Agent-Diff-Visualizer (ADV)

ADV is a local-first VS Code extension that helps review large AI-generated git diffs by grouping changes semantically and surfacing risks.

Open Source

This project is open-source under the MIT License. Contributions, issues, and improvement ideas are welcome.

Features

Core Capabilities

• Semantic Task Clustering: Groups changed files into logical tasks (auth refactor, UI update, database schema) with task-oriented labels and file impact metrics
• Confidence Scoring: Aggregates risk signals (secrets, complexity, drift, architecture smell) into a single trust metric
• Intent Mapping: Extracts user prompt and agent reasoning from local Cline/Aider logs for review context
• Risk Highlighting: Detects hardcoded secrets, sensitive path changes, and complexity spikes

Advanced Features (v0.1.6+)

• Intent Drift Detection: Compares initial prompt scope against changed files; alerts when code extends beyond declared intent (e.g., "fix UI" but changes auth config). Shows severity level, evidence, and affected files
• Dependency Topology Map: Visualizes file relationships and flags architectural risks:
  • Impact edges (solid): Downstream consumers affected by changes
  • Smell edges (dashed): Potential circular dependencies or cross-layer violations
• Atomic Reversion Timeline: Step-by-step scrubber to review agent execution flow and rollback from any step onward (keeps early steps, discards later changes)
• Review Status Tracking: Mark tasks as pending/approved/rejected/read with persistent state per workspace

Usage

Quick Start (VS Code Extension)

1. Install from VS Code Marketplace
2. Open a workspace with uncommitted git changes
3. Run command: ADV: Open Agent Diff Review (Ctrl/Cmd+Shift+P, type "ADV")
4. Review panel opens in sidebar:
   • Left: Semantic groups with approve/reject/read buttons
   • Right: Intent mapping, topology map, and reversion timeline

Configuration

Open VS Code settings and search for adv.*:

{
  "adv.maxGroups": 8,
  "adv.ollamaModel": "llama2" // Optional: enable local LLM labeling via Ollama
}

Intent Log Discovery

Place agent logs in workspace root or subdirectories:

• Cline: .cline/history/*.json
• Aider: .aider.chat.history.md
• Generic: logs/, .logs/, agent/, .agent/ (.json, .jsonl, .md, .log, .txt files with agent-related names)

ADV scans these paths on startup to extract prompt and thinking for intent drift detection.

Copilot & Cursor Integration

Bridging the gap for Copilot Chat and Cursor where structured agent logs are unavailable.

• Direct Intent Setting: Type @adv <intent> in Copilot Chat to manually define your coding mission.

• Quick Review: Use the /review command to launch the visual diff panel instantly after setting your intent.

• Session Management: Use /clear to reset stored context for a fresh architectural review.

• Priority Intelligence: Intent captured via @adv now takes precedence over file-based logs (Cline/Aider) for more accurate Scope Drift Detection.

Development Setup

1. Clone and npm install
2. Run npm run watch (TypeScript compiler in watch mode)
3. Press F5 to launch extension dev host
4. npm run lint before commit

Roadmap

• ✅ Phase 1: Semantic grouping + review UI (v0.1.0)
• ✅ Phase 2: Deeper Cline/Aider intent mapping (v0.1.5)
• ✅ Phase 3: Intent drift + topology map + atomic reversion (v0.1.6)
• Phase 4: Interactive topology visualization (interactive DAG/network graph)
• Phase 5: Multi-step diff preview and step-level edit capability
• Phase 6: Integration with code snapshot services for rollback preview

Contributing

Please read CONTRIBUTING.md before opening a pull request. Issue and PR templates are available under .github/.

Security

If you discover a security issue, please report it through SECURITY.md.

CI

GitHub Actions runs build and lint automatically on pushes to main and on pull requests.

Design Philosophy

• Local-first: All analysis runs in your VS Code process; no telemetry, no cloud calls (except Ollama if configured)
• Heuristic + LLM: Semantic grouping uses rule-based classification by default; optional Ollama integration for smarter task labeling
• Low overhead: Workspace state persisted locally; no external storage
• Degradation-friendly: Missing intent logs? Missing Ollama? Extensions gracefully degrade with sensible defaults

Acknowledgments

Built to support autonomous agent workflows (Cline, Aider, OpenDevin, Copilot Agent mode). Inspired by the need for human-in-the-loop validation in agentic code generation.
