meshfox for VS Code

Opens .canvas.md files as an interactive node canvas — the same web UI meshfox view serves in a browser tab, embedded directly in an editor tab instead. Requires the meshfox binary (see the repo root README for install instructions). Resolved from PATH first, then scripts/install.sh's own default install location (~/.local/bin) and a couple of other common ones (/opt/homebrew/bin, /usr/local/bin) if that fails — GUI apps launched from Finder/Dock/Spotlight don't always inherit a login shell's PATH, so this covers the common case of a real install that VS Code just can't see. Set meshfox.executablePath in settings to override both.

On the VS Code Marketplace as Orofarne.meshfox-vscode — install from there (Extensions view, search "meshfox", or ext install Orofarne.meshfox-vscode) rather than building it yourself; the rest of this file is for developing the extension itself.

*.canvas.md opens as a canvas automatically (it's the default editor for that pattern). A plain .md file that's a canvas without the suffix — a marker-carrying file like this project's own README.md — doesn't auto-open as one (VS Code has no reliable way to sniff a file's content before opening it, and an earlier attempt to fake that by opening the canvas editor and immediately bailing out for non-canvases broke VS Code's own tab bookkeeping). Instead, this extension is also registered as an optional editor for any .md, so it always shows up in "Open With..." (right-click a file → Open With..., or the "Open as meshfox canvas" command/Explorer context-menu entry this extension adds). Pick it once for a file like README.md, and if you want that to stick permanently, add it to workbench.editorAssociations in settings — either your own user settings, or this repo's own .vscode/settings.json if you want it for every contributor:

"workbench.editorAssociations": {
  "README.md": "meshfox.canvasEditorAny"
}

Read-only from VS Code's own perspective, same as the browser UI: click "Edit" inside the canvas itself to unlock dragging/resizing/saving layout and persisting a cached block's output — see the root README's "Concept".

Platform support: macOS/Linux only for now. The extension talks to meshfox view --watcher-socket <path> over a Unix domain socket, the same protocol crates/cli/src/watcher.rs speaks — a known gap tracked in the repo's TODO.canvas.md under "Полноценная поддержка Windows".

Syntax highlighting for raw .md/.canvas.md text

Wherever the raw file is shown as text rather than through the canvas editor — git diffs/blame, "Open With... → Text Editor", any .md without a canvas marker — an injection grammar (syntaxes/meshfox-marker.injection .json) highlights meshfox's own bookkeeping comments (<!-- meshfox:node id="..." ... -->, meshfox:edge, meshfox:var, meshfox:option, meshfox:tag-color, meshfox:output//meshfox:output, meshfox:comment//meshfox:comment) — the construct name as a keyword, each key="value"/bare-flag attribute per SPEC.md's own attr-list grammar. It reuses standard TextMate scope names (entity.other.attribute- name, string.quoted.double, keyword.control, ...) so it picks up whatever colors the user's current theme already assigns those, no custom theme needed. Ordinary code fences (```bash, etc.) already get embedded-language highlighting from VS Code's own bundled Markdown grammar with no help needed here.

Deliberately scoped to just the marker comments for now — a fenced runnable block's own trailing attributes (```bash name="..." deps="..." cache) aren't highlighted yet. Getting that right without risking the embedded-language highlighting inside the fence body (a real regression, worse than the current gap) needs live verification of exactly how VS Code's bundled Markdown grammar tokenizes a fence's opening line, which this repo's history is a good reminder not to guess at (see git log for the custom-editor bail-out that broke tab state — same lesson: TextMate/VS Code API interactions that look right on paper still need an actual F5 check before trusting them).

Keeping meshfox itself up to date

Once a day (throttled via globalState, not on every window), the extension checks GitHub's Releases API for a newer meshfox than the one meshfox.executablePath resolves to and — only for a release build (a v1.2.3-style version; a local/dev build has nothing to compare against, same as meshfox check-updates's own no-op case) — shows a toast with an Update button if one exists. Nothing is downloaded or installed by that check itself; clicking Update (or running the "meshfox: Check for Updates" command directly) asks for confirmation once more, then runs meshfox check-updates -y — the existing CLI command (self_update-based, downloads from the same GitHub releases) that actually replaces the binary, reused rather than reimplemented here.

If the configured executable can't be found at all (spawning it fails with ENOENT), an error notification offers Install — same as running the "meshfox: Install" command directly — which types the same install one-liner the root README documents into an integrated terminal, Enter left to you: never runs it on your behalf.

How it works

The extension acts as its own private coordinator (see src/coordinator.ts) — it binds a Unix socket, and for each file opened through either viewType spawns meshfox view <path> --port 0 --watcher-socket <that socket>. Once the worker reports its bound port over the socket, the editor tab's webview fetches that worker's own index.html and becomes it directly (src/canvasEditorProvider.ts/canvasHtml.ts) — not an <iframe> pointed at it. A <base href="http://127.0.0.1:<port>/"> injected into the fetched page's <head> makes every one of its root-absolute asset/fetch() references resolve against that server instead of the webview's own origin, so the app runs exactly as it does in a real browser tab, just hosted directly in the tab's own webview document. Closing the tab kills that worker; a "↗ open" link to another canvas inside the UI opens (or focuses) another VS Code tab the same way.

Being the webview's own top-level document means it's also subject to two things a real browser tab never has to deal with, both worked around in canvasAppHtml (canvasHtml.ts): the injected CSP needs 'wasm-unsafe- eval' on script-src (Shiki's default syntax-highlighting engine is WASM — without it, every code block quietly renders unhighlighted rather than erroring), and a small <style> reset undoes VS Code's own default webview stylesheet, which paints a background-color onto every bare <code> element (meant for a short inline `snippet` in a markdown-preview-style webview) — Shiki's <pre class="shiki"><code> wrapping means that paints over/behind a highlighted block's own intended background and washes out its colors otherwise.

This wasn't the original design — an earlier version did use an <iframe>, and copy/paste plus the right-click context menu silently didn't work inside it. That turned out to be a long-standing, still-open upstream VS Code limitation specific to a nested cross-origin iframe inside a webview, not to a webview's own top-level content (see microsoft/vscode#180234, #68799, #121580) — switching to loading the app as the webview's own document sidesteps the whole bug class rather than working around its symptoms. If anything still feels off compared to a real browser tab, the "meshfox: Open in Browser" command (also a button in the editor tab's own title bar) opens the exact same already-running worker in a real browser tab instead, which is never subject to any webview limitation at all.

Developing

cd editors/vscode
npm install

Press F5 (or Run → "Run meshfox extension") to launch an Extension Development Host with the extension loaded — this compiles automatically via the npm: compile pre-launch task. npm run watch recompiles on save if you'd rather keep a dev host open across edits (reload it with Cmd/Ctrl+R after each change instead of relaunching).

Building a local .vsix

For testing a dev build without waiting on a Marketplace release:

npx @vscode/vsce package

produces meshfox-vscode-<version>.vsix, installable with:

code --install-extension meshfox-vscode-<version>.vsix

or via the Extensions view → "..." → "Install from VSIX". vsce package needs no publisher account/token — that's only for actually publishing a new version to the Marketplace.
