JumpProto

English | 简体中文

JumpProto helps Go teams move between generated Go code and the source .proto files that produced it. It is useful in repositories where .pb.go files, services, and Proto sources live in separate directories and the normal definition flow stops inside generated code.

Use JumpProto to:

jump from generated Go symbols back to message, enum, service, rpc, nested messages, and fields in .proto;
find Go usages from a Proto message, enum, RPC, field type, or field name;
keep project-level Proto roots and compile rules in .jumpproto;
run or dry-run the current Proto compile command from the sidebar;
diagnose stale or unexpected navigation results without leaving the editor.

Screenshots

JumpProto sidebar with Proto roots and compile rule

Jump from generated Go code to the source Proto definition

Find Go usages from a Proto field

Install

After installation, open a Go workspace that contains generated .pb.go files and source .proto files.

Quick Start

Open the JumpProto view from the Activity Bar.
Add the directory that contains source Proto files, for example proto_src.
Open a generated Go file and place the cursor on a generated symbol such as CreateOrderReq.
Press F12, or run JumpProto: Jump To Proto.
Open a .proto file and run JumpProto: Jump To Go on a message, field, enum, service, or RPC when you need Go usages.

If your team wants shared project setup, commit a .jumpproto file at the workspace root.

Main Workflows

Go To Proto

JumpProto follows the generated Go definition, reads the generated file header, and opens the matching source .proto file.

// generated order.pb.go
// source: api/order.proto

type CreateOrderReq struct {
    UserId string `protobuf:"bytes,1,opt,name=user_id,json=userId,proto3"`
}

Put the cursor on CreateOrderReq or UserId in Go, then use F12 or JumpProto: Jump To Proto.

Proto To Go

From a .proto file, JumpProto searches Go code for common usage forms:

qualified imports, such as orderpb.CreateOrderReq;
import aliases;
same-package generated Go references;
field reads, such as req.UserId;
getter calls, such as req.GetUserId();
composite literal fields, such as UserId: value.

Results open in VS Code's native references view.

Compile Current Proto

Configure a command template once, then run it for the active .proto file from the sidebar or command palette.

cd {protoSrcRoot} && make api pkg={protoFileNoExt}

Use Test Command before compiling. It performs a shell dry run and writes the rendered command to the JumpProto output channel.

Project Config

JumpProto uses .jumpproto at the opened workspace root for project-level configuration. This is the recommended setup for teams because roots and compile rules can be shared with the repository.

{
  "protoRoots": [
    "proto_src",
    "../shared-proto"
  ],
  "searchInWorkspace": true,
  "makeProtoCommand": "cd {protoSrcRoot} && make api pkg={protoFileNoExt}",
  "exclude": [
    "**/node_modules/**",
    "**/vendor/**",
    "**/out/**",
    "**/dist/**",
    "**/.git/**"
  ]
}

Relative protoRoots are resolved from the workspace root. .jumpproto values take priority over older protoJump.* VS Code settings; missing fields still fall back to those settings for compatibility.

Compile Placeholders

Placeholder	Value
`{workspaceFolder}`	Current workspace root.
`{protoSrcRoot}`	Matched Proto source root.
`{protoFile}`	Active Proto file path.
`{protoFileNoExt}`	Active Proto file name without `.proto`.
`{protoDir}`	Directory of the active Proto file.
`{relativeProto}`	Path relative to `protoSrcRoot`, including `.proto`.
`{relativeProtoNoExt}`	Path relative to `protoSrcRoot`, without `.proto`.
`{protoPackage}`	Package segment inferred from `go_package` or `package`.

For repositories with multiple compile targets, route by relative path:

cd {protoSrcRoot} && case {relativeProto} in
  rpc/*) make rpc pkg={protoFileNoExt} ;;
  api/*) make api pkg={protoFileNoExt} ;;
  model/*) make golang_model_proto ;;
  *) make special_proto packagename={protoPackage} filename={protoFileNoExt} ;;
esac

Commands

Command	What It Does
`JumpProto: Jump To Proto`	Opens the source `.proto` definition for the generated Go symbol under the cursor.
`JumpProto: Jump To Go`	Finds Go usages for the Proto symbol or field under the cursor.
`JumpProto: Compile This Proto`	Runs the configured command template for the active `.proto` file.
`JumpProto: Test Navigation`	Resolves the current cursor target and writes the result to output.
`JumpProto: Diagnose Current Symbol`	Writes detailed navigation diagnostics to output.
`JumpProto: Open Output`	Opens the `JumpProto` output channel.
`JumpProto: Clear Cache`	Clears JumpProto's in-memory navigation and usage caches.

The sidebar also provides buttons for Proto roots, Make Proto rules, language switching, theme switching, diagnostics, output, and cache cleanup.

Requirements

Generated Go files should be produced by protoc-gen-go.
Generated files should contain a source header such as // source: api/order.proto.
Go-to-Proto navigation works best with the official Go extension and gopls enabled.
Compile commands run locally through the current system shell.

Limits

Go-to-Proto navigation depends on VS Code first resolving the Go symbol to a generated .pb.go or .pb.gw.go definition.
Proto-to-Go usage search is a static workspace search, not a full Go type-system reference query.
Usage search returns up to 200 references and can be cancelled from the progress notification.
Field usage search can miss reflection, dynamic code, generated wrappers, or unusual aliasing.
JumpProto caches file scans for responsiveness. Cache entries are automatically invalidated on relevant file, config, or workspace changes, and can also be cleared manually from the sidebar.

Privacy

JumpProto runs locally inside VS Code/Cursor. It does not send paths, source code, Proto files, Go files, or compile commands to any remote service.

Path examples in this README use placeholders such as /workspace/demo-shop, /ABSOLUTE/PATH/TO/..., and $HOME/... to avoid exposing personal local directory information.

Support

Report issues at github.com/SivanCola/JumpProto/issues.

License

JumpProto is licensed under the Apache License, Version 2.0. See LICENSE. Third-party asset notices are listed in NOTICE and THIRD_PARTY_NOTICES.md.

简体中文

JumpProto 帮助 Go 项目在生成后的 Go 代码和源 .proto 文件之间来回跳转。它适合 .pb.go、业务 Go 代码和 Proto 源码分散在不同目录里的仓库，尤其适合普通定义跳转只停在生成代码里的场景。

你可以用 JumpProto：

从生成 Go 符号跳回 .proto 里的 message、enum、service、rpc、内部消息和字段；
从 Proto 的 message、enum、RPC、字段类型或字段名反查 Go 使用处；
使用 .jumpproto 保存项目级 Proto 根目录和编译规则；
在侧边栏运行或 dry-run 当前 Proto 文件的编译命令；
在跳转结果异常时查看诊断信息并清理缓存。

安装

安装后，打开包含生成 .pb.go 文件和源 .proto 文件的 Go 工作区。

快速开始

从 Activity Bar 打开 JumpProto 侧边栏。
添加源 Proto 文件所在目录，例如 proto_src。
打开生成 Go 文件，把光标放在 CreateOrderReq 这类生成符号上。
按 F12，或执行 JumpProto: Jump To Proto。
打开 .proto 文件后，可在 message、字段、enum、service 或 RPC 上执行 JumpProto: Jump To Go 查看 Go 使用处。

如果团队需要共享配置，建议把 .jumpproto 提交到仓库根目录。

主要工作流

Go 跳 Proto

JumpProto 会跟随生成 Go 定义，读取生成文件头部，再打开对应的源 .proto 文件。

// generated order.pb.go
// source: api/order.proto

type CreateOrderReq struct {
    UserId string `protobuf:"bytes,1,opt,name=user_id,json=userId,proto3"`
}

把光标放在 Go 里的 CreateOrderReq 或 UserId 上，然后使用 F12 或 JumpProto: Jump To Proto。

Proto 查 Go

从 .proto 文件出发，JumpProto 会搜索常见 Go 使用方式：

带包名引用，例如 orderpb.CreateOrderReq；
import alias；
同包生成 Go 引用；
字段读取，例如 req.UserId；
getter 调用，例如 req.GetUserId()；
结构体字面量字段，例如 UserId: value。

结果会打开在 VS Code 原生引用视图里。

编译当前 Proto

配置一次命令模板后，即可从侧边栏或命令面板按当前 .proto 文件执行。

cd {protoSrcRoot} && make api pkg={protoFileNoExt}

编译前建议先点击 Test Command。它只做 shell dry-run，并把展开后的命令写入 JumpProto 输出面板。

项目配置

JumpProto 推荐使用工作区根目录下的 .jumpproto 保存项目级配置。这样团队可以在仓库里共享同一套根目录和编译规则。

{
  "protoRoots": [
    "proto_src",
    "../shared-proto"
  ],
  "searchInWorkspace": true,
  "makeProtoCommand": "cd {protoSrcRoot} && make api pkg={protoFileNoExt}",
  "exclude": [
    "**/node_modules/**",
    "**/vendor/**",
    "**/out/**",
    "**/dist/**",
    "**/.git/**"
  ]
}

相对 protoRoots 会从工作区根目录解析。.jumpproto 优先于旧的 protoJump.* VS Code 设置；未声明的字段仍会回退到旧设置，便于兼容已有用户。

编译占位符

占位符	含义
`{workspaceFolder}`	当前工作区根目录。
`{protoSrcRoot}`	命中的 Proto 源文件根目录。
`{protoFile}`	当前 Proto 文件路径。
`{protoFileNoExt}`	当前 Proto 文件名，不含 `.proto`。
`{protoDir}`	当前 Proto 文件所在目录。
`{relativeProto}`	相对 `protoSrcRoot` 的路径，包含 `.proto`。
`{relativeProtoNoExt}`	相对 `protoSrcRoot` 的路径，不含 `.proto`。
`{protoPackage}`	根据 `go_package` 或 `package` 推导出的包名片段。

同一仓库有多套编译目标时，可以按相对路径分流：

cd {protoSrcRoot} && case {relativeProto} in
  rpc/*) make rpc pkg={protoFileNoExt} ;;
  api/*) make api pkg={protoFileNoExt} ;;
  model/*) make golang_model_proto ;;
  *) make special_proto packagename={protoPackage} filename={protoFileNoExt} ;;
esac

命令

命令	作用
`JumpProto: Jump To Proto`	打开光标下生成 Go 符号对应的源 `.proto` 定义。
`JumpProto: Jump To Go`	查找光标下 Proto 符号或字段的 Go 使用处。
`JumpProto: Compile This Proto`	按当前 `.proto` 文件上下文运行已配置的命令模板。
`JumpProto: Test Navigation`	解析当前光标目标并写入输出面板。
`JumpProto: Diagnose Current Symbol`	将当前光标的详细诊断信息写入输出面板。
`JumpProto: Open Output`	打开 `JumpProto` 输出面板。
`JumpProto: Clear Cache`	清理 JumpProto 的内存跳转和 usage 缓存。

侧边栏也提供 Proto 根目录、Make Proto 规则、语言切换、主题切换、诊断、输出和清理缓存入口。

前置条件

Go 代码应由 protoc-gen-go 生成。
生成文件应包含 // source: api/order.proto 这类 source 头部。
Go 跳 Proto 推荐配合官方 Go 扩展和 gopls 使用。
编译命令会在本机通过当前系统 shell 执行。

支持边界

Go 跳 Proto 依赖 VS Code 先把 Go 符号解析到生成的 .pb.go 或 .pb.gw.go 定义。
Proto 查 Go 是静态工作区搜索，不等同于完整 Go 类型系统引用查询。
Usage 搜索最多返回 200 个引用，可在进度通知里取消。
字段使用处搜索可能漏掉反射、动态代码、生成包装或复杂别名。
JumpProto 会缓存文件扫描以保持响应速度。相关文件、配置或工作区变化时会自动失效，也可以从侧边栏手动清理。

隐私

JumpProto 只在 VS Code/Cursor 本地运行，不会把路径、源码、Proto 文件、Go 文件或编译命令发送到任何远程服务。

本文档中的路径示例使用 /workspace/demo-shop、/ABSOLUTE/PATH/TO/... 和 $HOME/... 这类占位符，避免暴露个人本地目录信息。

支持

问题反馈请提交到 github.com/SivanCola/JumpProto/issues。

许可证

JumpProto 使用 Apache License, Version 2.0 授权。详见 LICENSE。第三方资源声明见 NOTICE 和 THIRD_PARTY_NOTICES.md。
