MySQL Routine Debugger for Visual Studio Code

[!CAUTION] Early alpha software: this project has undergone only limited testing. Features may be incomplete, behavior may change without notice, and defects may modify routines or other database objects incorrectly. Do not use it with production databases. Use only isolated development or test environments and ensure you have current backups.

Issue reports and help with collaborative testing are very welcome. If you try the debugger, please open an issue to share problems, suggestions, or successful test results. Every constructive report helps make the project safer and more useful.

This module integrates the MySQL Routine Debugger into Visual Studio Code. It provides a dedicated debugger panel for MySQL and MariaDB stored procedures and functions, with searchable routine selection, breakpoints, Continue, Step Into, Step Over, Step Out, variable watches, and execution logs.

The extension runs its Java debugger server in the background and stores database passwords in Visual Studio Code secret storage.

Requirements

• Visual Studio Code 1.96 or newer
• Java 17 or newer
• A reachable MySQL or MariaDB server
• A database account allowed to inspect, create, replace, and restore routines and to create supporting schema objects

Install

1. Open the project's latest release.
2. Download the Visual Studio Code extension file ending in .vsix.
3. In Visual Studio Code, open the Extensions view.
4. Open the Views and More Actions (...) menu and select Install from VSIX....
5. Choose the downloaded .vsix file and reload Visual Studio Code if prompted.

You can also install it from a terminal:

code --install-extension mysql-routine-debugger-<version>.vsix

The latest-release link will become available when the first packaged release is published.

Open the debugger

1. Run MySQL Routine Debugger: Open Debugger from the Command Palette, or select its status-bar item.
2. Select Connect, choose MySQL or MariaDB, and enter the connection details. Use Disconnect when finished; disconnecting is disabled during an active debug session.
3. Type in the routine field to filter its autocomplete dropdown, then choose a routine to load it automatically. Add breakpoints and start debugging.
4. Invoke the routine from another database client.
5. Use Continue (F5), Step Into (F7), Step Out (Ctrl+F7), or Step Over (F8) when execution pauses, then stop the session when finished. Step Into and Step Out appear as separate buttons only where each operation applies.

The debug log is hidden by default; use Show Log when you need it. Use Reset All Debug Changes to recover from an interrupted session.
