Universal Debugger AI

AI-powered multi-language debugging extension with advanced symbolic execution and path-sensitivity analysis for Visual Studio Code.

---

🌟 Features

🔍 Multi-Language Support

• Go: Full Delve debugger integration with advanced context analysis
• Python: Complete debugpy support with async/await analysis
• JavaScript/TypeScript: Node.js and browser debugging with closure analysis
• Automatic Detection: Seamlessly switches between languages based on debug session

🧠 Advanced AI Analysis

• Symbolic Execution: Analyze execution paths and constraints
• Path-Sensitivity Analysis: Track variable states across different execution paths
• Context-Aware Variable Expansion: Deep inspection of complex data structures
• Business Logic Detection: Automatically identifies application-relevant code

📊 Rich Debugging Context

• Enhanced Variable Analysis
• Execution Path Graphs
• Performance Metrics
• Memory Usage Tracking

🤖 AI Integration

• OpenAI GPT Support: GPT-3.5, GPT-4, and custom models
• Anthropic Claude Support
• Azure OpenAI Integration
• Custom Endpoints

---

🚀 Quick Start

Installation

From Marketplace:

ext install NandamYashwanth.go-debugger-ai

From VSIX:

1. Download latest .vsix from releases
2. Install via VS Code: Extensions > ... > Install from VSIX

Initial Setup

Configure AI Provider (optional):

{
  "contextSelector.llm.provider": "openai",
  "contextSelector.llm.openaiApiKey": "your-api-key-here",
  "contextSelector.llm.model": "gpt-4"
}

Enable Multi-Language Support:

{
  "universalDebugger.multiLanguage.enabled": true,
  "universalDebugger.multiLanguage.autoDetection": true
}

First Debug Session

1. Open project (Go, Python, JS, or TS)

2. Set breakpoints

3. Start debugging

4. Open Context Analyzer:

   • Command Palette: Universal Debug: Open Context Analyzer
   • Or use debug toolbar icon

---

📋 Language Support

🐹 Go

• Debugger: Delve
• Features: Goroutine analysis, pointer dereferencing
• Files: .go

🐍 Python

• Debugger: debugpy
• Features: Async/await analysis, module tracking
• Files: .py, .pyw

⚡ JavaScript/TypeScript

• Debugger: Node.js, Chrome
• Features: Closure & prototype chain analysis
• Files: .js, .ts, .mjs, .tsx, .cjs

---

🎛️ Configuration

Multi-Language

{
  "universalDebugger.multiLanguage.enabled": true,
  "universalDebugger.multiLanguage.autoDetection": true,
  "universalDebugger.variableAnalysis.maxDepth": 6,
  "universalDebugger.variableAnalysis.memoryLimitMB": 50
}

Language-Specific

{
  "goDebugger.variableAnalysis.maxVariableValueLength": 500,
  "goDebugger.variableAnalysis.enableTypeInference": true,
  "goDebugger.businessLogic.applicationPatterns": [
    "Handler)", "Controller)", "Service)", "Repository)",
    ".Get", ".Post", ".Put", ".Delete", ".Create", ".Update"
  ]
}

AI Provider

{
  "contextSelector.llm.provider": "openai",
  "contextSelector.llm.openaiApiKey": "sk-...",
  "contextSelector.llm.model": "gpt-4",
  "contextSelector.llm.temperature": 0.3,
  "contextSelector.llm.maxTokens": 4000
}

---

🎮 Commands

Command	Description
Universal Debug: Open Context Analyzer	Opens debugging context view
Universal Debug: Refresh Debug Context	Manually refresh context
Universal Debug: Show Execution Path Graph	Show execution flow
Universal Debug: Check Debugger Status	Show language + connection
Universal Debug: Export Debug Analysis	Save context data to file

---

📱 User Interface

Context Analyzer

• Variable Inspector
• Function Call Stack
• Execution Paths
• AI Analysis

Execution Path Graph

• Visual Flow
• Alternative Paths
• Risk Analysis
• Performance Metrics

---

🔧 Advanced Features

Variable Expansion

{
  "universalDebugger.languageSpecific.go.maxVariableDepth": 6,
  "universalDebugger.languageSpecific.python.maxVariableDepth": 4,
  "universalDebugger.languageSpecific.javascript.maxVariableDepth": 5,
  "universalDebugger.languageSpecific.javascript.analyzeClosures": true,
  "universalDebugger.languageSpecific.python.enableAsyncAnalysis": true
}

Symbolic Execution & Path Analysis

• Constraint Tracking
• Root Cause Analysis
• Conflict Detection
• Performance Monitoring

---

🎯 Use Cases

🐛 Bug Investigation

1. Set breakpoint
2. Start debug session
3. Open Context Analyzer
4. Inspect AI insights
5. Review alternative paths

🔍 Code Understanding

1. Set breakpoints in key functions
2. Debug with sample input
3. View Execution Path Graph
4. Export context data

⚡ Performance Analysis

1. Enable memory tracking
2. Set breakpoints
3. Monitor variable + execution cost

---

🤝 Language-Specific Examples

Go

func processUser(ctx context.Context, userID int64) (*User, error) {
    user, err := userRepo.GetByID(ctx, userID)
    if err != nil {
        return nil, fmt.Errorf("failed to get user: %w", err)
    }
    return user, nil
}

Python

async def process_data(data_source: str) -> Dict[str, Any]:
    async with aiohttp.ClientSession() as session:
        response = await session.get(data_source)
        data = await response.json()
        return data

JavaScript

function processApiResponse(response) {
    const { data, status, headers } = response;
    return data.map(item => ({ id: item.id, name: item.name, processed: true }));
}

---

🔧 Troubleshooting

Extension Not Activating

# Ensure session type is go, python, debugpy, node, chrome

Language Detection Issues

{
  "type": "go",
  "request": "launch",
  "program": "${workspaceFolder}"
}

AI Issues

• Verify API key
• Check connectivity
• Inspect output panel

Performance Tweaks

{
  "universalDebugger.variableAnalysis.maxDepth": 3,
  "universalDebugger.variableAnalysis.memoryLimitMB": 25
}

---

📊 Performance Metrics

• Collection Time
• Variable Count
• Memory Usage
• Symbolic Analysis Time
• Path Sensitivity Time
• Language

---

🛠️ Development

Build From Source

git clone https://github.com/yashwanthnandam/go-debugger-ai.git
cd go-debugger-ai/extension
npm install
npm run compile
npm run package

Contributing

1. Fork & branch
2. Develop & test
3. PR with description

Architecture

src/
├── extension.ts
├── detection/languageDetector.ts
├── factories/debuggerFactory.ts
├── languages/{go,python,javascript}Handler.ts
├── protocols/*Protocol.ts
├── services/{contextCollector,llmService,...}.ts
├── views/{contextSelectorView,executionPathGraphView}.ts

---

📚 API Documentation

LanguageHandler Interface

interface LanguageHandler {
  inferType(...): string;
  parseVariableValue(...): ParsedValue;
  extractFunctionName(...): string;
  isSystemVariable(...): boolean;
  isApplicationRelevant(...): boolean;
}

DebuggerProtocol Interface

interface DebuggerProtocol {
  attachToSession(...): void;
  getStackTrace(): Promise<DebugFrame[]>;
  getCurrentFrame(): Promise<DebugFrame | null>;
}

---

🔗 Links

• GitHub: go-debugger-ai
• VS Code Marketplace: Universal Debugger AI
• Issues: Report bugs / request features
• Discussions: Community forum

---

📜 License

MIT License – See LICENSE file

🙏 Acknowledgments

• VS Code Team
• Delve / Go Team
• Python debugpy
• OpenAI & Anthropic
• Community Contributors

---

📈 Changelog

v2.0.0 (2025-06-13)

• Multi-Language: Python, JS, TS
• Enhanced AI Context Analysis
• Universal Variable Inspection
• Performance & Speed Optimizations
• Seamless Language Switching

v1.0.4

• Symbolic Execution
• Path Sensitivity
• Deep Variable Expansion
• AI Code Analysis

---

Happy Debugging! 🐛➡️✨
