Claude Code GUI
See Claude Code think, plan, and operate — live inside VS Code.
Why •
Highlights •
Quick Start •
Modes & Controls •
Configuration •
Development
Why this exists
Claude Code CLI is powerful, but most of its work happens invisibly in a terminal. Claude Code GUI turns the CLI into a visual cockpit: you can watch tool calls, diffs, token usage, and progress in real time without leaving VS Code.
If you’ve ever wanted to see the work, not just the answer, this is for you.
Highlights
- Journey Timeline — messages, tool calls, and results grouped into a readable, collapsible flow.
- Tool intelligence — per-tool duration and token counts with structured inputs and rich outputs.
- Diff-first edits — inline diffs, open-in-VS Code diff, and one-click revert.
- Live progress —
TodoWrite steps render into a task panel while Claude works.
- Usage cockpit — header meter + detailed modal for session and weekly usage/reset times.
- Permission control — allow/deny tool requests, Plan mode (read-only), YOLO mode (skip prompts).
- MCP hub — preseeded servers (Chrome, Context7, Sequential Thinking, Memory, Puppeteer, Fetch, Filesystem) with toggle/add/remove.
- Conversation history — automatic saving, search, restore, delete.
- Sidebar + editor panel — open the chat where you like.
How it works
- Extension host spawns
claude with --output-format stream-json.
- CLI events stream into the webview via
postMessage.
- React UI renders streaming output, tool cards, diffs, usage, and history.
Quick Start
Prerequisites
npm install -g @anthropic-ai/claude-code
claude auth login
Requires VS Code 1.94+. The extension expects claude on your PATH.
Open the chat
Cmd+Shift+C (macOS) / Ctrl+Shift+C (Windows/Linux)- Command Palette → "Open Claude Code GUI"
- Activity Bar → Claude icon
First message
- Type a prompt.
- Press Enter to send.
- Watch the timeline fill in as Claude works.
Modes & Controls
- Model selector — Sonnet 4.5 (default), Opus 4.5, Haiku 4.5.
- Thinking mode — Think → Ultrathink for deeper reasoning.
- Plan mode — read-only tool permissions (safe analysis).
- YOLO mode — skip permission prompts (use with caution).
Configuration
Settings live under Claude Code GUI in VS Code.
| Setting |
Default |
Description |
claudeCodeGui.claude.model |
claude-sonnet-4-5-20250929 |
Default Claude model |
claudeCodeGui.thinking.enabled |
true |
Enable thinking mode |
claudeCodeGui.thinking.intensity |
think |
Thinking intensity |
claudeCodeGui.permissions.yoloMode |
false |
Skip permission prompts |
Development
Setup
git clone https://github.com/MaheshKok/claude-code-gui-vscode.git
cd claude-code-gui-vscode
npm install
Build & watch
npm run build
npm run dev
npm run dev uses Bun for the watch scripts. Install Bun or run the individual watch:* scripts.
Available Commands
| Command |
Description |
npm run build |
Build for production |
npm run dev |
Watch mode |
npm run lint |
Run ESLint |
npm run typecheck |
TypeScript check |
npm run test |
Run tests |
npm run package |
Create .vsix file |
Contributing
Contributions are welcome!
- Fork the repository
- Create a feature branch (
git checkout -b feature/amazing)
- Commit your changes (
git commit -m 'Add amazing feature')
- Push to the branch (
git push origin feature/amazing)
- Open a Pull Request
Code Standards
- TypeScript for all code
- ESLint + Prettier formatting
- Tests for new features
- Descriptive commit messages
License
This project is licensed under the MIT License — see LICENSE.
Made with ❤️ by Mahesh Kokare
