Verde

A VS Code extension that provides a tree view explorer window

Features

• Live Instance Tree: View your Roblox game's instance hierarchy in VS Code
• Script Opening: Double-click scripts to open them in VS Code (works with Rojo/Argon/Azul sourcemaps)
• Instance Operations: Rename, duplicate, delete, copy, and paste instances
• Properties Panel: View and edit instance properties right from VS Code

Requirements

• Roblox Studio with the Verde plugin installed
• A Rojo/Argon/Azul setup with sourcemap generation (for script opening functionality)

Extension Installation

From VSIX

1. Run npm run package in the extension directory to create a .vsix file
2. In VS Code, press Ctrl + Shift + P to open the command palette
3. Select "Install from VSIX..." and choose the generated .vsix file

Online

Visual Studio Marketplace

Setup

1. Install the Verde plugin in Roblox Studio
2. Open your VS Code workspace
3. The extension will automatically start a WebSocket server
4. Open Roblox Studio and run your game with the plugin
5. The Roblox Explorer view should appear in VS Code

Extension Settings

• verde.sourcemapPath: Path to sourcemap file (relative to workspace root) - defaults to "sourcemap.json"
• verde.port: Port for the WebSocket server - defaults to 9000
• verde.host: Host IP address for the WebSocket server - defaults to "localhost"
• verde.autoStart: Automatically start the server when the extension activates - defaults to true

Usage

Opening Scripts

1. Click on any Script, LocalScript, or ModuleScript in the explorer
2. The extension will look up the file path in your sourcemap (if it exists)
3. The corresponding file will open in VS Code

Instance Operations

• Right-click instances for context menu options
• Use keyboard shortcuts for quick operations:
  • Enter: Rename
  • Delete: Delete
  • Ctrl+C: Copy
  • Ctrl+V: Paste
  • Ctrl+D: Duplicate
  • Ctrl+Shift+A: Open new instance panel
