VSCode Extension for Fluid Templating Language

This extension for VSCode (and compatible code editors) provides language support for the Fluid Templating Engine.

https://github.com/user-attachments/assets/c1808e64-2939-4674-918f-fdfb58d3baf3

Installation

The extension is available in the common marketplaces:

• Visual Studio Marketplace
• OpenVSX

It has been tested with:

• VSCode
• VSCodium
• Cursor
• Windsurf

Features

Live Template Analysis

The extension is able to utilize available binaries in your project to provide live template analysis for Fluid templates, e. g. to detect syntax errors or deprecations. This works out-of-the-box for Fluid 5.3 (or higher) and TYPO3 14.3 (or higher). In older TYPO3 versions the companion extension needs to be installed.

The following folders are checked for the fluid and typo3 binaries automatically:

• vendor/bin/
• bin/
• .Build/bin/

typo3 is preferred over fluid if both are available.

If DDEV is available and the project has DDEV set up, the binaries are executed inside of the web container by default. This can be turned off by disabling fluid.bin.useDdevIfAvailable in the extension's configuration.

If necessary, custom binaries can also be specified in the extension's configuration via fluid.bin.typo3.* and fluid.bin.fluid.*. ${workspaceFolder} is substituted with the path of the current workplace folder. Example (execute fluid within anonymous docker container):

{
    "fluid.bin.fluid.path": "docker",
    "fluid.bin.fluid.args": [
        "run",
        "-i",
        "--rm",
        "-v",
        "${workspaceFolder}:/app",
        "-w",
        "/app",
        "php:8.5-cli",
        "php",
        "vendor/bin/fluid"
    ]
}

ViewHelper Autocomplete & Documentation

The extension currently doesn't include a dedicated language server for Fluid. Instead, it relies on the built-in HTML language support of VSCode to provide autocompletion and inline documentation for ViewHelpers. This comes with some limitations:

• only built-in ViewHelpers are supported (no XSD support yet)
• only tag syntax is supported (no inline syntax yet)

The advantage of this approach is that no built-in features for HTML are lost in the process, this includes highlighting, autocompletion, auto-closing of tags, Emmet, inline documentation, embedded CSS and JavaScript and previews for color values.

File Detection

Files matching the following description are considered Fluid HTML files:

• *.fluid.html (available since Fluid 5 and TYPO3 14)
• *.html files in:
  • Resources/Private/Templates/
  • Resources/Private/Layouts/
  • Resources/Private/Partials/
  • Resources/Private/Components/
  • Resources/Private/PageView/
  • ContentBlocks/**/templates/

Files matching the following description are considered Fluid Text files:

• *.fluid.*, excluding *.fluid.html (available since Fluid 5 and TYPO3 14)
• *.txt files in:
  • Resources/Private/Templates/
  • Resources/Private/Layouts/
  • Resources/Private/Partials/
  • Resources/Private/Components/
  • Resources/Private/PageView/
  • ContentBlocks/**/templates/

Development & Contribution

We welcome contributions from the community to further improve the developer experience of Fluid templating in VSCode!

To get started with your local setup, you need node and npm available in your development environment. To generate the ViewHelper autocompletion and documentation, you also need php and composer.

General Setup

• clone the project
• run npm i
• run npm run build or npm run watch to transpile TypeScript into JavaScript
• run npm run lint to lint your code locally (is also performed in GitHub Actions)
• run npm run vscode-package to create a VSIX file, which can be installed manually in VSCode

For bigger changes, it is advisable to use the development and debugging workflow suggested in the official documentation.

Generate ViewHelper Autocompletion

The current autocompletion is based on the Custom Data format, which is read by VSCode's built-in HTML language server. To generate this file format, a small PHP project installs Fluid Standalone and all TYPO3 core extensions that expose a global ViewHelper namespace (EXT:fluid, EXT:core and EXT:form), extracts the ViewHelper API definitions from their source code and writes the Custom Data json files to fluid/out/.

cd fluid/
composer install
composer generate

Publishing to Marketplace

Publishing is only possible with access to the registered publisher in Visual Studio Code Marketplace as well as a personal access token with the "manage marketplace" permission. Details are available in publishing extension. Same goes for Open VSX, see Publishing with the ovsx Command.

Currently, this is done locally:

git checkout main && git pull
npm version <TODO>
npm run vscode-package
npm exec vsce login friendsoftypo3
npm run vscode-publish
git push --follow-tags

Packaging is already setup in GitHub Actions. Once the release workflow is finalized and properly tested, this can be moved to GitHub Actions as well.

Language Server Research

During the creation of this extension, research and experiments have been done on the topic of a dedicated Fluid language server:

Fluid Language Server
