iSDA — Interactive Screen Design Aid

A VS Code extension that replaces IBM i's 5250 Screen Design Aid (STRSDA) with a modern, file-backed visual editor for DDS display files and SDA-style menus. Open the source, see it as a live 5250 screen, click and drag fields, edit their properties, and watch the changes written straight back into the original source. Everything you didn't touch stays byte-for-byte as it was.

• Screen designer for .dspf, .dspf38 and .dspf36 (System/36 environment) files.
• Menu designer for .mnudds menus and their paired MNUCMD command members.
• Keyword pickers modelled on real SDA's "Select/Define ___ Keywords" screens, with IBM's own DDS Reference rules (usage, conditioning, mutual exclusions) enforced.
• Works on local files and on remote IBM i members and IFS streamfiles through Code for i.

Requirements

• VS Code 1.85 or later.
• Optional: Code for i for remote sources, Compile, Resolve Referenced Field and + Fields from database file. Compile-related buttons are hidden while the "IBM i: Connected / Not connected / Not installed" badge isn't showing connected.

Getting started

npm install
npm run compile

Open the folder in VS Code and press F5 to launch an Extension Development Host, then use any of these commands (Command Palette, editor title bar, or Explorer right-click):

Settings

Features

DDS scopes keywords at three levels — file, record, field — and iSDA's pickers follow the same structure. The generic Keywords tab (free-text name and parameters) remains the catch-all for anything without a dedicated screen. Each keyword's level, usage and conditioning rules are checked against IBM's DDS Reference (see Project documentation).

File level

• All nine real-SDA "Select File Keywords" categories in one picker: General, Indicator, Print, Help, Display Sizes, DBCS Conversion, Alternate, Window Border, Menu-bar.
• Multiple DSPSIZ display sizes with a size switcher; MSGLOC per display size.
• Command keys (CAxx/CFxx) with correct DDS override semantics — a record may redefine a number used at file level, and different records may reuse a number independently.
• File-level comments with per-row source line numbers and insert-at-line.

Record level

• One Base Record Keywords picker (General, Indicator, Application Help, Help, Output, Input, Overlay, Print) reused across RECORD, SFLCTL, SFLMSGCTL, WINDOW, WNDSFCTL, PULLDOWN, PDNSFLCTL, MNUBAR and USRDFN.
• Subfiles as real SDA treats them: the paired control and detail records are each editable and previewable, with the row template repeating correctly. Message subfiles and the selection-list keywords SFLSNGCHC/SFLMLTCHC are covered too.
• WINDOW picker (size/roll, border parameters/colour/attributes/characters, restrict cursor, message line) with drag, resize and click-to-rename on the preview.
• PULLDOWN and MNUBAR pickers; pull-down and menu-bar choices render visually.
• Repeatable, independently-conditioned instances for keywords such as MNUBARDSP and HLPTITLE (up to 15), not just one flat value.
• Whole-record create, copy, delete and rename (with safe cross-reference rewriting), from a full SDA record-type list including subfile, window, pull-down and menu-bar starter templates.
• Record-type restrictions IBM documents (for example USRDFN, SFL and MNUBAR each allow only a closed keyword list) are enforced in the pickers and the raw keyword editor. On those three record types the Keywords tab shows only the rows that list allows; the rest are not offered at all (a hand-written one stays listed in Advanced / raw keywords).

Field level

• Base pickers for Display Attributes, Colours, Keying Options, Validity Check (RANGE/COMP/VALUES/CHECK/CHKMSGID), Input Keywords, General, Database Reference, Error Messages and Message ID — each showing the right subset for character, numeric, date/time, constant and menu-bar-choice fields, and for each Usage code.
• Multi-instance keywords: real DDS allows COLOR(RED) under indicator 10 and COLOR(GRN) under indicator 20 on one field; every relevant picker supports that instead of collapsing to one instance.
• Date/time formats (DATFMT/DATSEP/TIMFMT/TIMSEP), editing keywords (EDTCDE/EDTWRD/EDTMSK), CNTFLD, SFLSCROLL, HTML, and WRDWRAP with its mutual-exclusion rules enforced.
• Choice and push-button fields: menu-bar choices (MNUBARCHC, SNGCHCFLD, MLTCHCFLD, CHOICE, CHC*) and push-button fields (PSHBTNFLD/PSHBTNCHC, with a "Push button" field kind in the add-field panel and a layout-accurate preview).
• Constants with system values (*DATE, *TIME, *USER, *SYSTEM) and MSGCON.
• Resolve Referenced Field (and Resolve All) and bulk + Fields from database file — real SDA's F10 key — both through Code for i. Resolve loads the referenced field's length, type, decimals and inherited keywords (TEXT, ALIAS, CCSID, editing, date/time formats) into the designer as a read-only view without changing the DDS source, so a +n / -n length on a reference field keeps working. Fields added from a database file are written as bare reference fields (R + REFFLD, no length, type or decimals) so they inherit editing and validity checking too; their definitions load into the designer the same way, straight after the insert.

Canvas and editing

• Click-to-place, drag, arrow-key nudge (Shift+Arrow moves 5 cells), and Ctrl+D duplicate / Ctrl+X/C/V cut, copy and paste of a field's whole definition; a single duplicate or paste asks where to land it through the same click-to-place flow as the Copy button.
• Multi-field select (Shift/Ctrl-click or rubber-band) with block move, copy, delete and style, following real SDA's block-command convention.
• Overlap warning banner — real DDS silently drops an overlapping field; iSDA flags it.
• Ruler overlay (SDA's F14), crosshair position readout, and a dimmed compare mode that shows another record format behind the one being edited.
• Optional source modification tracking (see Settings).

UI styles

Both designers offer two styles, switched live with no reload:

• Classic — the original three-column layout: left panel, canvas, properties panel.
• New — a two-column layout with a floating toolbox over the canvas (+ Field, + Constant, + Add record, + Fields from database file, Window, Menu) and a pinned toolbar (Save, Compile, connection badge, Record and Screen-size selects, Find-field search, "Screen Design · N records" title) above a persistent View and UI Settings accordion zone.

Both share a Green / Amber / Cyan / Violet / White accent colour, matching ACS 5250's session colours. An explicit COLOR keyword on a field always wins over the accent.

Menu design (MNUDDS)

An SDA-style menu is two source members working together:

• The MNUDDS member is plain DDS — CRTMNU compiles it into a *DSPF — so it is parsed and rendered by the same parser and engine as the screen designer. Any constant shaped like '1. Do a thing' is treated as a menu option.
• The MNUCMD member (conventionally <menu>QQ, same source file and library) maps each option number to the command it runs. The menu designer edits it: pick an option, type the command, and it is written straight back.

MNUDDS opens from a remote member (member: scheme), a local .mnudds file (with a sibling <basename>QQ.mnucmd), or an IFS streamfile (streamfile: scheme, same sibling convention). Compile Menu runs CRTDSPF, updates the message file in place (ADDMSGD per option, falling back to CHGMSGD when it already exists; the USRnnnn message-ID format TYPE(*DSPF) menus expect is described in IBM's note on adding a menu option), then CRTMNU. Compiling always needs a real, connected IBM i member, however the menu was opened for editing.

Architecture

The parser is TypeScript, compiled twice — CommonJS for Node and tests, and an esbuild IIFE bundle for the webview. The engine, writer and menu engine are dependency-free plain JS so the exact same code runs in Node (tests) and in the webview.

Code for i is a soft dependency. Compile, Resolve Referenced Field and Add-fields-from-database call .runCommand() directly on the connection from instance.getConnection() rather than through the code-for-ibmi.runCommand VS Code command, which Code for i registers late and which could still be missing on an otherwise working connection.

Development

npm install
npm run compile     # regenerates the webview templates, src/fixtures/sample.dspf, and dist/
npm test            # pure-Node test scripts, no framework; UI tests run the real webview in jsdom
npx vsce package --no-dependencies   # build a .vsix

• Never edit src/webviewTemplate.ts or src/menuWebviewTemplate.ts — they are generated.
• Client-side JS in buildWebviewTemplate.js and buildMenuWebviewTemplate.js (and the helpers they embed) lives inside Node template literals: no backticks in comments or strings, or the generated template breaks silently. Run node -c <file> before compiling.
• npm test runs src/test/run.js, which discovers every src/test/*.test.js - a new test file needs no registration. Each file runs in its own process and the run continues past a failing file. node src/test/run.js i106 dspfWriter runs only files whose name contains an argument; --list lists them; --slow N shows the N slowest files in the summary.
• Every test file uses the shared check(label, condition) and failureCount() from src/test/helpers/harness.js; src/test/helpers/common.js has kwd, withAlertCapture, newWebviewDom and the cached webviewHtml. Don't copy them into a test file.
• Test output: ok - label per pass and FAIL - label per failure; count them with grep -c "^ ok -" and grep -n "^FAIL -" (a test's own description text can contain "fail").
• See vsc-extension-quickstart.md for the general extension dev loop.

Project documentation

Status: early but functional. The parser, resolver and editor are verified against IBM's published DDS examples and round-trip tested (edit → regenerate source → re-parse → confirm nothing else changed). All tracked L, M, P and S36- tasks and all picker screens are done. The keyword audit is ongoing; its status table and open-work list in keywordFixes.md are the place to see what remains.

License

MIT — see LICENSE.
