e-lang: The Engineering Programming Language

e-lang is an experimental, domain-specific programming language designed from the ground up for engineering disciplines. By providing higher-level abstractions tailored to physical computing, e-lang makes it easier to write safe, mathematically verifiable engineering software.

🌟 Core Philosophy

e-lang is not a general-purpose programming language; it is an engineering engine. Its killer feature is native, syntax-level support for Dimensional Analysis and Unit Arithmetic.

1. Dimensional Analysis as a First-Class Citizen: Units are not external libraries; they are intrinsic to the type system. Adding Length to Time results in a strict compile-time error. Multiplying Length by Time creates a dynamically derived algebraic type.
2. Structural over Nominal Typing: In e-lang, units use structural typing based on "Dimension Vectors". Any unit that mathematically reduces to the same vector is of the same type (e.g., meter and foot are both structurally Length).
3. Zero-Cost Abstraction: The complex type-checking of units exists purely at compile time for developer ergonomics. At runtime, all variables are erased to dimensionless primitive scalars (standard 64-bit floats), normalized to base units.

🚀 Getting Started

The best way to try e-lang is to install the VSCode extension. This includes an interactive interpreter that runs e-lang notebook (*.elnb) files.

Installing the CLI

e-lang includes a basic CLI tool to run standalone script files (.elng). Currently, the only implemented command is run, which interprets a program and returns any print statements to the console.

npm i -g @eng-tools/e-lang@latest

To run an e-lang file, simply type:

elang run ./path/to/your/file.elng

(Note: This is an alpha version and it should not be used in production environments.)

📚 Language Tour: The Basics

Variables and Types

Variables in e-lang are declared using const (immutable) or var (mutable). e-lang supports strong type inference, but explicit type annotations are available.

// Immutable constants
const PI = 3.14159
const MAX_VALUE: number = 100
const greeting: text = "Welcome to e-lang"

// Mutable variables
var counter: number = 0
var isActive: boolean = true

// Reassignment
counter = 42

Type System and Unions

The type system supports basic primitives (number, text, boolean, null), lists, models, and Union Types.

// Type union - value can be number OR text
formula flexible(value: number or text) : text {
    return value
}

// Nullable type
const empty: null = null

📐 Dimensions and Units (The Core Feature)

The defining feature of e-lang is its ability to natively model physical quantities.

Declaring Dimensions

You can define base dimensions using the dimension keyword, and compose derived dimensions using mathematical operations (*, /, ^).

// Base dimensions
dimension Length
dimension Mass
dimension Time

// Derived dimensions
dimension Area = Length ^ 2
dimension Velocity = Length / Time
dimension Acceleration = Length / (Time ^ 2)
dimension Force = Mass * Length / (Time ^ 2)

Declaring Units

Once a dimension is declared, you can define units that belong to it. A unit can either be explicitly assigned to a dimension (a base unit), or mathematically derived from other units.

// Base units assigned to a dimension
unit meter : Length
unit kilogram : Mass
unit second : Time

// Derived units defined as multiples of other units
unit kilometer = 1000 * meter
unit gram = kilogram / 1000
unit minute = 60 * second

// Complex composite units
unit newton = kilogram * meter / (second ^ 2)
unit pascal = newton / (meter ^ 2)
unit joule = newton * meter
unit watt = joule / second

📏 Measurements and Conversions

In e-lang, a measurement is composed of a dimensionless scalar value combined with a unit type.

The Measurement Operator (~)

Attach a unit to a value using the ~ operator.

const distance = 100 ~ meter
const time = 10 ~ second
const height = 5.5 ~ meter

// Mathematical operations with units create new dynamic unit types
const area = (10 ~ meter) * (5 ~ meter)             // Result in meter^2
const speed = (100 ~ meter) / (10 ~ second)         // Result in meter/second

The Unit Conversion Operator (->)

You can project or convert measurements into compatible units using the -> operator. The compiler checks if the dimensions match.

const distance_in_km = 1000 ~ meter -> kilometer
const weight_in_grams = 5 ~ kilogram -> gram

// Valid Conversion
print 1 ~ kilometer + 500 ~ meter

// Invalid Conversion (Compile Time Error!)
// print 100 ~ meter + 20 ~ second

Imaginary Numbers (im)

e-lang has native support for complex / imaginary numbers, heavily used in electrical and signal engineering.

const complex_val = 5im
const five_plus_3i = 5 + 3im

// Measurements with complex components
const complex_measurement = (3 + 4im) ~ meter

🧮 Formulas and Lambdas

Functions in e-lang are declared using the formula keyword or via lambda expressions (=>).

Formulas

// Formula with types and return types
formula add(a: number, b: number) : number {
    return a + b
}

// Optional parameters using ?
formula optional_param(x: number, y?: number) : number {
    // y can be null
    return x + 5
}

Lambda Expressions

Lambdas offer a concise way to write inline functions, perfect for higher-order functions.

// Concise lambda
const double = (x: number) => x * 2

// Lambda with a block body
const complex_calc = (x: number, y: number) : number => {
    const sum = x + y
    return sum + (x * y)
}

// Higher-order formula accepting a lambda
formula apply(fn: (number) => number, value: number) : number {
    return fn(value)
}

print apply(double, 5) // Prints 10

🔀 Control Flow

e-lang features an expressive control flow syntax.

If / Else If / Else

const temp = 20
if (temp > 25) {
    print "Hot"
} else_if (temp >= 15 and temp <= 25) {
    print "Comfortable"
} else {
    print "Cold"
}

For Loops

for loops natively support explicit ranges, variables, and step sizes.

// Loop from 1 to 5
for (var i: number = 1 from 1 to 5) {
    print i
}

// Loop with custom step
for (var x: number = 0 from 0 to 50 step 5) {
    print x
}

Match Statements (Pattern Matching)

The match statement allows for concise multi-branch conditional logic. Match statements can also return values.

const status = 404
const message = match status {
    200 => "Success"
    404 => "Not found"
    500 => "Server error"
    default => "Unknown status"
}

📦 Collections and Models

Lists

Lists can hold elements and are zero-indexed.

const numbers = [1, 2, 3, 4, 5]
const first_val = numbers[0]

// Nested lists
const matrix = [
    [1, 2, 3],
    [4, 5, 6]
]

Models (Structs)

model blocks define custom data structures with typed fields.

model Material {
    name: text,
    density: number,
    yield_strength: number
}

// Optional parameters
model Part {
    id: number,
    description?: text
}

// Instantiating a model
const steel = {
    name: "Steel S355",
    density: 7850,
    yield_strength: 355
}

Models can also inherit fields from other models using the extends keyword.

model Beam extends Part {
    length: number,
    material: Material
}

🛠 Advanced Features

Statement Blocks

Statement blocks allow you to isolate variable scope and immediately evaluate code blocks that return a value.

const block_result = (() => {
    var x = 10
    var y = 20
    return x + y
})()

Modules (Import / Export)

To structure large projects, files can be imported and entities exported. The .elng extension is safely omitted in imports.

// In dimensions.elng
export dimension Length
export unit meter : Length

// In main.elng
import './dimensions'

const my_length = 50 ~ meter

🏗 Real-World Scenario: Structural Analysis

Putting it all together, here is a complete example of how e-lang models real engineering domains using dimensions, units, models, and formulas.

domain structural_engineering

// 1. Dimensions and Units
dimension Length
dimension Force
dimension Pressure
dimension Moment = Force * Length

unit millimeter : Length
unit newton : Force
unit kilonewton = 1000 * newton
unit megapascal : Pressure

// 2. Data Models
model Material {
    name: text,
    yield_strength: number
}

model CrossSection {
    area: number,
    inertia_moment: number,
    centroid: number
}

// 3. Formulas
formula bending_stress(moment: number, inertia: number, distance: number) : number {
    return (moment * distance) / inertia
}

// 4. Instantiation
const steel = {
    name: "Steel S355",
    yield_strength: 355
}

const beam_section = {
    area: 4260,
    inertia_moment: 8356000,
    centroid: 150
}

const length = 5000 ~ millimeter
const load = 50 ~ kilonewton

// Calculations and analysis seamlessly handle numbers and math!
