DigitalJS Schematic Viewer for VSCode

A VSCode extension that synthesises your Verilog / SystemVerilog files and renders the full interactive circuit simulator directly inside a VSCode panel.

Synthesis can run either via the DigitalJS online API or fully offline using local WebAssembly (YoWASP + Yosys bundled in the extension).

Why this exists

The published DigitalJS VSCode extension bundles an old, frozen version of yosys2digitaljs that fails on many modern constructs. The online version at digitaljs.tilk.eu is actively maintained and handles these correctly.

This extension supports two synthesis backends:

Server-side API — POSTs to digitaljs.tilk.eu; stays up to date automatically.
Local WebAssembly — runs Yosys entirely inside a Node.js Worker thread via @yowasp/yosys; no internet required for synthesis.

In both cases, rendering and simulation run locally in the VSCode webview using the DigitalJS library loaded from jsDelivr CDN.

Features

Two-button workflow — Click the DigitalJS icon in the top right corner of the editor window to synthesise the active .v / .sv file immediately using default settings. Use the DigitalJS icon in the Activity Bar (or right-click → Open in DigitalJS) to open the Parameters sidebar first and tweak synthesis/simulation options before running.
Two synthesis modes — choose between Server Side (online) and WebAssembly (local, offline) in the Parameters sidebar.
Input Controls panel — a dedicated bar above the schematic for driving circuit inputs live during simulation:
- Single-bit inputs (rst, en, …) get compact toggle switches.
- Multi-bit inputs get an editable value box.
- Outputs get a status lamp.
- Clock signals get a [value][▲▼] stepper to adjust their period in ticks, plus the standard step buttons below for precise manual ticking.
- A synthesis status indicator (circular lamp + label) sits at the start of the bar, separated from the Input Controls label by a divider.
- The whole panel can be hidden/shown with the arrow next to the Input Controls label.
Full circuit simulation inside VSCode with Start / Pause / Step (1 / 10 / 100 / 1000 ticks) controls.
Live tick counter updates in real time while simulation runs.
Waveform monitor panel with per-signal traces, zoom (+/−), scroll (◀ ▶), Live mode, and a live range display.
Mouse-wheel zoom on the circuit diagram, centered on cursor.
Auto-fit on load — circuit scales to fill the available panel space (still a bit buggy).
Draggable resize handle between the circuit and waveform panels.
Singleton panel — re-running synthesis on a new file reloads the same panel, no duplicates.

Requirements

VSCode 1.60 or later
Internet connection required for Server Side synthesis mode
No internet required for WebAssembly synthesis mode (Yosys WASM is bundled in the extension)

Installation

From the `.vsix` file (Recommended)

Download .vsix file from the Releases page
In VSCode: Ctrl+Shift+P → Extensions: Install from VSIX… → select the file

Build from source

git clone https://github.com/VENOMNBB/DigitalJS-Schematic-Viewer.git
cd DigitalJS-Schematic-Viewer
npm install
npm install -g @vscode/vsce
vsce package
code --install-extension digitaljs-schematic-viewer-x.x.x.vsix

Usage

There are two ways to run synthesis:

Quick synthesis (defaults)

Open a .v or .sv file in the editor.
Click the DigitalJS icon in the top right corner of the editor window.
The file is synthesised immediately with default settings — no extra panel opens, your focus stays in the editor.

Synthesis with custom parameters

Open a .v or .sv file in the editor.
Click the DigitalJS icon in the Activity Bar (left-hand side), or right-click in the editor or Explorer → Open in DigitalJS, or Ctrl+Shift+P → DigitalJS: Open in DigitalJS.
This opens the Parameters sidebar without synthesising yet. Adjust synthesis/simulation options as needed.
Click Synthesize Circuit in the sidebar to run.

In both cases:

The synthesised circuit appears in a panel beside your editor, with the Input Controls bar populated for any top-level inputs/clocks in the design.
Use the toolbar to Start, Pause, or Step the simulation (1 / 10 / 100 / 1000 ticks at a time).
Drive inputs directly from the Input Controls bar — switch toggles, edit multi-bit values, or adjust a clock's period — while the simulation runs.
Hover over wires in the circuit to add signals to the waveform monitor.

Synthesis modes

Mode	Internet required	Speed	Notes
Server Side	Yes (synthesis + CDN)	Fast	Uses digitaljs.tilk.eu API; supports the widest range of constructs
WebAssembly	CDN only	Slower on first use (WASM init)	Runs Yosys locally via @yowasp/yosys; fully offline synthesis

The default quick-synthesis button always uses WebAssembly mode. To use Server Side mode, open the Parameters sidebar and select Server Side from the Synthesis mode dropdown before clicking Synthesize Circuit.

On first use, WebAssembly mode downloads and caches the Yosys WASM binary (~50 MB). Subsequent runs are faster.

Work in Progress

Simulation Engine / Delay: The options for "Zero combinational propagation delay" and switching "Simulation engines" are visible in the UI but are not currently passed into the active JointJS/DigitalJS rendering engine.

Button	Action
▶ / ⏸	Start simulation / Pause simulation (single toggle button)
▶ 1	Step 1 tick
▶ 10	Step 10 ticks
▶ 100	Step 100 ticks
▶ 1000	Step 1000 ticks
`N` (tick counter)	Current simulation tick
− / +	Zoom circuit out / in
⊡	Fit circuit to panel

Input Controls panel:

Control	Action
Circular lamp + label (start of bar)	Synthesis status: grey/yellow = synthesising, green = ready, red = error
◀ / ▶ (next to panel title)	Collapse / expand the Input Controls bar
Toggle switch	Drive a single-bit input high/low
Value box	Edit a multi-bit input's value (decimal by default)
Lamp	Read-only indicator for an output signal
`[value][▲▼]` (clock rows)	Set the clock's period in ticks

Waveform toolbar:

Control	Action
+ / −	Zoom waveform in / out
`scale N`	Current pixels-per-tick
◀ / ▶	Scroll waveform left / right
Live	Jump to live (latest tick)
`range X – Y`	Currently visible tick range

How it works

Server Side mode:

VSCode extension host (Node.js)
  └─ HTTPS POST → digitaljs.tilk.eu/api/yosys2digitaljs
       └─ receives circuit JSON
            └─ postMessage → Webview
                 └─ new digitaljs.Circuit(json)   ← CDN library, runs locally
                 └─ circuit.displayOn($('#paper')) ← JointJS diagram
                 └─ new digitaljs.MonitorView(…)  ← waveform panel

WebAssembly mode:

VSCode extension host (Node.js)
  └─ spawns Worker thread (wasm-worker.mjs, ESM)
       └─ @yowasp/yosys → runs Yosys WASM locally
       └─ yosys2digitaljs/core → converts netlist to circuit JSON
            └─ postMessage → extension host
                 └─ postMessage → Webview
                      └─ new digitaljs.Circuit(json)   ← CDN library, runs locally
                      └─ circuit.displayOn($('#paper')) ← JointJS diagram
                      └─ new digitaljs.MonitorView(…)  ← waveform panel

The Worker thread is necessary because @yowasp/yosys is an ESM-only package that uses import.meta.url internally to locate its .wasm binaries — this only works in an ESM context, not in the CJS extension host.

Known limitations

CDN libraries (rendering/simulation) always require an internet connection
Very large designs may be slow to render (JointJS lays out all gates in the browser)
WebAssembly mode has a ~50 MB one-time WASM download on first use
WebAssembly mode uses hierarchy -auto-top; proc; opt internally, which may produce slightly different results than the server-side synthesis pipeline for complex designs

Credits

DigitalJS by Marek Materzok (tilk) — the circuit simulator
yosys2digitaljs — the synthesis backend
Yosys — the open-source synthesis framework powering it all
YoWASP — WebAssembly port of Yosys enabling local synthesis

License

MIT — see LICENSE
