SolarWire Support - VS Code Extension

VS Code extension for SolarWire DSL, providing syntax highlighting, snippets, real-time preview, and more!

Installation

From VS Code Marketplace

Install from VS Code Marketplace or search for "SolarWire Support" in the Extensions panel.

• ✅ Syntax Highlighting – Color-coded SolarWire code for better readability
• ✅ Snippets – Quick code snippets for common elements
• ✅ Real-time Preview – Live preview panel that updates as you type
• ✅ Diagnostics – Error highlighting with detailed messages
• ✅ Auto-completion – Smart suggestions for elements, attributes, and declarations
• ✅ Hover Information – Documentation when hovering over elements and attributes
• ✅ Export – Export to SVG and PNG formats

Installation

From Source

1. Clone the repository
2. Run npm install in the root directory
3. Run npm run build to compile all packages
4. Open the packages/vscode-extension folder in VS Code
5. Press F5 to launch the Extension Development Host
6. Open a .solarwire or .md file to use the extension

Commands

• SolarWire: Open Preview – Open the real-time preview panel
• SolarWire: Export SVG – Export the current document as SVG
• SolarWire: Export PNG – Export the current document as PNG

Usage

1. Create a new file with the .solarwire extension, or use in .md files
2. Start writing SolarWire code – syntax highlighting will work automatically
3. Use Ctrl+Shift+P (or Cmd+Shift+P on Mac) and select "SolarWire: Open Preview" to see the live preview
4. The preview updates automatically as you type
5. Use auto-completion (Ctrl+Space) to get suggestions for elements and attributes
6. Hover over elements and attributes to see documentation
7. Any parsing errors will be highlighted in red with detailed messages

Snippets

The extension provides the following snippets:

• rect – Rectangle element: ["text"]
• round – Rounded rectangle: ("text")
• circle – Circle element: (("text"))
• text – Text element: "text"
• placeholder – Placeholder element: [?"text"]
• image – Image element: <url>
• line – Line element: -- @(x1,y1)->(x2,y2)
• row – Row container: {row}
• col – Column container: {col}
• table – Table element: ##
• tablerow – Table row: #

Auto-completion

The extension provides smart auto-completion for:

• Elements: All SolarWire element types with snippets
• Attributes: Common attributes for each element type
• Declarations: Document-level declarations at the top of the file

Diagnostics

The extension provides real-time error diagnostics:

• Parsing errors are highlighted with red squiggles
• Error messages show the exact line and column
• Errors update automatically as you type
• Hover over errors to see detailed messages

Export

SVG Export

1. Open a .solarwire file
2. Use Ctrl+Shift+P and select "SolarWire: Export SVG"
3. Choose a location to save the SVG file
4. Alternatively, click the "Download SVG" button in the preview panel

PNG Export

1. Open a .solarwire file
2. Use Ctrl+Shift+P and select "SolarWire: Export PNG"
3. Preview the PNG in the webview panel
4. Click "Save PNG" to choose a location
5. The PNG is exported at 2x resolution for crispness

Example

!title="My Wireframe"

["Header"] @(50,50) w=700 h=80 bg=#4CAF50 c=white
["Content"] @(50,150) w=700 h=400
["Footer"] @(50,570) w=700 h=60 bg=#333 c=white

Development

Build

cd packages/vscode-extension
npm run build

Project Structure

packages/vscode-extension/
├── src/
│   └── extension.ts        # Main extension code
├── lib/
│   ├── parser/             # Parser library (compiled)
│   └── renderer-svg/       # SVG renderer library (compiled)
├── syntaxes/
│   └── solarwire.tmLanguage.json  # Syntax highlighting grammar
├── snippets/
│   └── solarwire.json     # Code snippets
├── media/
│   └── solarwire-markdown.js  # Preview panel scripts
├── language-configuration.json  # Language configuration
├── package.json
├── tsconfig.json
└── readme.md

License

MIT © SolarWire contributors
