CodeDocX

Smart documentation assistant with AI chatbot and code visualization for VS Code.

Overview

CodeDocX addresses the critical documentation challenges in modern software development:

• Writing: Slow, repetitive, and often skipped
• Reading: Painful and time-consuming, especially for new team members
• Maintaining: Impractical in fast-changing systems — docs quickly become outdated

This leads to onboarding delays, wasted engineering time, and avoidable bugs due to poor documentation.

Our Solution - CodeDocX

CodeDocX is a powerful VS Code extension designed to enhance developer productivity by providing intelligent code analysis, documentation generation, and visualization capabilities. Whether you're working on a complex enterprise application or a simple project, CodeDoc helps you understand, document, and navigate your codebase more effectively.

Main Features

1. Project Overview

Automatically analyzes your Java project and displays a layered architecture visualization (Controllers, Services, Repositories, Entities, Others). Shows statistics, class cards, and quick navigation to source files.

2. Code Explaination (Documentation Generator)

Class Documentation Generator:

Generates detailed Markdown documentation for any Java class, including Spring context, responsibilities, method docs, usage examples, and relationships. Links to related classes and files are included.

Project Documentation Generator

Creates a comprehensive project overview document, including architecture diagrams, layer analysis, Spring patterns, class relationships, request lifecycle, and technology stack.

3. AI Assistant

An AI chatbot that acts as the assistant to answer user's questions for coding and provides onboarding help to guide new joiners understand the code base faster

4. Visualization

Generates Mermaid diagrams for class relationships, project architecture, and entity relationships to help users understand the code base with visualization

5. Stale Documentation Detector

Detect the staleness of the documentations when PR request is made and help users to update the stale docuemntation

User Guide

Getting Started

1. Install CodeDocs from the VS Code Marketplace.
2. Open a Java project in VS Code.
3. Configure the extension:
   • Open the command palette (Ctrl+Shift+P or F1).
   • Run CodeDoc: Configure Extension.
   • Enter your OpenAI API key, select the model, and set token/temperature (optional).
4. Click the CodeDoc icon in the sidebar to open the main view.

Supported Technologies

• Languages: Java
• Frameworks: Spring Boot

Development Setup

1. Clone the repository
2. Run npm install to install dependencies
3. Run npm run watch to start the TypeScript compiler in watch mode
4. Press F5 to launch the extension in a new VS Code window
5. Type codedoc.configureExtension in the command palette to configure the extension (input your OpenAI API key, select model, and set the max token and temperature(optional))
6. Open a Java project in VS Code and click the CodeDoc icon in the sidebar to start using the extension
