VeriGood - Verilog Formatter

A Verilog/SystemVerilog code formatter for VS Code with granular control over formatting features.

Features (More to be added)

This formatter provides comprehensive formatting capabilities with individual control over each feature:

• Module header formatting with port alignment
• Assignment alignment
• Wire/reg/logic declaration alignment
• Parameter/localparam alignment
• Module instantiation formatting
• Always/initial block indentation
• Case statement indentation
• If/else block begin/end enforcement
• For loop begin/end enforcement
• Generate block indentation
• Comment column alignment
• Ifdef/else/endif annotation
• Trailing whitespace removal
• Blank line compression

Installation

From VSIX (Local Install)

1. Download verigood-verilog-formatter-1.0.0.vsix
2. Open VS Code
3. Press Ctrl+Shift+P → "Extensions: Install from VSIX..."
4. Select the downloaded .vsix file

From Marketplace

1. Open VS Code Extensions (Ctrl+Shift+X)
2. Search for "VeriGood - Verilog Formatter"
3. Click Install

Usage

Format Document

• Keyboard: Shift+Alt+F (Windows/Linux) or Shift+Option+F (macOS)
• Context Menu: Right-click → "Format Document"
• Command Palette: Ctrl+Shift+P → "Format Document"

Format Selection

• Keyboard: Shift+Alt+F (Windows/Linux) or Shift+Option+F (macOS) with text selected
• Context Menu: Right-click on selected text → "Format Selection"
• Command Palette: Ctrl+Shift+P → "Format Selection"

Recommended Keybindings

For the best experience, add these keybindings to your keybindings.json (File → Preferences → Keyboard Shortcuts → Open Keyboard Shortcuts JSON):

  {
    "key": "shift+alt+f",
    "command": "editor.action.formatDocument",
    "when": "editorTextFocus && !editorHasSelection"
  },
  {
    "key": "shift+alt+f",
    "command": "editor.action.formatSelection",
    "when": "editorTextFocus && editorHasSelection"
  }

This allows Shift+Alt+F to automatically format the entire document when nothing is selected, or format just the selection when text is selected.

Set as Default Formatter

Add to your settings.json:

{
  "[verilog]": {
    "editor.defaultFormatter": "internal.verigood-verilog-formatter",
    "editor.formatOnSave": true
  },
  "[systemverilog]": {
    "editor.defaultFormatter": "internal.verigood-verilog-formatter",
    "editor.formatOnSave": true
  }
}

Configuration & Examples

Each feature can be individually enabled or disabled. Below are before/after examples for each setting.

1. Module Header Formatting

Setting: "verilogFormatter.formatModuleHeaders": true

Before:

module my_module #(parameter WIDTH = 8, parameter DEPTH = 16) (
input clk, input rst, output [WIDTH-1:0] data);

After:

module my_module #(
  parameter WIDTH = 8 ,
  parameter DEPTH = 16
) (
  input              clk ,
  input              rst ,
  output [WIDTH-1:0] data
);

---

2. Assignment Alignment

Setting: "verilogFormatter.alignAssignments": true

Before:

assign data_out = data_in;
assign valid = ready & enable;
assign count_next = count + 1'b1;

After:

assign data_out   = data_in       ;
assign valid      = ready & enable;
assign count_next = count + 1'b1  ;

---

3. Wire/Reg Declaration Alignment

Setting: "verilogFormatter.alignWireDeclSemicolons": true Before:

wire [7:0] data_in;
wire valid;
wire [15:0] address;

After:

wire [7:0]  data_in;
wire        valid  ;
wire [15:0] address;

---

4. Parameter Alignment

Setting: "verilogFormatter.alignParameters": true Before:

parameter WIDTH = 8;
parameter DEPTH = 256;
parameter ADDR_WIDTH = 10;

After:

parameter WIDTH      = 8  ;
parameter DEPTH      = 256;
parameter ADDR_WIDTH = 10 ;

---

5. Always Block Indentation

Setting: "verilogFormatter.indentAlwaysBlocks": true Before:

always @(posedge clk) begin
if (rst) begin
data <= 0;
end
end

After:

always @(posedge clk) begin
  if (rst) begin
    data <= 0;
  end
end

---

6. Enforce Begin/End Blocks

Setting: "verilogFormatter.enforceBeginEnd": true Before:

if (enable)
  data_out <= data_in;
else
  data_out <= 8'h00;

for (i = 0; i < 8; i = i + 1)
  mem[i] <= 0;

After:

if (enable) begin
  data_out <= data_in;
end else begin
  data_out <= 8'h00;
end

for (i = 0; i < 8; i = i + 1) begin
  mem[i] <= 0;
end

---

7. Case Statement Indentation

Setting: "verilogFormatter.indentCaseStatements": true Before:

case (state)
IDLE: next_state = ACTIVE;
ACTIVE: next_state = DONE;
default: next_state = IDLE;
endcase

After:

case (state)
  IDLE:    next_state = ACTIVE;
  ACTIVE:  next_state = DONE;
  default: next_state = IDLE;
endcase

---

8. Generate Block Indentation

Setting: "verilogFormatter.indentCaseStatements": true (uses same setting) Before:

generate
if (USE_FEATURE) begin
my_module inst (.clk(clk));
end
endgenerate

After:

generate
  if (USE_FEATURE) begin
    my_module inst (.clk(clk));
  end
endgenerate

---

9. Module Instantiation Formatting

Setting: "verilogFormatter.formatModuleInstantiations": true

Formats module instantiations with aligned ports and parameters, including comprehensive support for:

• Single-line and multiline port connections
• Multiline concatenations with nested patterns
• Replication patterns: {COUNT{signal}}
• Double-replication patterns: {{COUNT{signal}}}
• Array indices with slicing: signal[BIT-1:0]
• Nested concatenations: {signal1, signal2, {signal3[7:0]}}
• Complex mathematical expressions in parameters

Before:

my_module #(.WIDTH(8), .DEPTH(16)) inst (.clk(clk), .data(data));

After:

my_module #(
  .WIDTH (8 ),
  .DEPTH (16)
) inst (
  .clk  (clk ),
  .data (data)
);

Multiline Concatenation Example:

// Before
u_parity_check (
.idata ({{CMDQ_W{cmdq_pop}}, {RESPQ_W{respq_pop}}, {RXDQ_W{rxdq_pop}}}),
.idata_enable ({{CMDQ_PAR_W{cmdq_en}}, {RESPQ_PAR_W{respq_en}}, {RXDQ_PAR_W{rxdq_en}}})
);

// After - all commas and closing braces aligned
u_parity_check (
  .idata        ({{CMDQ_W{cmdq_pop}}       ,
                  {RESPQ_W{respq_pop}}     ,
                  {RXDQ_W{rxdq_pop}}       }),
  .idata_enable ({{CMDQ_PAR_W{cmdq_en}}    ,
                  {RESPQ_PAR_W{respq_en}}  ,
                  {RXDQ_PAR_W{rxdq_en}}    })
);

---

10. Comment Column Alignment

Setting: "verilogFormatter.commentColumn": 40 Before:

wire [7:0] data; // Data signal
wire valid; // Valid flag

After:

wire [7:0] data;                        // Data signal
wire valid                              // Valid flag

---

11. Ifdef Comment Annotation

Setting: "verilogFormatter.annotateIfdefComments": true Before:

`ifdef DEBUG
  // Debug code
`else
  // Release code
`endif

After:

`ifdef DEBUG
  // Debug code
`else // DEBUG
  // Release code
`endif // DEBUG

---

12. Trailing Whitespace Removal

Setting: "verilogFormatter.removeTrailingWhitespace": true Removes all trailing spaces and tabs from line endings.

---

13. Blank Line Compression

Setting: "verilogFormatter.maxBlankLines": 1 Before:

wire [7:0] data;



wire valid;

After:

wire [7:0] data;

wire valid;

All Available Settings

{
  "verilogFormatter.indentSize": 2,
  "verilogFormatter.maxBlankLines": 1,
  "verilogFormatter.alignPortList": true,
  "verilogFormatter.alignParameters": true,
  "verilogFormatter.wrapPortList": true,
  "verilogFormatter.lineLength": 160,
  "verilogFormatter.removeTrailingWhitespace": true,
  "verilogFormatter.alignAssignments": true,
  "verilogFormatter.alignWireDeclSemicolons": true,
  "verilogFormatter.commentColumn": 40,
  "verilogFormatter.formatModuleInstantiations": true,
  "verilogFormatter.formatModuleHeaders": true,
  "verilogFormatter.indentAlwaysBlocks": true,
  "verilogFormatter.enforceBeginEnd": true,
  "verilogFormatter.indentCaseStatements": true,
  "verilogFormatter.annotateIfdefComments": true
}

Changelog

Version 1.2.7 (2025-11-05)

Selection Formatting & Wire Declaration Improvements

• ✨ Macro Annotation in Selection - ifdef/else/endif comment annotation now works in selection formatting
• ✨ Comment Column Alignment in Selection - Comment column alignment now applied in selection formatting
• ✨ Blank Line Compression in Selection - Blank line compression now works in selection formatting
• 🐛 Simple Wire Alignment - Simple wire declarations (no ranges, no init) now use minimal spacing with aligned semicolons
• 🐛 Wire Name Parsing - Fixed issue where trailing spaces in wire names caused semicolons to shift right on repeated formatting
• 🐛 Indent Preservation - Wire declarations now preserve original indentation instead of normalizing to minimum
• 🔧 Alignment Stability - Added checks to prevent re-formatting when declarations are already correctly aligned

Version 1.2.6 (2025-11-05)

Module Instantiation Enhancements

• ✨ Nested Concatenation Support - Full support for complex nested concatenations in multiline port connections
• ✨ Replication Patterns - Handles single {COUNT{signal}} and double {{COUNT{signal}}} replication patterns
• ✨ Array Index Support - Properly formats signals with array indices including slicing (signal[BIT-1:0])
• 🐛 Closing Brace Preservation - Fixed issue where closing braces were being removed in deeply nested patterns
• 🐛 Alignment Fixes - All commas and closing braces in multiline concatenations now align at consistent column
• 🐛 Spacing Fixes - Removed extra spaces before closing parentheses in concatenation endings
• 🔧 Selection Formatting - All nested pattern improvements applied to both full document and selection formatting

Version 1.2.5 (2025-11-04)

Module Header & Cleanup Improvements

• Fixed trailing blank lines being added at end of file
• Added blank line after module header closing parenthesis
• Improved module instantiation closing parenthesis alignment

Version 1.2.4 (2025-11-04)

Multiline Formatting Enhancements

• Added comprehensive multiline parameter and port formatting
• Support for mathematical expressions in parameters
• Support for ifdef/else/endif within parameter lists
• Improved multiline concatenation formatting

Version 1.2.3 (2025-11-04)

Bug Fix

• Fixed format selection for wire/reg/logic declarations with initialization
• Range formatting now properly handles declarations like wire [7:0] data = 8'h00;
• Initialization values are aligned when present in selected range

Version 1.2.2 (2025-11-04)

Bug Fix

• Reverted assignment bracket alignment - assignments no longer align closing brackets
• Assignment LHS (including brackets) is now treated as a single unit for alignment
• Only declarations (wire/reg/logic/input/output/inout) align closing brackets

Version 1.2.1 (2025-11-04)

Alignment Improvements

• Changed range/bracket alignment to align closing bracket ] instead of opening bracket [
• Applies to wire/reg/logic declarations: wire [7:0] data; instead of wire [7:0] data;
• Applies to port declarations: input [15:0] address; with aligned closing brackets
• Makes bit-width patterns more visually consistent and easier to read

Version 1.2.0 (2025-11-03)

Range Formatting Enhancements

• Added intelligent structure detection for range formatting
• Complete structures (always, initial, generate, for, case, if/else blocks) now receive full formatting including indentation fixes when selected
• Partial selections only apply alignment-based formatting without changing indentation
• Extended range formatting to support all declaration types and module instantiations
• All alignment calculations (assignments, wires, parameters, ports) are now based solely on selected lines

Version 1.1.1 (2025-11-03)

Format Selection Support

• Added DocumentRangeFormattingEditProvider for format selection feature
• Fixed line ending handling (Windows \r\n vs Unix \n)
• Format selection now properly formats only the selected range

Version 1.1.0 (2025-11-03)

Alignment Improvements

• Fixed module instantiation closing parenthesis alignment
• Fixed module header parameter comma alignment
• Improved port list formatting consistency

Version 1.0.0 (2024)

Initial Release

• Full document formatting support
• Module header formatting with port alignment
• Assignment, wire, and parameter alignment
• Module instantiation formatting
• Block indentation (always, initial, case, generate)
• Configurable formatting options

License

MIT License - See LICENSE for details.
