SchemaSight

Chat with your database. Locally.

Understand any database, instantly — local AI, no cloud, no data leaves your machine.

SchemaSight is a VS Code extension for developers who need to make sense of unfamiliar or legacy databases. Connect to SQL Server, PostgreSQL, or MySQL, index schema objects locally, and ask grounded questions about tables, views, stored procedures, functions, and business logic without leaving your editor.

Why SchemaSight

Developers lose hours reading database schemas, stored procedures, and scattered business logic just to answer questions like:

• What does this procedure do?
• Where is row-level security applied?
• What tables are involved in invoicing?
• What is this database about?

SchemaSight helps you answer those questions from the indexed schema itself, with local retrieval and local LLM generation.

What It Is

• A local-first database comprehension copilot for VS Code
• Built for schema exploration and stored-code understanding
• Best for onboarding, maintenance, audits, and legacy-database discovery

What It Is Not

• Not a live SQL execution tool
• Not a row-level data exploration or BI tool
• Not a database performance tuning or query-plan analyzer

Supported Databases

• SQL Server
• PostgreSQL
• MySQL

Core Features

• Add and manage database connections in the VS Code sidebar
• Guided onboarding flow with Ollama verification, model pull, and schema crawl in one place
• Change your chat model at any time via the model settings panel — pull and re-index without leaving VS Code
• Crawl and index tables, views, stored procedures, and functions
• Use local embeddings and local Ollama models for grounded Q&A
• Ask follow-up questions like “can you explain it?” with object resolution
• Inspect how answers were produced through context and retrieval visibility
• View index status and quality details for each connection

Local-First By Design

SchemaSight is designed for teams that cannot or do not want schema understanding workflows to depend on a cloud service.

• Retrieval and answer generation run on your machine via Ollama
• Embeddings run locally via Transformers.js (all-MiniLM-L6-v2) — no external embedding API required
• Credentials are stored using VS Code secret storage
• The extension works from schema metadata and object definitions, not uploaded app code

Screenshot

Onboarding

Chat

Quick Start

For users

1. Install and start Ollama.
2. Open SchemaSight from the VS Code sidebar or run SchemaSight: Open Panel.
3. Add a database connection.
4. Follow the onboarding flow — verify Ollama, pull your model, and crawl the schema all from within the extension.

   Note: Initial indexing summarizes every schema object using a local LLM. On an Apple M5 16GB with ~95 objects, this takes approximately 15–20 minutes. Older hardware will take longer. This is a one-time cost — re-indexing is only needed when your schema changes or you switch models.

5. Ask questions in plain English about your schema, tables, stored procedures, and business logic.

Example questions

• What is this database about?
• What tables are related to orders?
• Is there logic to remove row-level security?
• Explain example_store_procedure in detail.
• What does this stored procedure update?

Architecture Overview

SchemaSight uses a layered architecture with clear separation of concerns:

The extension host uses dependency injection: extension.ts constructs repositories and services and passes a single Services object into PanelManager and then MessageRouter. Handlers receive only the repositories and services they need. The webview and extension communicate via a message-based API defined in shared/types.ts (no shared runtime beyond postMessage).

System Architecture

User actions go from the webview over postMessage into the extension host, then down through handlers → services → repositories to external systems. The table above lists the components in each layer.

Frontend Flow

The frontend is a single React app mounted in the panel and sidebar webview. App.tsx coordinates three main hooks:

• useConnections() — Connection list, add/remove/test, crawl status, crawled-connection ids, index stats
• useChat() — Per-connection chat state, streaming tokens, thinking steps, summary persistence
• useOllamaStatus() — Ollama availability, selected model, model-pulled state, pull progress

UI journey:

1. Add or select a connection in the sidebar
2. Ensure Ollama and model are ready
3. Crawl and index the schema (progress via CRAWL_PROGRESS messages)
4. Ask questions in chat; inspect “How this was answered” for retrieval and context

Crawl And Index Flow

During indexing:

1. ConnectionRepository supplies config and password; SchemaRepository calls the appropriate DB driver and returns a DatabaseSchema (tables, views, procedures, functions).
2. Indexer builds one SchemaChunk per object, summarizes each with OllamaRepository, embeds summaries locally via Transformers.js (all-MiniLM-L6-v2) through EmbeddingRepository, then ChunkRepository upserts into LanceDB with vector and FTS indexes.

Chat And RAG Flow

At a high level:

1. ChatHandler resolves connection and context limit, then delegates retrieval to RagPipelineService.
2. RagPipelineService calls QueryClassifier to classify the query as broad, semantic, or detail. For broad queries it fetches all chunks; for semantic it may rewrite the question via OllamaRepository, embeds the query via EmbeddingRepository, and runs hybrid search via ChunkRepository.
3. For "explain that" / detail requests, it resolves referred chunks (from context or findByName) and injects full definitions into the system prompt.
4. PromptBuilder builds the RAG system prompt; RagPipelineService may summarize older conversation when near the model context limit.
5. OllamaRepository streams the chat response; ChatHandler posts CHAT_CHUNK, CHAT_THINKING, and CHAT_DONE back to the webview.

Why The Architecture Matters

• Separation of concerns — Repositories own data and external APIs; services own orchestration and rules; handlers own request/response only.
• Testability — Repositories and services can be unit-tested with mocks; the message contract in shared/types.ts is the single bridge between webview and extension.
• Local-first — Retrieval, embeddings, and generation stay on the machine; credentials in VS Code SecretStorage.
• Transparency — "How this was answered" is backed by real pipeline stages (search, context, model) exposed via CHAT_THINKING.

Trust And Boundaries

SchemaSight aims to be useful and transparent, but it should be treated like an assistant for understanding database structure and logic, not as an authoritative execution engine.

• It answers from retrieved schema context and object definitions
• It works best when the relevant tables, procedures, or functions are present in the index
• Broad architectural answers are inferred from indexed object names and summaries
• Changing the Ollama model requires re-indexing for consistent results

Installation

From Marketplace

Install SchemaSight from the VS Code Marketplace.

From source

npm install
npm run build

Then open the repo in VS Code and press F5 to launch the Extension Development Host.

Model Notes

• Recommended model: llama3.1:8b
• Smaller models may index faster but can reduce answer quality
• llama3.1:8b may struggle to summarize stored procedures exceeding ~20,000 characters. If your database has large, complex procedures, consider a stronger model such as llama3.1:70b or qwen2.5:32b for better indexing quality
• To change your model after onboarding, use the model settings option in the panel — pull the new model and re-index your connection for changes to take effect.

Development

Project structure:

License

MIT — see LICENSE for details.
