XLIFF Viewer

Open .xlf and .xliff translation files as a structured, themed GUI instead of raw XML. Built for Business Central / AL translation files, where a single file holds thousands of units and the trans-unit id already carries the object hierarchy — so the viewer shows objects, members and translated elements rather than one long list of <trans-unit> elements.

Read-only until you say otherwise. A file opens as a viewer; editing is a toggle away, and when it is off the GUI says which of the three reasons applies. Writes go through VS Code's own edit machinery, so undo, dirty state and save behave exactly as they do in the text editor.

✨ Features

• Structured tree — object type → object → member → translated element, built from the trans-unit id rather than from the display note, so the grouping is exact even when two objects share a name
• Object-type grouping — the top level is Tables (16), PageExtensions (89), Codeunits (15)…, so a file's couple of hundred objects are navigable instead of one flat list
• Namespaced apps — the readable, namespaced ids AL 18 writes under TranslationsWithNamespaces build the same exact tree, with a namespace level above the object types. An object whose ids come in both readable and hashed form — AL falls back to hashes for long or non-ASCII ids — is still one node
• Rolled-up state — every container shows a progress bar coloured by its worst descendant, not by its percentage: 99 % done with one missing target is not the same as 99 % done with one needing review
• Every field shown — source, target, maxwidth, size-unit, al-object-target, translate="no", every <note>, and a state the spec does not define is shown as the file wrote it
• Search — over id, names, source, target and notes, with * wildcards (Setup*, *caption*); a matching unit brings its whole path into view
• State filter — chips for the states the file actually contains, driven by the same roll-up the header shows
• Base-file pairing — resolves the .g.xlf for a language file and marks units the base no longer has (orphaned) or whose source has since changed
• Go to source — opens the AL source that declares the unit, with the Caption, ToolTip or label itself selected — or the member or object that declares it, when the source has no line for the unit. When the app's source does not declare it, the unit opens in the base file instead, with a notice that closes itself. The button's tooltip says which it will be. No AL tooling needed, on the desktop or the web
• Edit mode — opt-in per window: type a target, pick a state, and let the state follow the edit. Writes go through a WorkspaceEdit, so one typed translation is one undo step
• Validation hints — a target past its maxwidth, a placeholder the translation lost or invented, an empty target the file calls finished. Advisory: they never block an edit or change a value, and a container says how many translations beneath it are worth a look
• Load-bearing whitespace — a target that is only a space, or whose edges differ from the source, is marked and explained; xml:space="preserve" means those spaces are the translation
• Multi-<file> documents — a switcher, with each file remembering its own expansion
• Reopen as XML — the editor registers at default priority, so Reopen Editor With… → Text Editor is always there
• Comes back where you left it — hiding a tab and returning to it keeps the expansion, the focused row, the scroll position, the search, the filter and the edit toggle
• Desktop and web — the same extension runs in VS Code and in vscode.dev / github.dev

🧰 Usage

Open any .xlf or .xliff file. The viewer replaces the text editor automatically.

• Header — the app the file translates, its languages, unit count, resolved base file, and the whole file's progress
• Toolbar — search, state chips, expand / collapse all, and the edit toggle
• Tree — click a container row anywhere to open or close it; unit rows are content, not controls

Each unit renders as a labelled box:

Property
┌ Caption                          ● translated ┐   Go to source
│ Original     ExampleSourceText                │
│ [ de-DE ]    ExampleTranslation               │
└───────────────────────────────────────────────┘
  Developer    de-DE=ExampleTranslation

The legend names the translated element and carries its state. Original is the source; the bracketed row is the translation, labelled with the file's target language.

Editing

Turn editing on with the toolbar toggle, or start every file that way with xliffViewer.editMode.

• The translation row becomes a field. It is committed when you leave it, not on every keystroke, so Ctrl+Z undoes a translation rather than a letter
• Escape abandons what you typed and puts the committed value back
• The field is as wide as what it holds and grows as you add lines; drag its lower edge for more room
• Editing a target sets its state to xliffViewer.stateOnEdit; clearing one always sets needs-translation. Picking a state yourself overrides both
• A base file (.g.xlf) is never editable — it is the generator's output. The GUI says so rather than showing a dead field

Search tips

• Plain text (caption) — matches anywhere in id, names, source, target or notes, case-insensitively
• Leading wildcard (*setup) — matches anything ending in the term
• Trailing wildcard (Table *) — matches anything starting with it
• Both (*name*) — the same as a plain substring match
• Everything else is literal, so a query full of . and ( from a source string still finds it

⌨️ Keyboard Shortcuts

Keys typed into a field belong to the field, not to the tree.

The tree is a single tab stop with the arrow keys moving inside it, which is how an ARIA tree behaves. Everything interactive has a name, nothing animates when your system asks it not to, and the signals that are colours also carry a word or a number.

⚙️ Settings

How the base file is found

For <App>.<lang>.xlf, in order, first hit wins:

1. xliffViewer.baseFile — absolute path, workspace-relative path, or glob
2. xliffSync.baseFile, if the XLIFF Sync extension has it set — read defensively, never written
3. The sibling <App>.g.xlf
4. Any *.g.xlf in the same folder
5. Any *.g.xlf under a Translations/ folder in the workspace, preferring the one named after this app

Not finding one is a normal state, not an error: the viewer works fully without a base file and the affordances that need one say why they are disabled. NAB AL Tools has no base-file setting to read — it uses the same convention steps 3–5 already implement.

How "Go to source" finds the AL source

• Where it looks. It searches the app the translation file belongs to: the nearest folder above it that holds an app.json, else the workspace folder. node_modules, .alpackages, .snapshots and hidden folders are skipped. The app's preprocessorSymbols decide which side of an #if counts.
• How it matches. The numbers in a trans-unit id are AL's hash of each name. Every candidate declaration is checked against them, so a match is exact, never a guess by name.
• Several equally good matches — two apps in one workspace, say — are offered to choose from.
• Your edits count. An AL file open with unsaved edits is read as it stands in the editor.
• Always fresh. The index of objects is built on the first click and kept current as files change.

📦 Installing

Install XLIFF Viewer from the Visual Studio Marketplace or from Open VSX, or from the command line:

code --install-extension Florian-Noever.xliff-viewer

Every GitHub release also carries its VSIX, for Extensions → … → Install from VSIX…. npm run package builds one from source as xliff-viewer-<version>.vsix.

The VSIX carries the two host bundles, the webview bundle and its HTML shell, and nothing else — no sources and no tests.

🧩 Repository

GitHub: Florian-Noever/xliff-viewer

Bug reports and feature requests are welcome via Issues.

🛠️ Developer Notes

Architecture

The XML is parsed once, in the host — the webview never sees it. The whole document is read and written as one string with a format-faithful serialiser, verified byte-identical against a fixture corpus written in the exact shape the AL compiler emits.

Build commands

npm, and nothing else — packaging needs it regardless, since vsce shells out to it.

npm ci                   # install exactly what package-lock.json pins

npm run compile          # check-types + lint + esbuild (both targets) + vite build
npm run watch            # all four watchers, which is what F5 starts
npm run check-types      # tsc for the host and tests, vue-tsc for the webview
npm run lint             # eslint src
npm test                 # build, then vitest: data, host, webview and the perf budgets
npm run test:integration # build, then @vscode/test-electron and @vscode/test-web
npm run dev:webview      # the webview alone, against a fixture document
npm run package          # vsce package

npm run dev:webview serves the UI with no extension host behind it, rendering a projection of the largest fixture file. A drift test rebuilds that document from the file and fails if it has been hand-edited, so the dev server always shows what the extension actually sends.

Install scripts are opt-in. npm 11 runs a dependency's install script only when allowScripts in package.json approves it. Two are: @playwright/browser-chromium, which downloads the browser the web integration tests run in, and esbuild. Without the first, those tests cannot start — and they hang rather than fail, so if they ever sit silent after a dependency update, check npm install-scripts ls first. @vscode/vsce-sign is denied: packaging does not need it, and releases are published by CI.

Tests

Four Vitest projects: data (pure, and deliberately without a vscode alias, so a data test that imports it fails to resolve), host (a hand-written vscode mock), webview (jsdom), and perf (the wall-clock budgets, run serially so they measure the code rather than the load).

The XLIFF the tests read is invented. src/test/fixtures/corpus.ts generates every file in src/test/fixtures/xliff/ in the exact shape the AL compiler writes, and a test fails if a committed file drifts from it. After changing the generator, rewrite the files with the command below (in PowerShell, set $env:UPDATE_FIXTURES = '1' first instead):

UPDATE_FIXTURES=1 npx vitest run --project data src/test/data/corpus.test.ts

CI & Releases

CI runs on every push and pull request through the shared workflows of Florian-Noever/Florian-Noever. One job type-checks, lints and runs the data, host and webview tests; a second runs the integration tests in the desktop and the web host; a third packs a preview VSIX. The perf budgets stay out of CI, since shared runners are slower and noisier than the machines the budgets were set on, so run npm test locally before a release.

To release, bump the version with npm version x.y.z --no-git-tag-version and publish a GitHub release vx.y.z from a commit whose CI is green. The publish workflow builds and tests the tag, attaches the VSIX to the release and publishes it to the Visual Studio Marketplace and Open VSX.

📜 License

MIT.

The extension's own icons are in assets/. The in-GUI icons are from @vscode/codicons, licensed CC BY 4.0.
