GDL extension for Visual Studio Code

Development environment for Archicad 29 GDL language (XML, HSF and GDL source code): syntax coloring, snippets, code outline, quick reference.

Usage

You can get the extension from the marketplace.

.xml files with <Symbol> root tag will be automatically detected as GDL-XML, .gdl files as GDL-HSF language.

• To switch between XML and GDL-XML syntax coloring, use context menu commands: "Switch language to GDL-XML" or "Switch language to XML"
• Change unknown file types to GDL-XML or GDL-HSF by using the context menu.
• Or just use VS Code's language selector, in the lower right of the status bar.

Use the themes GDL Dark or GDL Light for GDL-specific coloring

• In Extensions View: select the GDL extension, click the Set Color Theme button, then choose Light or Dark.
• See also the section on "Customizing Themes" below.

Settings

1. Press Ctrl-Shift-P, type User, select Preferences: Open user settings
2. In the top search field, type gdl
   • Select Extensions / GDL Configuration
3. In the top search field, type gdl-
   • Click Edit in setting.json to customize editor defaults for gdl-xml and gdl-hsf files
     • tabs/spaces
     • indentation size
     • line-end rulers

Snippets

any GDL command, global or request - expand required parameters

subroutine - subroutine header and body

hotspot or hotspot2 - length edit hotspot triplet

[... 1... 0... - when used with multiple cursors, insert series of numbers starting from 1 or 0

VSCode standard language features for GDL-HSF

• Document symbols (Ctrl-Shift-O)
  • Subroutines, macro calls and special comments (between !=====... ) are shown
  • Type after @ to filter results
  • Type after @: to group results by type and filter them
  • This list is also visible and can be filtered in the Breadcrumbs bar and the Explorer/Outline view
  • The Breadcrumbs bar also shows which subroutine the cursor is in
• Workspace symbols (Ctrl-T) searches library parts in the opened folders by name or GUID
  • The search opens with the currently selected text
  • Type to filter results
  • Select to open the same script or xml that the current editor contains, or libpartdata.xml if unknown
  • If the workspace changed in a process outside VSCode, use the "Re-scan library parts in workspace folders" command to refresh the known library parts.
• When a folder of HSF files is opened, further features are available:
  • Show info about parameters when the mouse hovers on them (can be toggled on/off with Ctrl-Alt-Space)
  • Show parameters with bold font (can be toggled on/off with Ctrl-Alt-Space), jump to paramlist.xml with Ctrl-click.
  • IntelliSense lists constants (ALL_CAPS) with their initialized values
  • IntelliSense lists parameters with their description, type, flags, group and default value. This list can be filtered by parameter type too.
  • Follow libraryglobal, macro and subroutine calls with Ctrl-click
  • Show variable, dictionary key, returned_parameters assignments, dictionary or array declarations with Ctrl-click.
• Go to definitions/references, find all references of subroutines in same libpart (Ctrl-click or F12, Shift-F12, Shift-Alt-F12)
• Show Call Hierarchy (Shift-Alt-H), Peek Call Hierarchy
  • Incoming or outgoing macro calls are shown, respecting the execution context of the edited scipt. Eg. all scripts are searched outgoing from a master script, but only master and 2d scripts are searched outgoing from a 2d script.
  • HSF library parts inside the workspace are searched. If the workspace changed in a process outside VSCode, use the "Re-scan library parts in workspace folders" command to refresh the known library parts.
  • Until VSCode API improvement the feature is only available if the cursor is on a word (not whitespace). If the cursor is on a macro call, that macro will be searched, otherwise the edited file will be searched. Outgoing calls' peek documents are faulty, but double-clicking an item opens the correct document.
• Automatic indentation on typing
  • Increase after lines with block-opening keywords (for, if, while, group, subroutine...)
  • Decrease after block-closing keywords (next, else, endif, endwhile, endgroup, return...)
  • Line ending comments are handled, comment-only lines and difficult syntax with : or multiline strings are not
• Links to source files from LP_XMLConverter error messages in terminal. The error message is shown next to the code, until the first edit or switching the editor.

Paste as block

When when pasting text on a selection, and the pasted text begins with a block-starter GDL statement, text is inserted before the selection and a corresponding block-closing statement is inserted after. Pasted text is indented to the selection's indentation, and selection gets indented.

Reconginzed statements: if for while do repeat

By default this feature is off, can be enabled by command Toggle Paste as Block.

Script outline view

• Active for GDL-XML and GDL-HSF language in Explorer View
• Lists subroutines (also shown as red dots in the right-side overview)
• Lists special comments (can be toggled on/off)
• Lists macro calls (can be toggled on/off)
• Click listed element to show its code in the editor
• Use these extra features to help navigate among scripts contained in a single GDL-XML file:
  • Lists existing scripts
  • Scripts are color-coded alongside the line numbers (left side) and the overview (right side)
  • Scripts that are longer than one line are shown as having a "main" part
  • Lists main and migration GUIDs (with version and automigration)
  • Lists the called macros (with info about which scripts they are called from)
  • Lists embedded images
  • "Go to Cursor" icon scrolls the editor to the cursor
  • See additional navigation icons (explained in hover text), also available as commands for setting keyboard shortcuts

Reference guide

If the cursor is on a known keyword, command, request, global variable or ac_ parameter: Use Ctrl-F1 (or context menu command) to bring up its reference in a VSCode tab. Double-word commands (eg. define fill) are recognized. For unknown words, the Index is displayed.

Use the Related... link at the bottom of the page to see similar commands: this link takes you to the chapter of the GDL Reference Guide that contains the keyword. Ctrl-C copies the selected text, Ctrl-F searches on the shown page.

Syntax coloring

Capabilities

• Highlight keywords, globals, fixed named parameters, add-on parameters, strings, request strings, autotext strings, subroutine labels
• Distinguish imperial numeric constants
• Deprecated keywords and globals
• Match for-next loop variables
• Detect parentheses, array dimension and range []() mixups
• Detect function calls with missing parentheses
• Highlight illegal variable names (e.g. 0var)
• Highlight innermost loop, macro call, group boundaries

Extra capabilities with GDL themes

• Different styles for 2d/3d/parameter/properties/ui script-related commands
• Different styles for i/o, attribute, transformation commands
• Further distinctions possible, but not implemented in themes
• Different color for CONST and _temporary variables

Known limitations

This is not a full parser: the underlying mechanism doesn't allow matching the end of a statement. Some valid syntaxes won't be highlighted, and some invalid syntaxes will be highlighted (the trouble starts when commands are split into multiple lines).

• Can't detect uninitialized variables
• Can't detect undefined subroutines
• Fixed name variables and requests are colored as valid in strings with different delimiters '”
• Keywords in illegal position (e.g. in function parameters) are colored as valid
• Can't detect if enough function/command parameters are used
• Can't detect missing or unneeded commas
• Can't edit or view GSM files properly

Customizing themes

1. Press Ctrl-Shift-P, type settings json, select Preferences: Open Settings (JSON)
2. Insert the following JSON object into the list (add it between the list elements):

     "editor.tokenColorCustomizations": {
           "[<GDL Dark|GDL Light>]": {
                 "textMateRules": [
                 ]
           }
     }


3. Open the theme source you want to customize: \.vscode\extensions\graphisoft.gdl-<version>\themes\..._theme.json
4. To customize certain colors:
   1. Open a GDL file and go to the color you want to change
   2. Use the VS Code command Inspect TM Scopes to get the name of the scope at the cursor position
   3. Copy the JSON object from ..._theme.json whose scope matches the "textMateRules": [] array
   4. The file \.vscode\extensions\gdl\misc\usedclasses.txt shows the syntax tree
5. To customize all colors:
   • copy the JSON objects from ..._theme.json whose names begin with GDL to the "textMateRules": [] array
6. Modify/add "foreground" and/or "fontstyle" entries
7. Example:

       ...
       },
       "editor.tokenColorCustomizations": {
           "[GDL Dark]": {
               "textMateRules": [
                   {
                     "name": "GDL: Array index []",
                     "scope": "meta.gdl.arrayitem",
                     "settings": {
                       "foreground": "#d4d4d4"
                       }
                   },
                   {
                       "name": "GDL: Contents of ()",
                       "scope": "meta.gdl.grouping",
                       "settings": {
                           "foreground": "#d4d4d4"
                       }
                   }
               ]
           }
       },
       ...


8. Press Ctrl-S to apply changes to the user settings

Release Notes

1.29.0

• Reference guide 29
• Snippet updates
• Require _dark.tif for .svg source image in pathnametable check
• Paste as block
• Show group of parameters in hover / suggestions
• Links to source files from LP_XMLConverter error messages in terminal

1.28.1

• improved links (Ctrl-click):
  • link parameters to paramlist.xml
  • link dict keys to dict parameter keys
  • link to dict key assignments
  • link to returned_parameters
  • link to dict, dim declarations
  • link to for loop variables
  • highlight target variable in peek window instead assigned value (works better with new links)
• improved parameter highlight: don't highlight dict key with name of a parameter
• links / suggestions / highlights react to changes in files not opened in vscode (eg. master script while editing 2d script)
• documentation / snippet updates

1.28.0

• Reference guide 28
• pathNameTable tree view (move, rename, open, check against source)
• drag&drop image files into GDL code, adding them to libpartdata.xml too
• show variable assignments with Ctrl-click
• Show/Peek Call Hierarchy, Goto/Peek Definition and Ctrl-click follows LIBRARYGLOBAL calls

1.27.1

• new GSID_INFO request
• bugfix: parameter list wasn't processed after <Separator>
• GDL-XML language is auto-detected by <Symbol> root tag in file

1.27.0

• Reference guide 27
• Snippet fixes (keywords at end of line)

1.26.2

• Intellisense reads constants from edited file too, besides master script
• IntelliSense parameters and constants can no longer be toggled with Ctrl-Alt-Space, use vscode settings to filter the results (editor.suggest.showFields, editor.suggest.showConstants)
• Find references/definition handles subroutines in all scripts, not just the edited one
• Snippet bugfixing

1.26.1

• Show Call Hierarchy, Peek Call Hierarchy context menu items list incoming or outgoing macro calls inside the workspace
• New command Re-scan library parts in workspace folders available in explorer context menu to reconcile file changes outside vscode
• Auto-indentation on typing enter and block-closing keywords
• Snippet bugfixing, added snippets for some missing recent global variables, angle editing hotspots

1.25.3

• Follow macro calls with Ctrl-click
• Reference guide
  • Find requests by name
  • Links are followed on long pages
  • Recognize double-word commands (DEFINE, SET)

1.25.2

• Go to definitions/references, find all references of subroutines in same gdl-hsf file (Ctrl-click or F12, Shift-F12, Shift-Alt-F12)
• Exclude commented macro calls from outline and symbols
• Workspace symbols (Ctrl-T) can find library parts by GUID
• Highlight innermost loop, macro call, group boundaries
• Automatic unindentation of loop end keywords and groups, automatic indentation of do and repeat blocks
• IntelliSense lists parameter types in second row

1.25.1

• Document symbols (Ctrl-Shift-O)
• Workspace symbols (Ctrl-T)
• IntelliSense lists parameters and constants (toggle with Ctrl-Shift-Space)
• Show parameter info in hover
• Show parameters with bold font
• Highlighting of built-in property ID strings
• Highlighting of deprecated global variables
• Reference guide updates

1.24.5

• Reference Guide fix for VSCode 1.56
• Reference Guide supports dark themes
• Reference Guide supports copying and searching by keyboard shortcut

1.24.4

• fix installation problem

1.24.3

• Reference Guide updates
• LABEL_ASSOC_ELEM_GEOMETRY, STAIR_BREAKMARK_GEOMETRY

1.24.2

1.24.1

• First non-preview version. If you have the preview version called pbaksa@graphisoft.com.gdl-xml, you must uninstall it: both versions cannot be used at the same time.
• Contains Archicad 24.0.0 INT R1 (build 3008) GDL features and GDL Reference Guide

License

MIT License

https://github.com/GRAPHISOFT/vscode-gdl/blob/main/LICENSE.md
