Gmsh (Language Support & 3D Interactive Preview)

The definitive Visual Studio Code extension for Gmsh.
Featuring comprehensive language support (IntelliSense autocompletion, snippets, hover docs) alongside real-time 3D geometry and finite element mesh visualization.

Features • Getting Started • Configuration • Snippets • 日本語ドキュメント

✨ Features

1. 🧠 Comprehensive Gmsh Language Support (IntelliSense)

Keyword & Primitive Autocompletion: Instant suggestions for Point, Line, Circle, Spline, Curve Loop, Plane Surface, Surface, Volume, and OpenCASCADE primitives (Box, Cylinder, Sphere, etc.).
Dynamic Variable Detection: Automatically scans your open .geo file to suggest user-defined variables and arrays (e.g., out[], lc, r).
Context-Aware Safety: Autocompletion is intelligently suppressed inside comments (//) to prevent unwanted popup interruptions.
Hover Documentation: Hover over any Gmsh command to view its syntax, parameters, and example code in formatted Markdown.
Auto-Closing & Indentation Rules: Optimized brackets, quotes, and {} indentation hierarchy tailored for Gmsh syntax.

2. ⚡ Real-Time 3D Geometry & Mesh Preview

Live Sync: As you edit .geo files, the 3D preview automatically updates in milliseconds (debounced).
Two-Way Code Navigation: Click on any point, curve, or surface in the 3D viewport to immediately jump and focus the editor cursor on its definition line!
Mesh Dimension Switching: Toggle between 0D (geometry points/curves), 1D (line elements), 2D (surface triangles/quads), and 3D (volume tetrahedra/hexahedra).
3D Entity Labels: Visual tags for points (P1, P2...) and curves (C1, C2...) directly overlaid in 3D space.
Display Toggles: Easily toggle points, boundary curves, surface faces, mesh wireframe, labels, ground grid, and coordinate axes.
Multi-Angle Camera: Instant presets for Top, Front, Side, Isometric, and Fit-to-Screen views, plus Perspective / Orthographic projection toggle.
Export Options: Export the current model to STL (.stl), Wavefront OBJ (.obj), or Gmsh Mesh (.msh) directly from the preview toolbar.
Built-in Fallback Parser: Even if Gmsh CLI is not yet installed or has syntax errors, an internal fallback parser keeps basic geometry visible.

🚀 Getting Started

Installation

Option A: Install from GitHub Releases (.vsix)

Download gmsh-preview-0.2.0.vsix from GitHub Releases.
In VS Code, open Extensions (Ctrl+Shift+X / Cmd+Shift+X).
Click the ... (Views and More Actions) menu in the top right, then select Install from VSIX... (or simply drag and drop the .vsix file into the VS Code window).

Option B: Build and Install from Source

git clone https://github.com/Ringo3apples/gmshExtension.git
cd gmshExtension
npm install
npm run build
npx @vscode/vsce package

Install the resulting .vsix file via code --install-extension gmsh-preview-0.2.0.vsix.

Usage

Open any .geo or .msh file. The language mode is automatically set to Gmsh.

Opening the 3D Preview

Choose any of these methods:

Click the eye icon ($(eye)) at the top-right corner of the editor title bar.
Click $(eye) Gmsh Preview in the status bar (bottom right).
Press Ctrl+Shift+P (or Cmd+Shift+P on macOS) and run:
```
Gmsh: Open 3D Realtime Preview to the Side
```

Automatic Gmsh CLI Detection

The extension automatically searches common system paths, C:\Program Files\gmsh*, Conda environments, Downloads, and system PATH for the gmsh executable:

When found, you will be prompted to save it to your settings.
To re-scan manually: Run Gmsh: Auto-Detect Gmsh Executable in the command palette.
To select manually: Run Gmsh: Browse for Gmsh Executable....

⚙️ Configuration (`settings.json`)

Setting	Type	Default	Description
`gmsh.executablePath`	`string`	`"gmsh"`	Path to the Gmsh executable (e.g., `gmsh` or `C:\gmsh\gmsh.exe`)
`gmsh.meshDimension`	`number`	`2`	Default mesh dimension (`0`: Geometry, `1`: 1D, `2`: 2D, `3`: 3D)
`gmsh.debounceDelay`	`number`	`400`	Delay (ms) after code edits before refreshing the preview

⌨️ Snippets & Shortcuts

Type the prefix and press Tab or Enter to expand:

Prefix	Expands To	Description
`Point`	`Point(1) = {x, y, z, lc};`	Point primitive
`Line`	`Line(1) = {start, end};`	Line segment
`Circle`	`Circle(1) = {start, center, end};`	Circular arc
`Curve Loop`	`Curve Loop(1) = {c1, c2, ...};`	Closed curve boundary
`Plane Surface`	`Plane Surface(1) = {loop1};`	Planar surface
`Surface Loop`	`Surface Loop(1) = {s1, s2, ...};`	Enclosed surface shell
`Volume`	`Volume(1) = {loop1};`	3D Volume
`Extrude`	`Extrude {dx, dy, dz} { ... };`	Translation extrusion
`Rotate`	`Rotate { {ax,ay,az}, {px,py,pz}, angle } { ... }`	Rotation transform
`Box`	`Box(1) = {x, y, z, dx, dy, dz};`	OpenCASCADE 3D box
`Cylinder`	`Cylinder(1) = {x, y, z, dx, dy, dz, r};`	OpenCASCADE cylinder
`Sphere`	`Sphere(1) = {x, y, z, r};`	OpenCASCADE sphere
`BooleanDifference`	`BooleanDifference(1) = { ... } { ... };`	OpenCASCADE Boolean cut
`MeshSize`	`MeshSize {points} = size;`	Prescribed element size
`Transfinite Curve`	`Transfinite Curve {curves} = n;`	Structured 1D discretization
`For`	`For i In {1:10} ... EndFor`	Loop iteration
`If`	`If (cond) ... EndIf`	Conditional branch
`Printf`	`Printf("value: %g", var);`	Formatted console output

🇯🇵 日本語

Gmsh のジオメトリスクリプト（.geo）およびメッシュファイル（.msh）に対応した VS Code 拡張機能です。構文ハイライト・入力補完・スニペット・ホバー解説といった言語サポートと、Three.js を用いたリアルタイム 3D プレビュー・双方向コードジャンプを1つの拡張機能に統合しています。

IntelliSense 補完: Point, Circle, Extrude, MeshSize 等の主要コマンドおよびファイル内で定義した変数を自動補完。
ホバー表示: コマンドの上にマウスを置くだけで構文仕様・引数の意味・使用例を表示。
3D プレビュー: コード編集時にミリ秒単位で再描画。3D 上の点・線・面をクリックするとコードの該当行へ即座にジャンプ。
Gmsh 自動検出: お使いの PC 内の gmsh.exe を自動検出するため、環境変数の事前設定が不要です。

インストール方法（日本語）

GitHub Releases から最新の gmsh-preview-0.2.0.vsix をダウンロードします。
VS Code の拡張機能ビュー（Ctrl+Shift+X）を開き、右上の「…」メニューから「VSIX からのインストール...」を選択してダウンロードしたファイルを選びます（または VS Code ウィンドウへファイルをドラッグ＆ドロップ）。

🛠️ Development & Building

# Clone the repository
git clone https://github.com/Ringo3apples/gmshExtension.git
cd gmshExtension

# Install dependencies
npm install

# Build the extension and Webview bundle
npm run build

# Watch mode for rapid development
npm run watch

# Type-check TypeScript
npm run compile

Press F5 in VS Code to launch the Extension Development Host window for live debugging.

📄 License

This extension is licensed under the MIT License.
