSH settings?
DSH deliberately treats
DEEPSEEK_API_KEY supplied by the launching environment as read-only (writes would be silently shadowed). Fix: unset it in the shell that starts dsh web (or VS Code) and restart — the key already stored in ~/.dsh/.credentials.yaml takes over and the field becomes editable.
License
MIT © Xizhi1024
| |
