JsonlView

JsonlView is a read-only VS Code event data studio. Its first format adapter is a bounded JSONL/NDJSON engine; semantic profiles turn records into useful views for traditional software logs, telemetry and traces, and Agent trajectories.

It opens .jsonl and .ndjson as an optional read-only custom editor with:

• bounded byte indexing and lazy record hydration;
• virtualized table, event timeline, schema, problems, and record detail views;
• typed filtering, full-text search, forward/backward cursor pagination, and cancellation;
• direct physical-page input for large files, with BigInt-safe ordinal anchors;
• automatic semantic profile detection without changing the source record;
• collapsible JSON Tree, highlighted Pretty JSON, exact Source, on-demand full event text, derived semantics, and Agent content containers with Auto/Text/Markdown/JSON modes, and byte-boundary detail views;
• source generation tracking, stale-message rejection, manual rebuild, and follow mode;
• tail follow that keeps the prior page visible until a verified append generation can replace it atomically;
• on-demand category and time-bucket Insights with cancellation and hard scan limits.

Visual examples

These screenshots use the synthetic fixtures maintained in the companion JsonlView-harness checkout. They show the same read-only workbench across agent events, telemetry, and aggregate analysis.

Codex Rollout - Table

Generic Agent Events - Table and Tree

OpenTelemetry - Schema and Tree

Claude Code Session - Insights

The source file remains authoritative. JsonlView never edits it, executes its contents, or sends records over the network. File-backed resources are required in this release.

Product boundary

JSONL is the current physical format, while profiles provide the semantic view. A profile may interpret one JSONL record as an application log, OTel log/span, request event, Codex/Claude event, or software-engineering Agent step. Profiles do not own file I/O and cannot rewrite, drop, or split the authoritative record.

Formats that are not line-delimited JSON need separate adapters. Plain or multiline text logs, a regular JSON array/object, Chrome/Jaeger trace JSON, OTLP protobuf, and compressed .jsonl.gz are not claimed as supported in v0.2. See docs/format-and-profile-boundaries.md and the measured docs/acceleration-roadmap.md.

Built-in semantic profiles currently cover Codex rollout, Claude Code (transcript, observed job timeline, and observed command-history surfaces), vendor-neutral Agent events, software-engineering trajectories, OpenTelemetry, traditional structured application logs, and Generic JSONL fallback. Domain events keep their identity in the timeline (log, span, task, action, observation, patch, test, and result); severity remains a separate dimension.

Follow mode is opt-in. It opens the current tail page, keeps the visible rows stable while an appended snapshot is rebuilt, and swaps to the new tail page in one state update. Replacements, truncation, and invalid prefix changes still advance the source generation rather than mutating old record references.

Insights is also opt-in: no aggregate scan runs during open. Entering the tab or pressing its refresh button examines at most 100,000 physical records, 64 MiB of logical record content, or 5 seconds per request, whichever comes first. Bounded category/time accumulators receive only matching rows; requests are cancellable and report examined versus matched records, truncation reason, and group overflow.

Agent message, reasoning, and tool-result text keeps its original value for copying and can be viewed as plain text, conservative Markdown, or embedded object/array JSON. Known Codex item_completed -> AgentMessage -> Text content, Claude assistant text blocks, and the explicit Claude job timeline at/state/detail/text shape select Markdown by default; Claude history display, user prompts, tool output, and ordinary log text retain Auto mode. Structured tool results are promoted to a foldable JSON container when their value is an object/array or a bounded double-serialized JSON document. Command output can also select a conservative Code view for strong Shell, PowerShell, Python, JavaScript, or Rust signals; uncertain output remains selectable source text. The Claude surface rules are observed compatibility boundaries, not claims about an official stable on-disk schema.

Auto recognizes complete JSON, parseable JSON embedded in prose, headings/lists/quotes/tables, and fenced code; malformed or ambiguous content stays text. Markdown HTML is never executed. Fenced Python, Shell, JS/TS, Rust, and SQL snippets receive bounded lexical highlighting, plus per-block copy and Wrap controls; unknown languages stay exact source. Initial rich parsing is bounded to 64 KiB and displays its boundary; Raw and Copy remain the routes to the complete hydrated field without mounting one enormous DOM node. Ordinary structured results can use a separate bounded expansion up to 256 KiB; larger values stay Raw-only. Records larger than jsonlView.hydration.maxBytes intentionally remain bounded previews during list/index hydration. Tree exposes an explicit Show full record action for a second, independently bounded read controlled by jsonlView.hydration.fullMaxBytes; records above that ceiling remain previews. Visible pages also use the aggregate soft cap jsonlView.hydration.pageMaxBytes; a boundary record may exceed that cap to preserve cursor progress, and the page banner identifies the partial result. Rebuild reuses all hydration limits captured when the session opened.

Codex FileChange records with unified_diff (including path-keyed change maps) use a bounded unified-diff view with old/new line numbers and explicit green additions and red removals. Add/delete file content is projected into the same view; Raw keeps the exact record source, while Copy copies the diff view's available source.

Codex command arrays use a display-only Shell/PowerShell command view with argument boundaries, wrapping, and bounded lexical highlighting. Codex Code Mode JavaScript receives the same treatment for common object literals and statement boundaries; the original input remains the Copy/Raw source within the existing record hydration budget.

Experimental native scanner

jsonlView.native.newlineScanner defaults to off. auto probes the packaged win32-x64 Rust/napi-rs scanner and keeps it only when a bounded calibration is at least 10% faster than the adaptive Node scanner; missing, incompatible, or invalid native output falls back to Node. on prefers native but retains the same validation and fallback. A native process crash cannot be caught by a JavaScript fallback, which is why native is not the default in v0.2.

pnpm benchmark:engine --file <stable.jsonl> --scanner off --no-query
pnpm benchmark:engine --file <stable.jsonl> --scanner auto --no-query
pnpm benchmark:engine --file <stable.jsonl> --scanner on --no-query

Development

Development and CI use Node 24.15.0 through Volta (minimum supported runtime: Node 22.12.0) and pnpm 10.26.0. The Node floor is intentional: Vitest 5 and the current Node type definitions require it. The VS Code extension itself remains governed by the engines.vscode field above.

Generated benchmark and CDP acceptance artifacts are kept outside the source workspace by default, under the operating system temporary directory. Set JSONLVIEW_ARTIFACT_DIR to retain them in a specific external directory.

pnpm install --frozen-lockfile
pnpm check:contract
pnpm typecheck
pnpm test
pnpm test:coverage
pnpm build
pnpm native:verify
pnpm audit:cargo
pnpm check:cargo-policy
pnpm package:vsix

The repository also has a scheduled maintenance lane. pnpm check:dependencies checks direct dependencies against the npm latest tag and writes a bounded JSON report outside the checkout; it reports drift without silently changing the lockfile. pnpm benchmark:trend runs the stable synthetic workload and appends machine-readable timing and memory samples to an external history file. GitHub Actions runs both checks weekly and uploads the reports for comparison.

For a pinned producer checkout, pnpm discover:producers -- --root <checkout> --out <external-report> creates a bounded, redaction-safe inventory of JSONL path literals, serializer/writer terminals, stream producers, and relevant environment controls. The result is candidate evidence only: it records scan limits and source revision, may include test/documentation matches, and must be reviewed against a source anchor and fixture before runtime profile code is changed. The extension never scans a producer checkout.

Public promotion has a separate read-only gate. pnpm release:preflight -- --public --approved-npm-name @sumi-labs/jsonl-view --vsix-target <open-vsx|marketplace> --vsix-pair-report <pair-report> --paired-vsix-artifact <other-target-vsix> --provenance <full-native-report> --npm-manifest <npm-manifest> --npm-candidate <candidate-directory> --npm-tarball <exact-tgz> --vsix-manifest <vsix-manifest> --vsix-artifact <packaged-vsix> --out <external-report> requires a clean checkout, a configured remote, publishable identity and license metadata, a full native source-to-binary comparison, and inventories that exclude source, tests, reports, and credentials. The gate re-inspects the exact npm .tgz, including its embedded identity and complete inventory, then re-inspects the exact VSIX artifact before it can pass. It never publishes or changes credentials.

After the local and candidate manifests exist, run pnpm promotion:plan -- --preflight <preflight.json> --local-manifest <local-sync.json> --vsix-manifest <vsix-manifest.json> --npm-manifest <npm-manifest.json> once per target. Then run pnpm promotion:join -- --open-vsx <open-plan> --marketplace <marketplace-plan> to prove both plans share the exact same VSIX pair. The plan-only reports require an explicit window reload readback and leave GitHub, npm, Open VSX, and Marketplace in independent authorization states; they never invoke a publisher or registry command.

The public coordinates are explicit because extension names are registry identities rather than product labels:

Both VSIX files are built from the same frozen payload. They intentionally keep the same jsonlView.* commands, settings, and custom-editor ID, so install only the build supplied by the registry you use. If switching registries, uninstall or disable the other extension first.

Use the exact reviewed VSIX path with sync:local --vsix <candidate.vsix> when the same artifact will be promoted publicly; rebuilding a second candidate can produce a different native binary digest and is intentionally treated as a new release candidate.

pnpm package:npm creates a reviewable npm candidate directory and one exact .tgz in an external staging area; it never runs npm publish. A public candidate requires an explicit package name, version, --native, external build-once --dist, and external --tarball paths. Publish only the exact .tgz after preflight; do not rerun npm publish on the mutable directory. Pass the same verified native and production bundle to package:npm and package:vsix:candidate; preflight rejects either archive when those shared bytes differ. --allow-proprietary and --allow-dirty are limited to local probe packages; public staging rejects them. Use --replace only when intentionally replacing an existing staging directory. The candidate currently targets win32-x64 because it ships the packaged Rust addon.

For the extension currently used on this machine, run the local synchronization lane with the exact public identity and reviewed version:

pnpm sync:local -- --target open-vsx --version 0.2.1 --install

The command builds an external VSIX candidate, installs it through the selected portable VS Code CLI, and verifies the installed id, version, location, and bundle digests. It records a redaction-safe manifest outside the checkout and reports that the active window must be reloaded. It never publishes to npm, GitHub, Open VSX, or Marketplace; those targets use the protected promotion gate described in ADR-008.

The detailed architecture and acceptance contract live in docs/format-and-profile-boundaries.md and the decision records under docs/decisions/.

License

JsonlView is available under the MIT License. Third-party licenses and notices are listed in THIRD-PARTY-NOTICES.txt.
