EAR Audio Preview

A professional-grade audio analysis tool inside VS Code.

Waveform · GPU Spectrogram · Goniometer · Phase Correlation
LUFS / F0 / Onset Timeline · True Peak · Stereo Metering · WAV Export

[!NOTE] This project began as a fork of sukumo28/vscode-audio-preview but has been comprehensively rebuilt — every major subsystem (decode, FFT, rendering, metering, loudness, configuration) was replaced or substantially rewritten. The only surviving artifact from upstream is the postMessage wire protocol. See What's new for details.

What's new in v0.5.0

Getting-started tour — first open launches a 24-step interactive spotlight guide (try-it steps auto-advance as you click tabs, toggle meters or open panels); replay anytime via the ? button top-right
Anisotropic spectrogram rendering — sharp on the time axis, smooth on the frequency axis, the way RX/Audition read; deep dive: English · 中文
Measured speedups (micro-benchmarks vs the locked v0.4.0 baseline, same machine):
- F0/onset sequence analysis 6.4× faster (2.97 → 0.46 ms per 3 s clip) — buffer reuse, per-frame WASM vector release, time-budget yielding
- Offline STFT framing 2.3× faster (8.47 → 3.72 ms) and spectrogram wire deserialization 3.0× faster (1.68 → 0.56 ms)
- WAV export encoding 1.9× faster (5.40 → 2.85 ms per 5 s stereo clip) via a little-endian Int16Array fast path
- One-shot spectrogram analysis −23% (34.1 → 26.3 ms for 3 s @ W1024) with hoisted FFT work arrays; RAF frame-prep hot paths now allocate zero arrays per frame (was ~6)
- Package −64%: .vsix 15.6 → 5.6 MB (dead essentia-wasm chain and stale chunks removed), dist gzip −9%
60 Hz everywhere — loudness readouts report at display rate (was 50 ms — 3× the update frequency), F0/onset strips analyze at ~60 frames/s (was ~45), meter ballistics stay frame-rate independent
Benchmark & behavior-anchor suite — five-dimension micro-benchmarks (npm run bench) with locked speed/size regression gates, and 450+ tests anchoring DSP, IPC and UI contracts
Fixes — headphone-EQ overlay now opens with the E key (the old Cmd+Shift+E chord is swallowed by the IDE), playhead no longer jumps to the far left after leaving Edit & Export, level-meter L/R ↔ M/S right-click flips instantly while paused, masonry shortcut panel, dead Waveform-visible setting removed

What's new in v0.4.0

CQT spectrum analyzer — a PAZ-style Constant-Q spectrum mode in the Live Spec pane: variable-Q psychoacoustic bands (Q≈3.85–6.97 below 250 Hz, ≈10 above), left-edge rendering, low-freq trapezoids + smooth highs, and a max-hold Peak Hold envelope (double-click to clear)
Deep dive — read the story behind it: English · 中文 — how we reverse-engineered PAZ Analyzer's rendering and adapted it to the webview

What's new in v0.3.0

Headphone curve correction — AutoEq PEQ compensation in the Transport FAB Monitor panel; search models, visualize curves, bypass or apply in real time
Curve Correction overlay — press E to open the full EQ editor; save profiles per-workspace or globally
Extension-host AutoEq proxy — headphone metadata only (no audio upload); CSP-safe access to autoeq.app

What's new in v0.2.0

Marketplace release — install directly from the Visual Studio Marketplace
Transport FAB — compact bottom-left play / volume / monitor controls; seek bar integrated into the STFT waveform
Settings overlay — gear popover for Options, Player, and Edit & Export (replaces the old bottom-sheet FAB)
Edit & Export — full region select, preview listen, and WAV export workflow
Loudness timeline — stacked LUFS, F0 (PitchYinFFT), and onset-flux strips on a shared time axis
Extension-host Essentia — STFT and sequence analysis offloaded to the Node.js host for CSP-safe processing
EAR identity — extension ID Eps-Acoustic-Revolution-Lab.ear-audio-preview; settings namespace EarAudioPreview.*

See CHANGELOG.md for the full release history.

Compared to upstream

The upstream extension pioneered the VS Code Custom Editor model for audio, but its monolithic FFmpeg WASM decoder required Docker to build. This project replaces the entire stack while keeping the same extension-host-to-webview message contract.

Subsystem	Upstream	This project
Decode	Single FFmpeg WASM (Docker build)	Per-format WASM decoders + Web Audio fallback
Spectrogram	Canvas2D point-by-point	WebGL2 GPU texture renderer (~7× faster)
FFT	Ooura only	Ooura + Essentia.js (multi-window, LUFS)
Metering	Basic waveform only	LUFS, true peak, goniometer, phase correlation spectrum, stereo level meter
Live monitoring	None	Full analyser tap: L/R/M/S solo, 5-band monitor matrix
Loudness	None	Offline EBU R128 profile + live loudness-worklet + F0/onset strips
Onboarding	Docker + manual build	`npm install && npm run webpack`

Installation

For Users

Recommended — VS Code Marketplace:

Open VS Code → Extensions (Cmd+Shift+X / Ctrl+Shift+X)
Search for EAR Audio Preview or publisher Eps-Acoustic-Revolution-Lab
Click Install

Or install from the command line:

code --install-extension Eps-Acoustic-Revolution-Lab.ear-audio-preview

Alternative — VSIX file (e.g. from GitHub Releases):

code --install-extension ear-audio-preview-*.vsix

For Developers

git clone git@github.com:Eps-Acoustic-Revolution-Lab/EAR-Audio-Preview.git
cd EAR-Audio-Preview
npm install
npm run webpack

Press F5 in VS Code, open any audio file, and the editor activates automatically.

To make Audio Preview the default for audio files:

"workbench.editorAssociations": {
  "*.wav":  "earAudioPreview.audioPreview",
  "*.mp3":  "earAudioPreview.audioPreview",
  "*.flac": "earAudioPreview.audioPreview",
  "*.ogg":  "earAudioPreview.audioPreview",
  "*.opus": "earAudioPreview.audioPreview",
  "*.aac":  "earAudioPreview.audioPreview",
  "*.m4a":  "earAudioPreview.audioPreview"
}

Migrating from upstream or older builds

If you previously used sukumo28/vscode-audio-preview or an earlier EAR build, update settings.json:

// Editor associations: wavPreview.audioPreview → earAudioPreview.audioPreview
"workbench.editorAssociations": {
  "*.wav": "earAudioPreview.audioPreview"
}

// Settings namespace: WavPreview.* → EarAudioPreview.*
"EarAudioPreview.autoAnalyze": true
"EarAudioPreview.analyzeDefault": { }

Analyze UI cache stored under the old wavPreview.analyzeUiCache.v1 key is not migrated; panel settings reset once after upgrade.

Capabilities

Supported Formats

Extension	Decoder
`.wav` `.aac` `.m4a` `.sph`	Browser `decodeAudioData`
`.mp3`	`mpg123-decoder` (WASM worker)
`.flac`	`@wasm-audio-decoders/flac`
`.ogg`	Ogg Vorbis WASM
`.opus`	`ogg-opus-decoder`

Files stream from the extension host in 3 MB chunks. The webview assembles the full buffer, then decodes in one pass. A circular SVG progress ring on the FAB button tracks transfer + decode progress.

Workspace Panes

Four tabbed views, each mounted lazily on first access:

Pane	Purpose
STFT	Multi-channel waveform + GPU spectrogram with drag-to-zoom on time, frequency, and amplitude axes. Right-click to reset any axis.
Live Spec	Real-time goniometer (3 modes), per-bin phase correlation spectrum, log-spaced spectral bars with peak hold and configurable HF tilt. Expandable to fullscreen.
Loudness	Offline EBU R128 profile over the full file — integrated/short-term/momentary LUFS curves, true-peak markers, LRA, PLR. Drag to select a time region.
Edit & Export	WAV export of selected region (EasyCut).

STFT Pane (Default)

The STFT pane displays waveform and spectrogram side-by-side:

Waveform — Multi-channel amplitude display with RMS, peak, and true-peak readouts on hover. Drag the resize handle between waveform and spectrogram to adjust heights.
Spectrogram — GPU-accelerated frequency-time visualization. Supports linear, log, and mel frequency scales. Auto-FFT mode adapts window size to visible time range.
Zoom — Click and drag to zoom into a time/frequency region. Hold Ctrl to constrain to time axis, Shift for frequency/amplitude axis.
Reset — Right-click to reset view. Ctrl+right-click resets time only, Shift+right-click resets frequency/amplitude only.
Cue position — Click anywhere to set the playback cue (white vertical line).

Live Spec Pane

Real-time analysis during playback:

Goniometer — Three modes: Polar Sample (scatter), Polar Level (directional gate), Lissajous (X-Y). Shows stereo field and phase relationships.
Phase Correlation Spectrum — Per-frequency-bin correlation coefficient ρ ∈ [−1, 1]. Red = out-of-phase, green = in-phase.
Live Spectrum Analyzer — Log-spaced frequency bars with configurable release rate (dB/s), peak hold, and HF tilt (0–6 dB/oct).
Fullscreen — Click ↗ to expand. Press Esc or right-click to exit.

Loudness Pane

Offline EBU R128 loudness profile with stacked timeline strips (shared time axis):

LUFS strip — Integrated (I), short-term (S), and momentary (M) loudness over time. BSpline-smoothed for display. Timeline padding aligns with the waveform above.
F0 strip — Fundamental frequency (Hz, log scale) via Essentia PitchYinFFT; unvoiced frames are left blank.
Onset strip — Spectral flux onset strength via Essentia Flux (half-rectified L2).
True peak markers — Red markers on the LUFS strip indicate true-peak excursions above 0 dBTP.
LRA & PLR — Loudness Range and Peak-to-Loudness Ratio displayed in the info panel.
Time selection — Drag across any strip to select a region and re-analyze with new bounds.
Layout — Three compact horizontal strips; tab re-entry keeps stable height (no viewport stretch).

Edit & Export Pane

Export selected audio regions:

EasyCut — Select a time range in any pane, then export as WAV from this tab.
Format — Exports preserve original sample rate and bit depth.

Common Operations

Playback Control

Play/Pause — Click the play button in the player bar, or press Space (if enabled in settings)
Seek — Click anywhere on the seek bar, or click on the waveform/spectrogram to set cue position
Volume — Adjust the volume slider in the player bar. Switch between dB and linear scale in Player settings

Zoom in — Click and drag on waveform or spectrogram to select a region
Constrained zoom — Hold Ctrl while dragging to zoom time axis only, Shift for frequency/amplitude axis only
Reset zoom — Right-click on the graph. Ctrl+right-click resets time only, Shift+right-click resets frequency/amplitude only
Resize waveform — Drag the horizontal handle between waveform and spectrogram to adjust heights

Analysis & Inspection

Hover readout — Hover over waveform to see RMS, peak, and true-peak values at that time position
Frequency readout — Hover over spectrogram to see frequency and dB level
Select region — Drag to select a time range, then switch to Edit & Export pane to export as WAV
Re-analyze — Change settings in the Options tab, then click Save to redraw spectrogram

Live Monitoring

Enable live analysis — Check "Show live analysis" in Options tab to activate real-time meters
Solo channels — Use the monitoring bar below the info table to solo L, R, M (mid), or S (side)
5-band monitor — Configure crossover edges in the monitoring matrix for frequency-specific solo
Fullscreen live spec — Click ↗ in Live Spec pane to expand. Press Esc or right-click to exit

Live Monitoring Details

Enable Show live analysis in the FAB settings sheet. A dedicated analyser node taps the playback graph without affecting the main output:

Stereo level meter (right column) — L/R or M/S RMS + peak bars, peak-hold with 2 s decay, clip LEDs. Resizable width. Green → yellow → red gradient.
Goniometer — three sound-field modes: Polar Sample (scatter), Polar Level (Insight-style directional gate), and Lissajous. WebGL2 or Canvas2D rendering.
Phase correlation spectrum — per-frequency-bin ρ ∈ [−1, 1] plus broadband correlation readout.
Live spectrum analyzer — log-spaced bars, configurable release rate (dB/s), peak hold, and per-octave tilt (0–6 dB/oct).
Monitoring matrix — solo L, R, M (mid), or S (side). 5-band parametric monitor with configurable crossover edges.
Fullscreen overlay — click ↗ to expand the Live Spec pane; Esc or right-click to close.

FFT & Analysis

Two backends, switchable at any time:

Backend	Strengths
Ooura (default)	Pure JS, instant startup, fast for most workloads
Essentia.js	Hann, Hamming, Blackman-Harris, Triangular windows + offline LUFS

Frequency scales: linear, log piecewise, or mel (configurable filter bank). Optional auto-FFT mode adapts window size to the visible time range for optimal frequency resolution. High-resolution mode doubles spectrogram pixel dimensions for pixel-dense displays.

Loudness & Dynamics

Offline profile — LoudnessService runs an OfflineAudioContext with loudness-worklet over the full file. Produces LUFS-M/S/I curves, LRA, PLR, and max true-peak. BSpline-smoothed for display.
True peak everywhere — ebur128-wasm powers per-window true-peak in waveform hover readouts, per-buffer true-peak in the level meter, and full-file true-peak in the info table.
Live EBU R128 — loudness-worklet provides real-time LUFS-M/S/I during playback. Session max true-peak is tracked continuously.

Graph Interaction

Consistent across waveform, spectrogram, and loudness panes:

Action	Result
Click	Set cue position (white line)
Drag	Select range → re-analyze with new bounds
Ctrl + drag	Constrain to time axis only
Shift + drag	Constrain to value axis only
Right-click	Reset view range (Ctrl/Shift for single-axis reset)
Hover	RMS, peak, true-peak, and frequency readout

Playback

Full Web Audio graph: source → HPF/LPF biquad filters → gain → destination. Optional auto-play on seek, spacebar toggle, dB or linear volume scale. The live monitoring sub-graph (splitter → analysers → gain matrix → merger) connects in parallel when enabled.

Architecture

┌── Extension Host (Node.js) ────────────────────────────────────┐
│  AudioPreviewEditorProvider                                    │
│  Chunked streaming (3 MB) · VS Code settings · globalState     │
└──────────────────────┬─────────────────────────────────────────┘
                       │ postMessage: CONFIG · DATA · RELOAD
┌──────────────────────▼─────────────────────────────────────────┐
│  Webview (browser sandbox)                                     │
│                                                                │
│  DecoderFactory ──→ PlayerService (Web Audio graph + live tap) │
│      │                    │                                    │
│      │                    └──→ Live meters (Level · Gonio ·    │
│      │                         Spectrum · Phase Correlation)   │
│      │                                                         │
│      └──→ AnalyzeService (Ooura / Essentia STFT)               │
│                └──→ SpectrogramRenderer (WebGL2, twgl.js)      │
│                                                                │
│  LoudnessService (OfflineAudioContext + ebur128-wasm)          │
│                                                                │
│  Workspace panes: STFT | Live Spec | Loudness | Edit           │
│  All services extend Service → EventTarget                     │
│  All UI extends Component → Disposable                         │
└────────────────────────────────────────────────────────────────┘

Message types: src/message.ts. Benchmarks (Apple Silicon, 300 s stereo file): spectrogram CPU pack ~41 ms → ~6 ms with WebGL2.

Usage

Getting Started

Open an audio file — Click any supported audio file (.wav, .mp3, .flac, .ogg, .opus, .aac, .m4a) in VS Code. The EAR Audio Preview editor opens automatically.

Set as default editor (optional) — Add to your settings.json:

"workbench.editorAssociations": {
  "*.wav":  "earAudioPreview.audioPreview",
  "*.mp3":  "earAudioPreview.audioPreview",
  "*.flac": "earAudioPreview.audioPreview",
  "*.ogg":  "earAudioPreview.audioPreview",
  "*.opus": "earAudioPreview.audioPreview",
  "*.aac":  "earAudioPreview.audioPreview",
  "*.m4a":  "earAudioPreview.audioPreview"
}

Navigate the interface — The editor loads with the STFT pane active, showing waveform and spectrogram. Switch between workspace panes using the tabs below the player bar.

UI Layout

Element	Location	Role
Info table	Top-left	Metadata: format, sample rate, bit depth, duration, true peak
Workspace tabs	Top bar	STFT · Live Spec · Loudness · Edit & Export (ear-eq sliding focus)
Transport FAB	Bottom-left	Collapsed play/volume knob; expands to seek, monitor solo, level meter
Meta FAB	Bottom-left (stacked)	Settings overlay: Options / Player / Edit & Export
Seek bar	STFT pane	Time scrubber lives in the waveform area (not a global header)

Settings

Click the FAB (bottom-left) to open the settings sheet. Three tabs:

Options Tab

Common Settings:

Time range — Set min/max time bounds for analysis (seconds)

Waveform Settings:

Visible — Toggle waveform display on/off
Amplitude range — Set min/max amplitude bounds for display

Spectrogram Settings:

Visible — Toggle spectrogram display on/off
High-resolution mode — Doubles canvas pixel dimensions for sharper rendering on high-DPI displays
Window size — FFT window size (256–32768 samples, or Auto)
- Auto mode — Adapts window size to visible time range for optimal frequency resolution
Window type — Hann, Hamming, Blackman-Harris, or Triangular
FFT backend — Ooura (fast, pure JS) or Essentia.js (multi-window support, offline LUFS)
Frequency scale — Linear, log piecewise, or mel
Frequency range — Set min/max frequency bounds (Hz)
dB range — Set min/max dB bounds for spectrogram color mapping

Live Analysis Settings:

Show live analysis — Enable real-time meters during playback (goniometer, spectrum, level meter)
Goniometer mode — Polar Sample, Polar Level, or Lissajous
Spectrum release rate — Decay speed in dB/s (1–60 dB/s)
Spectrum peak hold — Peak hold duration in seconds (0–5 s)
HF tilt — High-frequency tilt compensation (0–6 dB/oct)

Player Tab

Playback Controls:

Volume scale — dB or linear scale
Initial volume — Default volume on load (dB or linear, depending on scale)
Enable space key play — Toggle playback with spacebar
Enable seek to play — Auto-play when seeking to a new position

Filters:

Enable HPF — High-pass filter on playback
HPF frequency — Cutoff frequency in Hz (10 Hz – Nyquist)
Enable LPF — Low-pass filter on playback
LPF frequency — Cutoff frequency in Hz (10 Hz – Nyquist)
Match filter frequency to spectrogram — Auto-sync filter cutoffs with spectrogram frequency range

EasyCut Tab

Export Settings:

Time range — Select start/end time for export (inherited from selection in other panes)
Export — Click to export selected region as WAV file

Save Button:

Click Save at the bottom of the settings sheet to redraw the spectrogram with current analysis settings. Settings persist automatically to VS Code globalState (debounced, 500 ms).

Headphone curve correction (Monitor):

Open the Transport FAB → Monitor section → click the profile row (or press E)
Search autoeq.app for your headphone model, pick measurement + target curve, then Apply preset
BYPASS toggles real-time EQ without clearing the profile
Save to workspace writes .vscode/ear-headphone-eq.json; Save globally stores in extension globalState
EQ applies to live playback only in v1 (not baked into Edit & Export)

Network & privacy

The curve correction feature contacts https://autoeq.app via the extension host (Node.js) to:

List headphone measurement entries and target curves
Request parametric EQ (PEQ) presets for a selected model

Your audio files are never uploaded. Only headphone model metadata (name, measurement source, target label, sample rate) is sent to AutoEq when you apply a preset. The webview cannot call AutoEq directly because the API does not allow cross-origin requests from vscode-webview:// origins; the extension proxies those HTTP calls instead.

Development

npm install
npm run webpack-dev    # watch mode
npm test               # Jest (jsdom + jest-canvas-mock)
npm run lint           # ESLint
npm run format         # Prettier

Script	Purpose
`npm run webpack`	One-shot build → `dist/`
`npm run webpack-dev`	Watch + rebuild
`npm test`	Unit tests
`npm run lint-check` / `format-check`	CI checks

Build targets

Three webpack outputs: dist/extension.js (Node), dist/audioPreview.js (webview), dist/web/extension.js (VS Code for Web).

Key dependencies

Layer	Packages
Decode	`mpg123-decoder`, `@wasm-audio-decoders/flac`, `@wasm-audio-decoders/ogg-vorbis`, `ogg-opus-decoder`
FFT	`ooura`, `essentia.js`
GPU	`twgl.js` (WebGL2)
Loudness	`loudness-worklet`, `ebur128-wasm`

Roadmap

Done

[x] Per-format WASM decoders (no Docker)
[x] WebGL2 GPU spectrogram
[x] Essentia FFT backend + offline LUFS
[x] Four workspace panes (STFT / Live Spec / Loudness / Edit)
[x] Stereo level meter (L/R and M/S, resizable)
[x] Live log spectrum (peak hold, configurable release, HF tilt)
[x] Goniometer (polar sample / polar level / Lissajous)
[x] Frequency-domain phase correlation spectrum
[x] Live + offline EBU R128 loudness (LUFS, LRA, PLR, true peak)
[x] ebur128-wasm true peak (file, window, buffer levels)
[x] Live monitoring matrix (L/R/M/S + 5-band solo)
[x] Mid/side derived offline analysis
[x] Loudness profile pane with BSpline-smoothed curves
[x] Auto-FFT window inference from visible time range
[x] Settings persistence via globalState
[x] Compact workspace chrome (minimal top tab bar, no global transport header)
[x] Transport FAB — play/volume/monitor in bottom-left popover; seek in STFT pane
[x] Ear-eq UI tokens — pill controls, sliding focus, segmented controls, knob component
[x] Hearing protection — optional peak-dBFS mute in Playback settings
[x] LUFS timeline alignment with waveform (timelinePlotLayout)
[x] Loudness pane layout stability — fixed chart height on tab re-entry
[x] Edit & Export panel surfaces + ear-eq segmented controls (channels, listen, destination)
[x] Loudness multi-strip layout — LUFS + F0 (PitchYinFFT) + Onset flux (Essentia)
[x] Monitoring curve for flat frequency response (AutoEq PEQ, live playback)
[x] CQT spectrum analyzer (PAZ-style variable-Q, left-edge rendering, Peak Hold) — deep dive: English · 中文
[x] Anisotropic spectrogram rendering (time-sharp / frequency-smooth) — deep dive: English · 中文
[x] Getting-started tour — 24-step interactive spotlight onboarding with try-it auto-advance

Planned

[ ] Chromagram strip (CQT) or PredominantPitchMelodia for polyphonic melody
[ ] Optional third-strip feature toggle (Spectral Centroid, etc.)
[ ] Frequency-weighted RMS (dBA, dB-B, dB-C)
[ ] Bake headphone EQ into Edit & Export processed output
[ ] Worker offload for long-file Essentia sequence analysis

Contributing

Bug reports, documentation, and pull requests are welcome.

Fork the repo at Eps-Acoustic-Revolution-Lab/EAR-Audio-Preview
git checkout -b feature/amazing-feature
Commit and push
Open a Pull Request to the lab-version remote

Run npm test && npm run lint-check before submitting.

License

MIT — see LICENSE.

Acknowledgments

earlab — development and maintenance
sukumo28 — original Custom Editor foundation
Microsoft custom-editor-sample
Audio DSP stack: Ooura, Essentia.js, mpg123-decoder, wasm-audio-decoders, loudness-worklet, ebur128-wasm, twgl.js

EAR Audio Preview

Eps-Acoustic-Revolution-Lab

EAR Audio Preview

What's new in v0.5.0

What's new in v0.4.0

What's new in v0.3.0

What's new in v0.2.0

Compared to upstream

Installation

For Users

For Developers

Migrating from upstream or older builds

Capabilities

Supported Formats

Workspace Panes

STFT Pane (Default)

Live Spec Pane

Loudness Pane

Edit & Export Pane

Common Operations

Playback Control

Zoom & Navigation

Analysis & Inspection

Live Monitoring

Live Monitoring Details

FFT & Analysis

Loudness & Dynamics

Graph Interaction

Playback

Architecture

Usage

Getting Started

UI Layout

Settings

Options Tab

Player Tab

EasyCut Tab

Network & privacy

Development

Build targets

Key dependencies

Roadmap

Done

Planned

Contributing

License

Acknowledgments
