Soldered MicroPython Helper

A MicroPython-focused extension for Visual Studio Code designed for working with ESP and RP2-based boards. Flash firmware, upload scripts, monitor serial output, and fetch Soldered libraries — all from within the editor.

Note: This extension is actively developed. Report issues on GitHub.

Install from VS Code Marketplace

Requirements

Before using this extension, install the required Python tools:

pip install esptool mpremote

Both esptool and mpremote must be accessible on your system PATH.

Serial port access

Linux: If your board does not appear in the port list, run this once to grant your account access to serial ports:

sudo usermod -a -G dialout $USER

Then log out and log back in. After that, the extension can communicate with your board.

macOS: No extra steps needed. If your board does not appear in the port list, you may need to install a USB-Serial driver for your board's chip:

• CP210x driver — used by most ESP32 boards
• CH340 driver — used by some cheaper boards

After installing the driver, replug your board.

Windows: If no ports appear, try running VS Code as Administrator.

Features

• Flash MicroPython firmware to ESP and RP2-based boards
• Upload, run, and delete .py files on the device
• Upload entire folders preserving directory structure
• Browse files and folders on the device in a tree view
• Live serial output monitoring
• Open and edit files directly from the device
• Fetch Soldered libraries and examples from GitHub
• Auto-detect connected serial ports

Installation

1. Open Visual Studio Code.
2. Go to the Extensions panel (Ctrl+Shift+X).
3. Search for Soldered MicroPython Helper.
4. Click Install.

Alternatively, install directly from the Marketplace.

Usage

Selecting a port

Select your board's serial port from the COM Port dropdown. Buttons requiring a connected device are disabled until a port is selected.

Flashing firmware

Select your board from the grouped dropdown and click Flash. The extension fetches the latest official MicroPython firmware automatically.

Uploading files

Upload the currently open file, any .py file from your PC, or an entire folder. When uploading a folder, the directory structure is preserved on the device — subdirectories are created automatically. Files can be run directly on the device and stopped at any time.

Managing files on the device

Click List Files to browse files and folders on the device in a tree view. Folders are expanded by default and can be collapsed. Hover over any item to reveal inline Open, Run, and Del buttons. Files opened from the device are downloaded to a temporary location and opened in the editor. Deleting a folder removes it and all its contents after confirmation.

Installing Soldered modules

Browse modules by category and select a module from the dropdown. Install the library, examples, or both with a single click.

Serial monitor

Open the serial monitor to stream device output to the VS Code output panel. The monitor closes automatically when uploading or running files.

Notes on MicroPython code

Always include a delay inside while True loops. Without one, the device may become unresponsive and output becomes unreadable.

from time import sleep

while True:
    sleep(0.5)
    print("Running...")

Planned / TODO

• Drag & drop file upload — drag .py files from your OS file explorer directly into the file tree to upload them to the device
• Create folder on device — add a new folder directly from the panel without uploading a file first
• Port rescanning on disconnect — automatically restart port scanning when a board is unplugged
• Extension settings menu

Developer Setup

Prerequisites

• Node.js and npm
• Python 3.x
• Native build tools for the serialport package:
  • Windows: npm install --global --production windows-build-tools
  • macOS: xcode-select --install
  • Linux: sudo apt-get install build-essential python3-dev

Build

npm install
npm run vscode:prepublish

Run locally

Open the project in VS Code and press F5 to launch an Extension Development Host with the extension loaded.
