XRobot VS Code ExtensionXRobot 与 LibXR 的 VS Code 扩展 / VS Code extension for XRobot and LibXR |
| 视图 View | 适用的文件夹 | Folder | 内容来源 | Content from |
|---|---|---|---|---|
| XRobot | 包含 Modules/modules.yaml 的 BSP |
A BSP with Modules/modules.yaml |
xrobot describe、Modules/modules.yaml、Modules/sources.yaml |
xrobot describe, Modules/modules.yaml, Modules/sources.yaml |
| LibXR | 根目录有 *.ioc 文件的 STM32CubeMX 工程 |
An STM32CubeMX project with a *.ioc file at its root |
User/libxr_config.yaml、User/flash_map.hpp |
User/libxr_config.yaml, User/flash_map.hpp |
🧩 XRobot 视图 / XRobot View
XRobot 视图显示生成的主函数头文件 User/xrobot_main.hpp 是否过期、每个模块的 lock 状态、入口源文件中的
硬件注册和 xrobot describe 报告的诊断信息，并列出 User/ 下的全部配置、所选配置中的实例及其参数、
Modules/modules.yaml 中的模块和 Modules/sources.yaml 中的源。选择另一份配置时运行
xrobot gen -c <配置>。
The XRobot view shows whether the generated header User/xrobot_main.hpp is stale, the lock state
of each Module, the registrations in the entry source and the diagnostics xrobot describe
reports. It lists every configuration under User/, the instances of the selected configuration
with their parameters, the Modules in Modules/modules.yaml and the sources in
Modules/sources.yaml. Selecting another configuration runs xrobot gen -c <configuration>.
实例和模块的每项修改对应一条 xrobot 命令。例如将 blink_led 的 blink_cycle 改为 500 时，扩展先修改
配置，再重新生成头文件：
Each change to an instance or a Module is one xrobot command. Changing blink_cycle of
blink_led to 500, for example, edits the configuration and then regenerates the header:
$ xrobot -C <BSP> instance -c User/xrobot.yaml set --json blink_led args.blink_cycle '"500"' --if-match <sha256>
$ xrobot -C <BSP> gen -c User/xrobot.yaml
Generated User/xrobot_main.hpp for User/xrobot.yaml
--if-match 是视图读取配置时文件内容的哈希。若文件在此之后被修改，命令保留文件原样并报告：
--if-match is the hash of the configuration as the view read it. If the file has changed since,
the command leaves it as it is and reports:
User/xrobot.yaml changed since it was read; reload and retry
| 操作 Action | 命令 Command |
|---|---|
| 添加 / 删除实例 Add / remove an instance | xrobot instance add MODULE [--id ID] / xrobot instance remove ID |
| 修改参数值 Change a value | xrobot instance set --json ID PATH VALUE --if-match <sha256> |
| 切换构造函数 Switch the constructor | xrobot instance set --json ID args LIST --if-match <sha256> |
| 重命名实例 Rename an instance | xrobot instance rename ID NEW_ID |
| 添加 / 删除模块 Add / remove a Module | xrobot module add owner/Repo[@ref] / xrobot module remove owner/Repo |
| 添加源 Add a source | xrobot source add-source URL --priority N |
| 新建模块 Create a Module | xrobot new-module |
| 同步模块 Sync Modules | xrobot setup、xrobot setup --frozen、xrobot setup --update |
| 格式化配置 Format configurations | xrobot format、xrobot format --check |
修改源的 URL 或优先级、删除源时，扩展按 URL 修改 Modules/sources.yaml 中对应的条目并保留注释；
官方源只读。实例修改成功后，若所选配置没有错误，扩展运行 xrobot gen 重新生成头文件。
Changing a source's URL or priority and removing a source edit the entry with that URL in
Modules/sources.yaml, keeping comments; the official source is read-only. After an instance edit
succeeds and the selected configuration has no errors, the extension runs xrobot gen to
regenerate the header.
🛠 LibXR 视图 / LibXR View
LibXR 视图显示工程的平台和 User/libxr_config.yaml 中的各项设置。平台由工作区根目录识别：STM32CubeMX 的
.ioc 为 STM32，app.yaml 加 boards/*/*.hpmpc 为 HPM，SysConfig 的 .syscfg 为 MSPM0。STM32 工程还显示
User/flash_map.hpp 记录的 MCU 型号和内部 Flash 布局（按等大扇区段列出）。libxr_config.yaml 的值可以在视图中
直接修改，修改后重新生成代码。"Generate LibXR Code" 依次运行 libxr parse 和 libxr gen；还没有
libxr_config.yaml 时，操作是对应平台的 libxr stm32 setup、libxr mspm0 setup 或 libxr hpm setup。STM32 另有
libxr parse、libxr gen 和 libxr stm32 flash-info。MSPM0 工程的 "Open in SysConfig" 启动独立版 SysConfig 打开
.syscfg（需要 xrobot.libxr.sysconfigTool 和 xrobot.libxr.mspm0SdkDir，或同名环境变量 SYSCONFIG_TOOL、
MSPM0_SDK_INSTALL_DIR）；HPM 工程的 "Open in HPM Pinmux Tool" 用 HPMicro 的 HPM Pinmux Tool 扩展打开 .hpmpc，
没有安装该扩展时提示安装或使用网页版。
The LibXR view shows the project's platform and the settings in User/libxr_config.yaml. The platform is
recognized from the workspace root: an STM32CubeMX .ioc is STM32, an app.yaml with boards/*/*.hpmpc is HPM, and a
SysConfig .syscfg is MSPM0. An STM32 project also shows the MCU and internal Flash layout recorded in
User/flash_map.hpp, listed as runs of equal sectors. Values of libxr_config.yaml can be edited in the view, which
regenerates the code. Generate LibXR Code runs libxr parse and then libxr gen; while there is no libxr_config.yaml,
the action is the platform's libxr stm32 setup, libxr mspm0 setup or libxr hpm setup. STM32 also has libxr parse,
libxr gen and libxr stm32 flash-info. Open in SysConfig starts the standalone SysConfig on the .syscfg of an MSPM0
project (it needs xrobot.libxr.sysconfigTool and xrobot.libxr.mspm0SdkDir, or the environment variables
SYSCONFIG_TOOL and MSPM0_SDK_INSTALL_DIR); Open in HPM Pinmux Tool opens the .hpmpc of an HPM project with HPMicro's
HPM Pinmux Tool extension, and without that extension offers to install it or to use the web tool.
引脚布局 / Pin Layout
LibXR 视图自上而下是：芯片（型号、封装、引脚数，展开后有 "Pin Layout"、来源文件和系统）、"Peripherals"（工程在 .ioc、
.syscfg 或 .hpmpc 中已选的外设，按通信、定时器、模拟、存储、其他、GPIO、系统分组，GPIO 和系统
默认折叠）、Flash 布局、配置文件、操作。"Pin Layout" 打开芯片的封装图（libxr pins，需要带有该命令的 libxr）。每个外设显示
它的引脚，展开是它在 libxr_config.yaml 中的参数，可以直接修改（和 Config File 里一样，修改后重新生成代码）。点击一个
外设会打开封装图并选中它：它每个功能当前用的引脚和其他可选的引脚。
面板和侧栏联动：同一时间只选中一件事，要么一个引脚，要么一个外设。点封装图上的引脚，右侧显示这个引脚、项目里用作什么、 它还能是什么；点其中的外设名（或侧栏 Peripherals 里的一项），右侧改显示这个外设：设置，以及它每个功能的引脚，封装图上 当前用的引脚为实线、其他候选为虚线，点引脚名在封装图上定位。在面板里选中外设（或点一个已选的引脚），侧栏里对应的外设 也被选中。
封装图：滚轮以光标为中心缩放（窗口窄、图在检查器上方时，滚轮滚动页面，Ctrl+滚轮缩放），按住拖动平移，双击回到完整视图（像 CubeMX）。已选的引脚按外设类别着色，标签是引脚名加上所选功能（PA9 USART1.TX）或 GPIO 的标签（PC0 ACC_CS）；
左上角的圆点是 1 脚。搜索框按引脚名、信号或外设（如 usart1 tx）高亮匹配的引脚，图例可以按类别过滤。点击引脚
显示它能承载的外设功能（按类别折叠），点击其中的外设名选中该外设。图中列出所有识别出的外设，包括 LibXR 没有对应
抽象的（ETH、FMC、OctoSPI 等）。MSPM0 的封装取自 SysConfig 工程（.syscfg 的 --package，或其 --board 对应的 LaunchPad），不用设置；xrobot.libxr.package 只用来覆盖它。面板本身只读。MSPM0 外设在 SysConfig 工程 .syscfg 中的设置（波特率、中断等）和它在 libxr_config.yaml 中的设置
一起显示，前者只读，"Open in SysConfig" 启动独立版 SysConfig 修改它。
The LibXR view reads, top to bottom: the chip (part, package and pins; open it for Pin Layout, the source file and the
system), Peripherals (what the project selected in its .ioc, .syscfg or .hpmpc, by
category: communication, timers, analog, memory, other, GPIO, system, with GPIO and system closed), the Flash layout, the
config file and the actions. Pin Layout opens the package drawing of the chip (libxr pins, which needs a libxr release
that has the command). Each peripheral shows its pins; open it for its settings in libxr_config.yaml, which can be edited
there (as in the Config File, the code is regenerated). Clicking a peripheral opens the drawing with it selected: the pin each
of its functions uses and the other pins that can carry it.
The panel and the sidebar follow each other, and one thing is selected at a time: a pin or a peripheral. Click a pin on the drawing and the inspector shows the pin, what the project uses it as and what else it can be; click a peripheral name there (or an item of the Peripherals group in the sidebar) and the inspector shows the peripheral: its settings and the pins of each function, drawn solid for the pin in use and dashed for the other candidates; click a pin name to find it on the drawing. Selecting a peripheral in the panel (or clicking a pin the project uses) selects it in the sidebar too.
The window is the chip: the drawing fills it, with the name, package and pin count written on the chip. The controls float over it: Search (a button that opens the field), Functions, Legend and Details, and the zoom in the bottom-right corner. The inspector (Details) opens beside the drawing when something is selected, and closes with Clear. The wheel zooms around the pointer, a drag pans and a double click shows the whole package again, as in CubeMX. Search highlights matching pins; Enter goes to the next match, Shift+Enter to the previous, Escape closes it. The arrow keys walk along the package once a pin is selected, and Escape clears the selection.
In the drawing the selected pins are coloured by peripheral category and labelled with the pin name and the selected
function (PA9 USART1.TX) or the label of a GPIO (PC0 ACC_CS); the dot in the top-left corner marks pin 1. The search
field highlights the pins that match a pin name, signal or peripheral (such as usart1 tx), and the legend panel filters
by category. Clicking a pin shows the peripheral functions it can carry, folded by category; clicking a peripheral name selects
it. Every recognized peripheral is listed, including those LibXR has no abstraction for (ETH, FMC, OctoSPI, ...). The
package of an MSPM0 comes from its SysConfig project (the --package of the .syscfg, or the LaunchPad its --board names), so nothing is set; the xrobot.libxr.package setting only overrides it. The panel itself is read-only. The settings of an MSPM0 peripheral in the .syscfg of the SysConfig project (baud rate,
interrupts, ...) are shown read-only next to its settings in libxr_config.yaml; Open in SysConfig starts the standalone
SysConfig to change them.
🚀 命令一览 / Commands
以下命令可在命令面板中运行，也出现在视图的右键菜单和标题栏中。
These commands run from the Command Palette and also appear in the views' context menus and title bars.
| 命令 Command | 作用 Purpose |
|---|---|
| XRobot: Refresh All | 重新读取两个视图 / Reload both views |
| XRobot: Collapse All Views | 折叠两个视图 / Collapse both views |
| XRobot: Show Pin Layout | 打开封装图 / Open the package drawing |
| XRobot: Select Product (xrobot gen -c) | 选择配置并生成头文件 / Select a configuration and generate the header |
| XRobot: Add Module Instance | 添加实例 / Add an instance |
| XRobot: Edit Module Instance | 修改实例 / Edit an instance |
| XRobot: Delete Module Instance | 删除实例 / Delete an instance |
| XRobot: Create Module (xrobot new-module) | 新建模块 / Create a Module |
| XRobot: Add Module Request | 添加模块 / Add a Module |
| XRobot: Change Module Request Ref | 修改模块的 ref / Change a Module's ref |
| XRobot: Remove Module Request | 删除模块 / Remove a Module |
| XRobot: Add Source | 添加源 / Add a source |
| XRobot: Edit Source URL | 修改源的 URL / Change a source's URL |
| XRobot: Edit Source Priority | 修改源的优先级 / Change a source's priority |
| XRobot: Delete Source | 删除源 / Delete a source |
| XRobot: Pick LibXR Config Path | 选择 libxr_config.yaml / Pick libxr_config.yaml |
| XRobot: Pick LibXR App Main Path | 选择 app_main.cpp / Pick app_main.cpp |
⚙️ 设置 / Settings
| 设置 Setting | 作用 Purpose |
|---|---|
xrobot.cli.extraPath |
查找命令行工具时追加的目录（PATH 语法）/ Extra directories for finding the CLIs (PATH syntax) |
xrobot.cli.pythonPath |
找不到命令时用于运行对应 Python 模块的解释器 / Interpreter that runs the Python module when a command is not found |
xrobot.libxr.iocFile |
使用的 .ioc 文件，留空时取根目录下的第一个 / The .ioc file to use; empty takes the first one at the root |
xrobot.libxr.package |
覆盖引脚布局中的芯片封装，留空即可（MSPM0 取自 SysConfig 工程）/ Overrides the package of the chip in the pin layout; leave empty (an MSPM0 takes it from its SysConfig project) |
xrobot.libxr.configPath |
libxr_config.yaml 的路径 / Path of libxr_config.yaml |
xrobot.libxr.appMainPath |
app_main.cpp 的路径 / Path of app_main.cpp |
xrobot.libxr.sysconfigTool |
MSPM0 用的 SysConfig 命令行工具（SYSCONFIG_TOOL，sysconfig_cli.bat 或 sysconfig_cli.sh），留空时用环境变量 / The SysConfig command-line tool for MSPM0 (SYSCONFIG_TOOL, sysconfig_cli.bat or sysconfig_cli.sh); empty uses the environment variable |
xrobot.libxr.mspm0SdkDir |
MSPM0 SDK 目录（MSPM0_SDK_INSTALL_DIR），留空时用环境变量 / The MSPM0 SDK directory (MSPM0_SDK_INSTALL_DIR); empty uses the environment variable |
🧪 测试 / Tests
$ npm ci
$ npm run compile
$ npm test
48 passing (2s)
1 pending
npm test 运行单元测试，npm run test:vscode 在 VS Code 扩展宿主中运行测试，npm run package 打包
.vsix。CI 在 Linux 和 Windows 上编译、检查、测试并打包。
npm test runs the unit tests, npm run test:vscode runs the tests in the VS Code extension host,
and npm run package builds the .vsix. CI compiles, lints, tests and packages on Linux and
Windows.
