MDC syntax highlight for Visual Studio Code

Provides syntax highlighting and colon (:) matching for MDC (Markdown Components) files, as well as document folding and format providers, along with component name and prop suggestions.

• Download VS Code extension

Best used with:

• Remark MDC
• Markdown It MDC

Or with Nuxt modules:

• Nuxt MDC
• Nuxt Content

Features

• Block Components
• Inline Components
• Span Text
• Attributes
• Document folding
• Formatting
• Component name and prop suggestions

Block Components

::card
---
icon: IconNuxt
title: A complex card.
---

Default slot

#description
  ::alert
    Description slot
  ::
::

Inline Components

:button-link[A button link]{.text-bold}
<!-- or -->
:button-link{.text-bold}[A button link]

Span Text

Hello [World]!

Attributes

Hello [World]{.text-primary-500}!

[Link](#link){.text-primary-500 ref="noopener"}!

**Bold Text**{style="color: tomato"}

`Inline Code`{style="background: [#333](https://github.com/nuxtlabs/vscode-mdc/issues/333)"}

_Italic Text_{#italic_text}

Document folding

The extension enables document code folding for MDC block components (and nested components). Simply hover over the gutter of the line you'd like to fold and click on the icon to expand or collapse the range.

Formatting

The plugin also enables a document format provider, disabled by default.

To globally configure document formatting in VS Code, search for mdc.enableFormatting in Settings.

Alternatively, to configure per-project, create or edit .vscode/settings.json in your project's root directory:

{
  // Required for the extension
  "mdc.enableFormatting": true,
  // Recommended (for `mdc` and `md`, depending on your usage)
  "[mdc]": {
    "editor.tabSize": 2,
    "editor.insertSpaces": true,
    "editor.detectIndentation": false,
    "editor.formatOnPaste": true
  }
}

[!Note] Since the format provider utilizes spaces for indention, you may also need to configure your project to insert spaces for tabs within .mdc or .md files as recommended above.

Component name and prop suggestions

The extension can provide intelligent auto-completion for MDC block components and their props by scanning your local project files or by fetching remote data when provided with an API URL in your VS Code settings.

When typing a colon (:) in your MDC document, the extension will suggest available component names. Within MDC component YAML front matter sections (between ---), the extension provides contextual prop suggestions (including nested props) with types and documentation where provided.

To enable component name and prop suggestions, enable the mdc.enableComponentMetadataCompletions setting in in VS Code, and configure the other settings as described below depending on your preferred component metadata source.

The extension supports two methods for providing component metadata:

• Local component metadata provided by the nuxt-component-meta module, or a static JSON file in your project.
• Remote component metadata provided by an API endpoint that returns JSON data.

Regardless of the method you choose, the data source must match one of the following formats:

1. The default format used by nuxt-component-meta

   • If your data source matches this format, it will automatically be transformed into the interface documented below.

2. A custom format that matches the following TypeScript interface:

   interface MDCComponentData {
     /** The kebab-case name of the markdown component */
     mdc_name: string
     /** Component description */
     description?: string
     /** Markdown-formatted documentation */
     documentation_markdown?: string
     /** URL to component documentation */
     docs_url?: string
     /** Component metadata interface from `nuxt-component-meta` */
     component_meta: {
       mode?: string;
       global?: boolean
       filePath?: string
       pascalName?: string
       kebabName?: string
       chunkName?: string
       fullPath?: string
       shortPath?: string
       meta: ComponentMeta; // import type { ComponentMeta } from 'vue-component-meta'
     }
   }

   type MDCMetadataResponse = MDCComponentData[]


Local component metadata

To enable local component metadata suggestions, you must first configure your project to provide component metadata in the format expected by the extension. You can do this by using the nuxt-component-meta module in your Nuxt project, or by providing a static JSON file that matches the interface described above.

To enable automatic discovery via nuxt-component-meta, follow these steps:

1. Follow the instructions to install nuxt-component-meta in your Nuxt project.

   • Add nuxt-component-meta dependency to your project:

     # Using PNPM
     pnpm add nuxt-component-meta

     # Using NPM
     npm install nuxt-component-meta


   • Add nuxt-component-meta to the modules section of your nuxt.config.ts and optionally configure the module:

     export default defineNuxtConfig({
       modules: ['nuxt-component-meta'],
       componentMeta: {
         // Options... see https://github.com/nuxtlabs/nuxt-component-meta
       }
     })


2. Once your project has been built or running on the dev server, the extension will automatically scan your project for component metadata and provide suggestions based on the components discovered with zero additional configuration.

Local component metadata options

mdc.componentMetadataLocalFilePattern

A glob pattern to the local MDC component metadata file. Defaults to: **/.nuxt/component-meta.mjs

mdc.componentMetadataLocalExcludePattern

A glob pattern to exclude directories from the local MDC component metadata search. Defaults to: {**/node_modules/**,**/dist/**,**/.output/**,**/.cache/**,**/.playground/**}

You may customize the local component metadata options per project by creating or editing .vscode/settings.json in your project's root directory with the desired setting. It utilize glob patterns to match the file or directories containing your component metadata from the root of the workspace:

{
  // Use a custom path to your component metadata file
  "mdc.componentMetadataLocalFilePattern": "path-to/your-static-file/component-metadata.json",
  // Or match a custom pattern
  "mdc.componentMetadataLocalFilePattern": "**/custom-component-metadata.json"
}

Remote component metadata

You can also choose to provide a URL to an API endpoint that returns component metadata in JSON format. The extension will fetch this data and provide suggestions based on the components found.

[!Note] A configured remote component metadata URL will take precedence over local metadata when both are available.

The endpoint provided to mdc.componentMetadataURL should return JSON data in one of the valid formats described above.

• To globally configure the metadata URL for your project, search for mdc.componentMetadataURL in VS Code Settings.
• To configure the metadata URL just for the scope of your active project, create or edit .vscode/settings.json in your project's root directory with the full URL to your API endpoint:

{
  // Use your remote API endpoint to fetch component metadata
  "mdc.componentMetadataURL": "https://example.com/api/my-components/mdc/metadata",
  // Or even utilize a locally running server
  "mdc.componentMetadataURL": "http://localhost:3000/api/component-meta"
}

The extension caches component metadata based on the the configurable TTL and provides a command MDC: Refresh component metadata to manually update the cache. To customize the cache TTL you may customize the value for mdc.componentMetadataCacheTTL in settings. Defaults to 30 minutes.

For more information

• MDC Syntax Reference

Running Extension Tests

To run the integration tests for this extension:

1. Install dependencies:

   pnpm install


2. Build the extension and run tests:

   pnpm test


This will compile the source and test files, then run the integration tests using VS Code's test runner.
