jlink-mcp

Give AI hands to touch silicon.
An MCP server that lets LLMs debug embedded devices through SEGGER J-Link probes.

See it work

A terminal session: the MCP server finds the probe, flashes firmware, opens a debug session, streams RTT logs, injects a fault, and decodes the resulting HardFault — naming the faulting instruction.

Real MCP tool calls against a real nRF52840-DK. Reproduce it yourself: npm run demo

Your firmware just crashed. One tool call:

> diagnose_crash

## Crash Diagnosis

### CPU State
Core: PC=0x000000B8 SP=0x2003FFA8 R0=0x0000000A R1=0x000007FF R2=0x00000001 ...
Status: XPSR=0x21000003 CONTROL=0x00000000 PRIMASK=0x00000000 ...
Stack: MSP=0x2003FFA8 PSP=0x00000000

⚠ CPU is in exception handler (IPSR=0x00000003)

### Fault Registers
CFSR=0x01000000 HFSR=0x40000000 DFSR=0x00000000 MMFAR=0xe000edf8 BFAR=0xe000edf8

### Decoded Faults
## UsageFault (UFSR):
  - UNALIGNED: Unaligned memory access
## HardFault (HFSR):
  - FORCED: Forced HardFault (escalated from configurable fault)

### Exception Stack Frame
  R0    = 0x0000000A     R1  = 0x000007FF
  R12   = 0x00000000     LR  = 0x000001F5
  PC    = 0x00000254     xPSR = 0x21000000

→ Faulting instruction at PC=0x00000254

### Recent Errors/Warnings from RTT
  [WRN] sensor_drv: sample out of range, clamping seq=2

Fault decoded, exception frame unwound, faulting instruction named, and the device's own log correlated — from one call, without a human reading a datasheet to find out what bit 24 of CFSR means.

Verbatim output from an nRF52840-DK in this project's hardware test suite.

What is this?

jlink-mcp connects AI assistants (Claude, Copilot, etc.) to your embedded hardware via SEGGER J-Link debug probes using the Model Context Protocol.

Instead of manually typing J-Link commands, your AI assistant can:

Read registers and memory to understand device state
Flash firmware and reset devices
Stream RTT logs and search them by level/module/regex
Diagnose crashes by auto-decoding ARM Cortex-M fault registers
Control execution — halt, step, resume, breakpoints
Start GDB servers for full debugging sessions

Also supports OpenOCD (ST-Link, CMSIS-DAP, FTDI) and Black Magic Probe backends.

Quick Start

Claude Desktop

Add to your Claude Desktop config (~/Library/Application Support/Claude/claude_desktop_config.json):

{
  "mcpServers": {
    "jlink": {
      "command": "node",
      "args": ["/path/to/jlink-mcp/out/mcp/standalone.js"],
      "env": {
        "JLINK_DEVICE": "nRF52840_XXAA"
      }
    }
  }
}

Claude Code

Add .mcp.json to your project root:

{
  "mcpServers": {
    "jlink": {
      "command": "node",
      "args": ["out/mcp/standalone.js"],
      "cwd": "/path/to/jlink-mcp",
      "env": {
        "JLINK_DEVICE": "nRF52840_XXAA"
      }
    }
  }
}

VSCode Extension

Install the extension (requires VSCode 1.110+, matching engines.vscode). It auto-registers the MCP server via the native vscode.lm API. Configure the device in settings:

jlinkMcp.jlink.device = "nRF52840_XXAA"

Copilot Chat and Claude in VSCode will automatically discover all 31 tools.

From Source

git clone https://github.com/Klievan/jlink-mcp.git
cd jlink-mcp
npm install
npm run compile
JLINK_DEVICE=nRF52840_XXAA node out/mcp/standalone.js

Tools (39)

Workflow Tools (start here)

Tool	Description
`start_debug_session`	One-call setup. Starts GDB server + connects RTT + returns boot log.
`snapshot`	Captures full device state: registers, fault status, stack dump, RTT output.
`diagnose_crash`	Auto-reads and decodes ARM Cortex-M fault registers (CFSR, HFSR, MMFAR, BFAR) with exception stack frame.

Device Setup

Tool	Description
`list_devices`	Scan for connected probes and show the configured target
`set_device`	Change the target device at runtime — no restart needed
`get_config`	Current probe, target device, and GDB server state

Device Control

Tool	Description
`device_info`	Probe type, target CPU, compact register summary
`halt`	Halt CPU
`resume`	Resume CPU
`reset`	Reset device (optionally halt after reset)
`step`	Single-step one instruction

Memory & Registers

Tool	Description
`read_memory`	Read memory at address (clean hex dump output)
`write_memory`	Write 32-bit value to address
`read_registers`	All CPU registers in compact format
`read_register`	Read specific register (PC, SP, R0-R12, etc.)

Flash

Tool	Description
`flash`	Flash .hex/.bin/.elf firmware to device
`erase`	Erase entire flash

Breakpoints

Tool	Description
`set_breakpoint`	Set hardware breakpoint at address
`clear_breakpoints`	Clear all breakpoints

GDB Server

Tool	Description
`gdb_server_start`	Start probe's GDB server
`gdb_server_stop`	Stop GDB server + disconnect RTT
`gdb_server_status`	GDB server, RTT, and proxy status

Source-Level Debugging

Attach a real GDB client for symbol-aware work — backtraces, variable inspection, and stepping by source line rather than by instruction.

Tool	Description
`gdb_connect`	Attach a GDB client (auto-starts the server; optional ELF for symbols)
`gdb_load`	Load an ELF for debug symbols, optionally flashing it too
`gdb_backtrace`	Call stack, optionally with locals in each frame
`gdb_command`	Run any GDB command — `print sensor_state`, `info threads`, `break main`
`gdb_wait`	Wait for the target to stop (after a continue or a breakpoint)
`gdb_disconnect`	Detach the client, clearing breakpoints and debug hardware

RTT (Real-Time Transfer)

Tool	Description
`rtt_connect`	Connect to RTT telnet port
`rtt_disconnect`	Disconnect from RTT
`rtt_read`	Read recent log lines (ANSI stripped, Zephyr format parsed)
`rtt_search`	Filter logs by level (`err`/`wrn`/`inf`/`dbg`), module, or regex
`rtt_send`	Send data to device via RTT down-channel
`rtt_clear`	Clear RTT buffer

Telnet Proxy (Trice / Pigweed)

Tool	Description
`telnet_proxy_start`	Start TCP proxy that tees RTT for external detokenizers
`telnet_proxy_stop`	Stop proxy
`telnet_proxy_status`	Proxy connection status
`telnet_proxy_read`	Read raw proxy buffer

Advanced

Tool	Description
`probe_command`	Execute raw probe commands
`get_config`	Current probe and server configuration

Multi-Probe Support

jlink-mcp supports multiple debug probe backends through a common ProbeBackend abstraction:

Backend	Probe Hardware	Status	RTT Support
J-Link	SEGGER J-Link, J-Link OB, J-Link EDU	Production	Yes
OpenOCD	ST-Link, CMSIS-DAP, FTDI, J-Link (via OpenOCD)	Beta	No
Black Magic Probe	BMP (built-in GDB server on serial)	Beta	No
probe-rs	All probe-rs supported probes	Planned	Planned

Selecting a Backend

# J-Link (default)
PROBE_TYPE=jlink JLINK_DEVICE=nRF52840_XXAA node out/mcp/standalone.js

# OpenOCD with ST-Link
PROBE_TYPE=openocd \
  OPENOCD_INTERFACE=interface/stlink.cfg \
  OPENOCD_TARGET=target/stm32f4x.cfg \
  node out/mcp/standalone.js

# Black Magic Probe
PROBE_TYPE=blackmagic \
  BMP_SERIAL_PORT=/dev/ttyACM0 \
  node out/mcp/standalone.js

Architecture

┌─────────────────────────────────────────────────────┐
│                    MCP Client                        │
│          (Claude, Copilot, any MCP client)           │
└──────────────────────┬──────────────────────────────┘
                       │ JSON-RPC over stdio
┌──────────────────────▼──────────────────────────────┐
│                  jlink-mcp                           │
│                                                      │
│  ┌──────────┐  ┌──────────┐  ┌───────────────────┐  │
│  │ 31 Tools │  │4 Resources│  │    4 Prompts      │  │
│  └────┬─────┘  └────┬─────┘  └───────┬───────────┘  │
│       │              │                │              │
│  ┌────▼──────────────▼────────────────▼───────────┐  │
│  │              ProbeBackend                       │  │
│  │  ┌─────────┐ ┌─────────┐ ┌──────────────────┐  │  │
│  │  │ J-Link  │ │ OpenOCD │ │ Black Magic Probe│  │  │
│  │  └────┬────┘ └────┬────┘ └────────┬─────────┘  │  │
│  └───────┼───────────┼───────────────┼─────────────┘  │
│          │           │               │              │
│  ┌───────▼───┐ ┌─────▼────┐ ┌───────▼──────────┐  │
│  │ RTTClient │ │TelnetProxy│ │  ProcessManager  │  │
│  └───────────┘ └──────────┘ └──────────────────┘  │
└─────────────────────────────────────────────────────┘
                       │
          ┌────────────▼────────────┐
          │    Debug Probe (USB)    │
          │  → Target MCU (SWD/JTAG)│
          └─────────────────────────┘

Source Layout

src/
├── probe/
│   ├── backend.ts      # ProbeBackend abstract class + shared utilities
│   ├── jlink.ts        # SEGGER J-Link implementation
│   ├── openocd.ts      # OpenOCD implementation
│   ├── blackmagic.ts   # Black Magic Probe implementation
│   └── factory.ts      # Probe creation from config
├── mcp/
│   ├── server.ts       # MCP server (31 tools, 4 resources, 4 prompts)
│   └── standalone.ts   # Standalone entry (stdio transport)
├── rtt/
│   └── rtt-client.ts   # RTT client with ANSI stripping + Zephyr log parsing
├── telnet/
│   └── telnet-proxy.ts # TCP proxy for Trice/Pigweed detokenizer
├── utils/
│   ├── config.ts       # VSCode settings / env var config
│   ├── logger.ts       # Logging
│   └── process-manager.ts # Child process lifecycle
└── extension.ts        # VSCode extension + MCP provider registration

Design Decisions (LLM-Optimized)

This server was built by having an AI use it against real hardware, then fixing every friction point.

What `read_registers` would give you

Raw JLinkExe output for halt; regs — 77 lines, of which about six carry information. Every token here costs context, and the register values are buried in the middle:

SEGGER J-Link Commander V9.70 (Compiled Aug 19 2026 12:16:13)
DLL version V9.70, compiled Aug 19 2026 12:15:25
Connecting to J-Link ...O.K.
Firmware: J-Link OB-nRF5340-NordicSemi compiled Jun 11 2026 13:12:28
Hardware version: V1.00
J-Link uptime (since boot): 0d 00h 34m 29s
S/N: 1050298247
License(s): RDI, FlashBP, FlashDL, JFlash, GDB
...30 more lines of connect banner...
PC = 00000044, CycleCnt = 00EB67E5
R0 = 20000000, R1 = 9D56C547, R2 = 00000000, R3 = 00000000
...
FPS0 = 00000000, FPS1 = 00000000, FPS2 = 00000000, FPS3 = 00000000
...28 more lines of zeroed FP registers...

What it actually gives you

Three lines. Same information, grouped by what you would ask for:

Core: PC=0x00000046 SP=0x20010000 R0=0x20000000 R1=0x01D43416 R2=0x00000000 ...
Status: XPSR=0x01000000 CONTROL=0x00000000 PRIMASK=0x00000000 BASEPRI=0x00000000
Stack: MSP=0x20010000 PSP=0x00000000

Both captured from the same board. The rest of the design follows the same rule — return what was asked for, and nothing else:

Output parsing strips the connection banner. Only data comes back.
Registers are compact and grouped (core / status / stack).
FP registers only shown if non-zero (they're usually all zeros).
RTT output has ANSI escape codes stripped and Zephyr log format parsed into structured fields.
Composite tools (start_debug_session, snapshot, diagnose_crash) replace multi-step workflows with single calls.
Fault decoding is automatic — reads CFSR/HFSR/MMFAR/BFAR and explains each bit.
rtt_search lets you find errors without reading the entire log.

Verified on real hardware

Most of what can go wrong between an LLM and a debug probe fails quietly: a tool returns success with an empty payload, a parser drops half a line, a session dies and the next command reports something plausible instead. None of that is visible from reading the code, and a test suite that asserts "the call did not error" passes on all of it.

So this project runs a hardware tier: 58 tests against a real nRF52840-DK on a self-hosted runner, driving the actual MCP server over stdio exactly as a client would. It covers probe discovery, flash and verify, halt/step/resume under a live GDB session, memory and peripheral reads, RTT streaming and filtering, and crash diagnosis against faults injected on demand.

It has caught bugs that had been shipping green, including:

diagnose_crash reporting "No faults detected" during real crashes — the memory-dump parser was dropping half of every line
every GDB-routed tool returning empty output while the server reported itself healthy
sessions leaving the target unbootable, with breakpoint comparators still armed that no reset clears

Raw probe output captured during those runs is committed as golden transcripts, so a fast unit tier replays real device bytes in seconds on any machine — no probe required to catch a format regression.

npm test          # ~190 tests, seconds, no hardware
npm run test:hil  # hardware tier; needs HIL=1 and a probe

Environment Variables

J-Link

Variable	Default	Description
`PROBE_TYPE`	`jlink`	Probe backend: `jlink`, `openocd`, `blackmagic`
`JLINK_DEVICE`	`Unspecified`	Target device (e.g., `nRF52840_XXAA`, `STM32F407VG`)
`JLINK_INSTALL_DIR`	Auto-detect	Path to SEGGER J-Link installation
`JLINK_INTERFACE`	`SWD`	Debug interface: `SWD` or `JTAG`
`JLINK_SPEED`	`4000`	Connection speed in kHz
`JLINK_SERIAL`		J-Link serial number (multi-probe)
`JLINK_GDB_PORT`	`2331`	GDB server port
`JLINK_RTT_PORT`	`19021`	RTT telnet port

OpenOCD

Variable	Default	Description
`OPENOCD_BINARY`	`openocd`	Path to openocd binary
`OPENOCD_INTERFACE`	`interface/stlink.cfg`	Interface config file
`OPENOCD_TARGET`	`target/stm32f4x.cfg`	Target config file
`OPENOCD_GDB_PORT`	`3333`	GDB server port
`OPENOCD_TELNET_PORT`	`4444`	Telnet command port

Black Magic Probe

Variable	Default	Description
`BMP_GDB_PATH`	`arm-none-eabi-gdb`	Path to GDB binary
`BMP_SERIAL_PORT`	`/dev/ttyACM0`	BMP serial port
`BMP_TARGET_INDEX`	`1`	Target index after scan

Prerequisites

SEGGER J-Link Software installed (JLinkExe, JLinkGDBServer)
A J-Link debug probe connected to an ARM Cortex-M target
Node.js 18+

For other backends: OpenOCD or arm-none-eabi-gdb as appropriate.

Contributing

Adding a new probe backend:

Create src/probe/yourprobe.ts implementing ProbeBackend
Add a case to src/probe/factory.ts
That's it — all 31 MCP tools work automatically

License

MIT - see LICENSE

Built by The Sprk Factory

jlink-mcp

Klievan

jlink-mcp

See it work

What is this?

Quick Start

Claude Desktop

Claude Code

VSCode Extension

From Source

Tools (39)

Workflow Tools (start here)

Device Setup

Device Control

Memory & Registers

Flash

Breakpoints

GDB Server

Source-Level Debugging

RTT (Real-Time Transfer)

Telnet Proxy (Trice / Pigweed)

Advanced

Multi-Probe Support

Selecting a Backend

Architecture

Source Layout

Design Decisions (LLM-Optimized)

What read_registers would give you

What it actually gives you

Verified on real hardware

Environment Variables

J-Link

OpenOCD

Black Magic Probe

Prerequisites

Contributing

License

What `read_registers` would give you
