Better Diff Viewer

View Git diff in a colorful HTML page via Diff2Html-UI.

Dark Mode (v0.0.8)

Better Diff Viewer screenshot - dark

Light Mode (v0.0.1)

Better Diff Viewer screenshot - light

Rationale

Creating a similar diff view panel to Source Tree. The aim is to add most of the features which Source Tree diff viewer can do. For example, view Diff in HTML, revert a file ...

Features

[x] View .diff/.patch or git diff in Diff2HTML-UI
[x] View diff for uncommitted changes
[x] Dark/light/auto mode support
[x] Diff2Html-UI user configurable settings
[x] Trigger content refresh manually
[x] Open a file in editor
[x] Revert a file
[x] Copy file path
[x] Toggle show/hide the command (i.e., git command), which was used to generate the diff result
[x] Support custom styling - better support for unknown themes
[x] Support custom user commands, which can be defined by user
[x] Store users view actions (i.e., remember viewed button for files)
[x] Zoom in/out
[x] Triggering extension commands from bottom toolbar
[x] Specify panel location (i.e. in editor or panel)
[x] View content of a GIT commit
[x] Support hunk action - e.g. revert hunk only code
[ ] Show and interact with git log tree

Commands

better-diff-viewer.viewDiffFile: view diff for current .diff/.patch file
better-diff-viewer.viewRepoGitDiff: view Git diff for current repository
better-diff-viewer.viewGitDiffForFile: view Git diff for current file
better-diff-viewer.viewCustomDiffFromCmd: View Diff from a custom command on current repository
better-diff-viewer.viewChangesInCommit: View Changes in selected commit
better-diff-viewer.viewChangesBetweenCommits: View Changes between selected commits

Settings

Command	Default Value	Description
better-diff-viewer.isAutoRefresh	true	Toggle if the view needs to be refreshed when any file get saved
better-diff-viewer.showBtnIcon	true	Show button icon
better-diff-viewer.showBtnLongDesc	true	Show button long description
better-diff-viewer.showBtnShortDesc	false	Show button short description (for saving spaces)
better-diff-viewer.customCssStyle	''	Add custom CSS style for the diff viewer. Please add in one line. For example: ".d2h-file-name{color:cyan !important;}"
better-diff-viewer.preserveViewedFileState	true	Preserve viewed checkbox state after diff viewer refresh
better-diff-viewer.enableRevertHunk	true	Support revert selected hunk
better-diff-viewer.showCmd	true	Set the default visibility of the command which used to generate the diff output. The cmd is shown at the bottom of the page
better-diff-viewer.zoomNum	0.9	Set default zoom level for the viewer
better-diff-viewer.showRevertFileWarning	true	Display a warning when reverting a file
better-diff-viewer.componentsDisplayAtEditor	["diffViewer"]	Components display at editor section - reload required
better-diff-viewer.componentsDisplayAtPanel	[]	Components display at panel section - reload required

better-diff-viewer.diff2html-ui.outputFormat	'line-by-line'	'line-by-line' or 'side-by-side'; A Diff2Html option
better-diff-viewer.diff2html-ui.drawFileList	true	A Diff2Html option
better-diff-viewer.diff2html-ui.srcPrefix	''	A Diff2Html option
better-diff-viewer.diff2html-ui.dstPrefix	''	A Diff2Html option
better-diff-viewer.diff2html-ui.diffMaxChanges	undefined	A Diff2Html option
better-diff-viewer.diff2html-ui.diffMaxLineLength	undefined	A Diff2Html option
better-diff-viewer.diff2html-ui.diffTooBigMessage	N/A	A Diff2Html option
better-diff-viewer.diff2html-ui.matching	'lines'	'lines', 'words' or 'none'; A Diff2Html option
better-diff-viewer.diff2html-ui.matchWordsThreshold	0.25	A Diff2Html option
better-diff-viewer.diff2html-ui.maxLineLengthHighlight	10000	A Diff2Html option
better-diff-viewer.diff2html-ui.diffStyle	'word'	A Diff2Html option
better-diff-viewer.diff2html-ui.renderNothingWhenEmpty	false	A Diff2Html option
better-diff-viewer.diff2html-ui.matchingMaxComparisons	2500	A Diff2Html option
better-diff-viewer.diff2html-ui.maxLineSizeInBlockForComparison	200	A Diff2Html option
better-diff-viewer.diff2html-ui.compiledTemplates	{}	A Diff2Html option
better-diff-viewer.diff2html-ui.rawTemplates	{}	A Diff2Html option
better-diff-viewer.diff2html-ui.highlightLanguages	N/A	A Diff2Html option

better-diff-viewer.diff2html-ui.colorScheme	'auto'	'light', 'dark' or 'auto'; A Diff2Html option values. The 'auto' will use the VSCode color schema
better-diff-viewer.diff2html-ui.synchronisedScroll	true	A Diff2HtmlUI option
better-diff-viewer.diff2html-ui.highlight	true	A Diff2HtmlUI option
better-diff-viewer.diff2html-ui.fileListToggle	true	A Diff2HtmlUI option
better-diff-viewer.diff2html-ui.fileListStartVisible	false	A Diff2HtmlUI option
better-diff-viewer.diff2html-ui.fileContentToggle	true	A Diff2HtmlUI option
better-diff-viewer.diff2html-ui.stickyFileHeaders	true	A Diff2HtmlUI option

Installation

Install from Visual Studio Marketplace

Thanks to Diff2Html

Goto Diff2Html

Author

Sam Wang - https://liveinaus.com

LICENSE

GNU General Public License v3.0

Enjoy!
