Prisma Studio Extension for VSCode

A powerful VSCode extension that seamlessly integrates Prisma Studio directly into your development environment. Access and manage your database with ease without leaving your code editor.

Note: This extension is built upon the excellent foundation provided by vscode-webpreview, which served as the base for this specialized Prisma Studio integration.

✨ Features

🚀 Core Functionality

• Embedded Prisma Studio: Run Prisma Studio directly within VSCode
• Quick Access: One-click access via status bar or keyboard shortcuts
• Flexible URL Configuration: Connect to any Prisma Studio instance
• Responsive Design: Multiple screen size presets for testing different viewports
• Local Prisma Studio: Start/stop Prisma Studio directly from VSCode using npx

🎯 Navigation & Controls

• Browser-like Navigation: Back, forward, and refresh controls
• Developer Tools: Built-in access to Chrome DevTools for debugging
• External Browser: Open current URL in your default browser
• Column Toggle: Switch between single and split-screen views
• Responsive View: Toggle resizable responsive preview mode

⚙️ Configuration Options

• Custom URLs: Configure default Prisma Studio URL
• Screen Presets: Define custom responsive breakpoints
• Docker Settings: Configure Docker image and database connections
• Workspace Settings: Per-project configuration support

📦 Installation

1. Open VSCode
2. Go to Extensions (Ctrl+Shift+X)
3. Search for "Prisma Studio"
4. Click Install on the extension by Eliezer Rangel

Alternatively, install from the Visual Studio Marketplace.

🚀 Quick Start

Method 1: Status Bar

Click the "Prisma Studio" button in the status bar (bottom of VSCode).

Method 2: Command Palette

1. Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (Mac)
2. Type "Open Prisma Studio"
3. Press Enter

Method 3: Keyboard Shortcuts

• Ctrl+Alt+P: Open Prisma Studio
• Ctrl+Alt+U: Change Prisma Studio URL

⌨️ Keyboard Shortcuts

🛠️ Configuration

Configure the extension through VSCode settings (settings.json):

{
  "webPreview.url": "http://localhost:5555",
  "webPreview.mediaScreenOverride": true,
  "webPreview.mediaScreen": {
    "Mobile": "375x667",
    "Tablet": "768x1024",
    "Desktop": 1440,
    "4K": 2560
  },
  "webPreview.schemaPath": "prisma/schema.prisma",
  "webPreview.port": 5555
}

Configuration Options

Default Screen Presets

{
  "SM": 640,
  "MD": 768,
  "LG": 1024,
  "XL": 1280,
  "2XL": 1536
}

🚀 Local Prisma Studio

The extension runs Prisma Studio directly using npx for a simpler setup:

Commands

• Start Prisma Studio: Launches Prisma Studio using npx
• Stop Prisma Studio: Stops the running Prisma Studio process

Requirements

• Node.js installed
• Prisma schema file in your project

Usage

1. Open a workspace with a Prisma project (recommended)
2. Use Command Palette → "Start Prisma Studio"
3. The extension will automatically find your schema.prisma file or ask you to select it
4. Access Prisma Studio at http://localhost:5555

Schema File Detection

The extension automatically searches for schema.prisma files in these locations:

• prisma/schema.prisma
• packages/prisma/schema.prisma
• apps/api/prisma/schema.prisma
• schema.prisma (root directory)

If not found, you'll be prompted to select your schema.prisma file manually.

🎮 Available Commands

Access these commands via Command Palette (Ctrl+Shift+P):

Panel Controls

When Prisma Studio is active, additional controls appear in the editor toolbar:

• Back (←): Navigate to previous page
• Refresh (⟳): Reload current page
• URL (🔍): Change current URL
• Toggle View (⊞): Switch between column layouts
• Responsive (📱): Toggle responsive view mode
• Dev Tools (⚒): Open Chrome DevTools
• External (↗): Open in default browser

📋 Usage Examples

Basic Usage

# Start your Prisma Studio locally
npx prisma studio

# Open VSCode and use Ctrl+Alt+P to access it

Custom Configuration

{
  "webPreview.url": "http://localhost:5555",
  "webPreview.schemaPath": "packages/prisma/schema.prisma",
  "webPreview.port": 5555
}

Responsive Testing

{
  "webPreview.mediaScreenOverride": true,
  "webPreview.mediaScreen": {
    "iPhone": "375x812",
    "iPad": "768x1024",
    "Desktop": 1920
  }
}

🔧 Troubleshooting

Common Issues

Prisma Studio not loading

• Ensure Prisma Studio is running on the configured URL
• Check if the URL is accessible in your browser
• Verify firewall settings

Prisma Studio fails to start

• Ensure Node.js is installed
• Check if port 5555 is available
• Verify your schema.prisma file exists and is valid
• Make sure your database is accessible
• Open a workspace folder for better schema detection

Schema file not found

• Ensure your file is named exactly schema.prisma
• Check that the file is in one of the common locations
• Use the file picker to manually select your schema file

Configuration errors

• If you get workspace configuration errors, try opening a folder/workspace
• Configuration will fall back to global settings if no workspace is open

Extension not responding

• Reload VSCode window (Ctrl+Shift+P → "Reload Window")
• Check VSCode Developer Console for errors
• Restart VSCode

Getting Help

1. Check the GitHub Issues
2. Create a new issue with detailed information
3. Include VSCode version, extension version, and error messages

🤝 Contributing

Contributions are welcome! This project is actively maintained and we're continuously working on improvements and new features.

Development Setup

1. Clone the repository

git clone https://github.com/eliecer2000/vscode-prisma-studio.git
cd vscode-prisma-studio

2. Install dependencies

npm install

3. Open in VSCode and press F5 to launch Extension Development Host

Planned Features

• 🔄 Auto-refresh when schema changes
• 🎨 Custom themes and styling options
• 📊 Database metrics and monitoring
• 🔐 Enhanced security features
• 🌐 Multi-database support
• 📱 Improved mobile responsiveness

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

🙏 Acknowledgments

• Built upon vscode-webpreview by jabed-web-dev
• Inspired by the Prisma community and their excellent tooling
• Thanks to all contributors and users providing feedback
