VHDL Essentials

The only VS Code extension that reads your Quartus project: build, flash, simulate, fit reports, pin-aware diagnostics and VHDL intelligence in one.

Why this extension

Most VHDL extensions stop at language support. VHDL Essentials is the only one that understands your Quartus project end to end:

• Build and flash from the editor — run Quartus flows and program your device without leaving VS Code
• Fit reports in the tree view — resource utilization (logic elements, pins, registers, PLLs, memory bits) parsed from .fit.summary after every build
• Pin-aware diagnostics — top-level ports are checked against QSF pin assignments, and hover shows the assigned FPGA pin
• QuestaSim/ModelSim integration — generate .do scripts, launch simulations and stream the transcript live
• QSF project explorer and linting — device, top-level entity, pin assignments, plus duplicate and unknown-command checks
• Full VHDL intelligence — go-to-definition, hover, rename, find references, signature help, outline, completion and a configurable formatter

Quick Start

1. Install the extension
2. Set maxv.quartusPath in your VS Code settings:

   { "maxv.quartusPath": "C:\\intelFPGA\\25.1std" }


3. Open a .qpf project file and press Build

Gallery

Features

Quartus Integration

• Build — compile your project with Quartus: Build, errors mapped back to source files
• Flash — program your FPGA via JTAG with Quartus: Flash
• New Project — scaffold a full Quartus project (QPF, QSF, entity, testbench, DO) with Quartus: New Project
• Project Explorer — tree view showing device, top-level entity, pin assignments, resource utilization, testbenches, and simulation scripts

VHDL Intelligence

• Go-to-definition for entities, packages, and symbols across workspace
• Hover showing port signatures, types, and pin assignments
• Autocomplete for keywords, entity names, package symbols, and local signals
• Rename (F2) workspace-wide for entities, signals, variables, constants, ports
• Find all references across all VHDL files
• Signature help inside port map(...) clauses
• Document symbols for outline view and breadcrumbs
• Semantic highlighting with entity/package/unused signal awareness
• Formatter (Shift+Alt+F) with configurable indentation

Linting & Diagnostics

• Syntax checking — unclosed scopes, mismatched end, missing begin, unbalanced parentheses
• Unused signals — flags declared but never referenced signals, variables, constants
• Undeclared identifiers — flags identifiers that are not declared anywhere
• Sensitivity list — detects missing/unnecessary signals in combinational processes
• Port map validation — checks port map associations against entity declarations
• Pin diagnostics — warns when top-level ports have no pin assignment in QSF
• Package body — detects functions/procedures declared but not implemented
• TODO tracking — surfaces TODO, FIXME, HACK, XXX, NOTE in comments
• QSF lint — tabs, multi-spaces, unknown commands, duplicate pins/signals

Simulation

• Generate DO — auto-generate QuestaSim .do scripts from testbench entities
• Run DO — launch QuestaSim with a .do file, transcript streamed in real-time
• Testbench templates — snippets for self-checking testbenches, clock generation, stimulus

Configuration

Prerequisites

• Intel Quartus Prime (Lite/Standard/Pro) — for build, flash, and new project
• QuestaSim or ModelSim — for simulation and .do generation
• VHDL source files (.vhd, .vhdl)
• Quartus Settings File (.qsf) — for pin diagnostics and project explorer

Changelog

[0.15.4] - 2026-07-07

• Quartus: New Project command scaffolds a complete project with guided prompts for device, part, entity, and path

[0.15.3] - 2026-06-30

• QSF auto-completion — file picker when writing set_global_assignment -name VHDL_FILE in .qsf files

[0.15.2] - 2026-06-26

• VHDL Formatter — Shift+Alt+F with configurable indentation, 18 unit tests

View full changelog

Documentation

Full documentation at guizzz.github.io/VHDL-Essentials

License

MIT License.
