Viritura MNX Viewer

VS Code extension package for MNX preview support.

Install

Install from the Visual Studio Marketplace.

Current capabilities

• Registers .mnx files as mnx language.
• Opens .mnx files in the rendered MNX Viewer by default, with VS Code's Reopen Editor With... available for source text.
• Adds MNX: Open Preview command in editor title and explorer context menu.
• Opens a side preview panel that renders MNX through the Viritura WASM layout engine and Canvas painter.
• Refreshes the preview as the source document changes.
• Provides zoom, fit-to-width, and Ctrl+wheel zoom controls.
• Supports page, horizontal, spread, horizontal spread, and continuous Horizon arrangements.
• Offers page-size and staff-size controls for paged arrangements.
• Lets you select among multiple scores in an MNX document.
• Reports loading, parse, layout, and runtime errors inside the preview.
• Bundles the WASM engine and SMuFL/text fonts into the VSIX for local/offline use.

Local development

corepack pnpm --filter mnx-viewer build
corepack pnpm --filter mnx-viewer test

The webview stages fonts from assets/fonts and WASM from the canonical engine/viritura-wasm/pkg-browser producer. For an unpackaged local build, run:

corepack pnpm wasm:build
corepack pnpm --filter mnx-viewer prepare:assets

Build a VSIX for local install

corepack pnpm build:vsix

The preserved package alias corepack pnpm --filter mnx-viewer package invokes the same root coordinator. It builds WASM once, uses Turbo for the extension host/webview and prepared media outputs, then runs vsce as a consumer.

Then in VS Code use Extensions: Install from VSIX....
