What is it?

Pretty XML is an XML formatter extension for Visual Studio Code and VSCodium. It formats XML documents using the same formatting style as Visual Studio on Windows.

Supported file extensions:

• xml
• xaml
• axml
• xsd
• xsl
• plist
• mobileconfig
• config
• csproj
• svg
• resx and all other XML-type files

A Visual Studio for Mac version of this extension is also available. Check it out at PrettyXML.VSMac

Suggestions and improvement pull requests are welcome.

Features

1. Prettify XML (XML Formatting)

Right-click and select "Prettify XML" or use the keyboard shortcut.

• Positions each attribute on a separate line
• First attribute on the same line as the element start tag
• All attributes indented, aligned with the first attribute
• If an element has no children, closes with an inline end tag
• No empty lines
• Supports ' and whitespace Unicode characters in attribute values for XAML parser compatibility

1.a. Format Entire Document

• Formats the entire valid XML document

1.b. Format Selection - Beta

• Formats a portion of an XML document. The XML can be partial and invalid. This feature is in beta, so feel free to submit pull requests with improvements.

Before

After

2. Pretty XML: Minimize

Minimizes XML documents.

Keyboard Shortcuts

Note

You can change these shortcuts in Preferences → Keyboard Shortcuts if desired.

Settings

These settings apply to the Prettify XML command.

Attributes In Newline Threshold

Example:

Value = 2

Input #1

<Element Attribute1="Value1" Attribute2="Value2" />

Output #1

<Element Attribute1="Value1" Attribute2="Value2" />

Input #2

<Element Attribute1="Value1" Attribute2="Value2" Attribute3="Value3" />

Output #2

<Element Attribute1="Value1"
         Attribute2="Value2"
         Attribute3="Value3"/>

Wild Carded Exceptions For Position All Attributes On First Line

List of element names to ignore the "Position All Attributes On First Line" setting. Include element names or patterns here.

Example:

 "prettyxml.settings.wildCardedExceptionsForPositionAllAttributesOnFirstLine": ["Content*"]

Input

<View>
    <Content X="X"
             Y="Y" Z="Z">
        <Label text="{i18>LabelText}" />
        <Input id="Input1"
               value="{service>description}" />
    </Content>
</View>

Output

<View>
    <Content X="X"
             Y="Y"
             Z="Z">
        <Label text="{i18>LabelText}" />
        <Input id="Input1" value="{service>description}" />
    </Content>
</View>

Add Empty Line Between Elements

If enabled, and the child elements count is greater than 2, adds an empty line between elements.

[!NOTE]
Please note: it will not add an empty line before the first element or after the last element.

Input 1

<Root>
<Element1>Text1</Element1>
<Element2>Text2</Element2>
<Element3>Text3</Element3>
</Root>

Output 1

<Root>
    <Element1>Text1</Element1>

    <Element2>Text2</Element2>

    <Element3>Text3</Element3>
</Root>

Add Xml Declaration If Missing

Adds XML declaration <?xml version="1.0" encoding="utf-8"?> if missing.
Default is true.

Requirements

• .NET 8 or later installed on your machine and accessible through the terminal
• Install the Muhammad-Sammy C# or Microsoft C# extension
• Visual Studio Code/VSCodium 1.59 or higher

Installation

Visual Studio Code - Visual Studio Marketplace

VSCodium - open-vsx.org

Known Issues

• Limited DTD support
• Formats valid XML files only. Syntax errors are displayed

Issues can be reported in the issues section

For more information

• Source Code
• If you want to support this project,
