SQL Debug Harness — VS Code Extension

Documentation: deeprajdeveloper.github.io/vscode-sql-debug-harness · Technical design · Change history

Statically rewrite a T-SQL stored procedure into a safe debug script: durable-table DML becomes SELECT previews (temp tables and table variables stay live), transactions are neutralized, and variables are traced — so you can run the script without mutating real tables.

Not a live debugger. This generates a static harness script — no breakpoints or step-into on SQL Server.

No Python required. The transform engine runs in-process inside the extension (TypeScript). Install from the Marketplace (or a VSIX) and go.

Overview

Stored procedures are hard to reason about from a script diff alone. You can read a CREATE PROCEDURE top to bottom and still not be fully certain which rows an UPDATE will touch — until it has already run.

SQL Debug Harness statically rewrites a T-SQL stored procedure so side-effecting statements become read-only previews — runnable against a real connection without writing anything. The engine is TypeScript and runs in-process.

Workbench preview — analyze a procedure and generate a debug harness in VS Code.

Before / after

Interactive scenarios (durable DML, temp tables, bare IF/ELSE, trace styles) live on the user documentation site. A few representative excerpts:

Durable-table DML

Input

CREATE PROCEDURE dbo.usp_SimpleDml
    @Id INT,
    @Name NVARCHAR(100)
AS
BEGIN
    INSERT INTO dbo.Items (Id, Name) VALUES (@Id, @Name);
    UPDATE dbo.Items SET Name = @Name WHERE Id = @Id;
END

Generated harness (excerpt)

-- [DBG] Harness: was CREATE PROCEDURE dbo.usp_SimpleDml; set parameter values below.
DECLARE @Id INT = NULL,  -- TODO: set test value
        @Name NVARCHAR(100) = NULL;  -- TODO: set test value
    -- [DBG-PREVIEW] Would have executed:
    SELECT N'INSERT to table dbo.Items' AS [DBG_Action], @Id AS [@Id], @Name AS [@Name];
    -- [DBG-PREVIEW] Would have executed:
    SELECT N'UPDATE to table dbo.Items' AS [DBG_Action], @Name AS [@Name]
    FROM dbo.Items
    WHERE Id = @Id;

Temp tables stay live

-- Input keeps both; harness only previews dbo.Items
INSERT INTO #Temp (Id) VALUES (@Id);      -- left live
INSERT INTO dbo.Items (Id) VALUES (@Id);  -- → SELECT preview

Bare IF / ELSE wrapping

-- Input
IF @Var1 >= 0
  SET @Var2 = 1
ELSE
  SET @Var2 = 0

-- Harness (default select traces)
IF @Var1 >= 0
  BEGIN
      SET @Var2 = 1
      SELECT 'DBG' [NOTES], @Var2 [Var2];
  END
ELSE
  BEGIN
      SET @Var2 = 0
      SELECT 'DBG' [NOTES], @Var2 [Var2];
  END

Quickstart (< 5 minutes)

1. Install SQL Debug Harness from the VS Code Marketplace (or code --install-extension dist/sql-debug-harness.vsix).
2. Open samples/fixtures/simple_dml.sql (or any .sql stored procedure).
3. Right-click → SQL Debug Harness → Generate Debug Script.
4. Review the harness in the Workbench — durable-table DML is preview-only; set DECLARE values and run against a safe connection.

Optional: Analyze Procedure shows Summary / Warnings / Identified in the Workbench tab.

What’s new in 0.0.5

• Compare toggle highlights additions and removals between source and debug script (banner / blank / non-[DBG] comments filtered).
• Activity Log is a Level / Function / Message table with color badges and level filters (All / None).

See the full change history.

Open from the sidebar

Click the SQL Debug Harness icon in the primary activity bar (left). The sidebar includes Open Workbench, Analyze, and Generate actions plus grouped Analyzed / Debugged procedure history.

Loading SQL: use Select File… in the workbench (Quick Pick of workspace .sql files), Load Active for the open editor, or right-click a file → Open in Workbench.

Commands

The Workbench shows:

• Source — selected text or full .sql file (Select File… or Load Active)
• Debug script — generated harness (when available)
• Compare — optional overlay that aligns source vs harness with add/remove highlighting
• Analysis — Summary / Warnings tabs plus Identified results grouped by Kind
• Activity log — Level / Function / Message table with level filters (collapsible)

Panes are resizable (drag the splitters). Click the full Analysis or Activity Log header to collapse it; panel order and collapse state are preserved. Source and Debug previews use T-SQL syntax highlighting, theme colors, and horizontal scrolling for long lines.

From the toolbar you can open History, Analyze, Generate, Compare, Clear generated output, and use Save for analysis .txt, debug .sql, log .log, or open the debug script in an editor tab.

Available from the SQL Debug Harness right-click submenu on .sql files and from the Command Palette. Non-empty editor selections are used when present.

Settings

Limitations (trust boundary)

This tool prioritizes correctness over coverage. If something cannot be rewritten safely, it is flagged — not silently left as live durable-table DML.

• T-SQL only for v1 (no PostgreSQL / Oracle / MySQL dialects yet).
• Static rewrite only — not a live/step-through debugger.
• Temp tables / table variables — DML against #temp, ##temp, and @tableVar is intentionally left live (session-scoped only).
• Dynamic SQL (EXEC(@sql), sp_executesql) is detected and warned; not rewritten.
• Cursors / WHILE — detected and warned; rewriting inside them is best-effort.
• MERGE / OUTPUT — flagged; MERGE is disabled rather than incorrectly previewed.
• Stored procedures are the target — not arbitrary ad-hoc DDL/DML scripts.
• No live DB connection in the extension — generate the script, then run it yourself (e.g. in SSMS / Azure Data Studio).

Why no Python backend?

Earlier versions shelled out to a PyPI package. That forced every user to have Python on PATH, survive first-run pip install, and deal with corporate lockdown / wrong interpreters. VS Code already runs Node.js, so the engine was ported to TypeScript and ships inside the VSIX. Installing the extension is the entire setup.

The engine uses a hybrid approach: optional AST via node-sql-parser (TransactSQL) plus text-scan / regex transforms for real enterprise T-SQL (TRY/CATCH, multi-line DML, etc.) where full AST parsing often fails.

Optional CLI (npx)

Same engine, outside the editor:

npx sql-debug-harness generate -i MyProc.sql -o MyProc_debug.sql
npx sql-debug-harness analyze -i MyProc.sql
npx sql-debug-harness version

(When developing from this repo: npm run compile && node out/cli.js generate -i ….)

Local development

git clone https://github.com/DeeprajDeveloper/vscode-sql-debug-harness.git
cd vscode-sql-debug-harness
npm install
npm test
npm run compile

Press F5 to launch an Extension Development Host.

Package a VSIX

npm run package
code --install-extension dist/sql-debug-harness.vsix

Publish to the Marketplace

Requires an Azure DevOps PAT with Marketplace → Manage (Organization: All accessible organizations).

export VSCE_PAT="your-token"
npm run publish              # runs check + tests, then uploads 0.0.x
npm run publish:dry-run      # package only, no upload
./scripts/publish-marketplace.sh --skip-tests --yes

After publish, the listing is at: marketplace.visualstudio.com/items?itemName=DeeprajAdhikary.sql-debug-harness

Roadmap

Shipped through 0.0.5: Marketplace extension, in-process TypeScript engine, Workbench (Compare, leveled/filterable Activity Log, History, Save/Clear), durable-table DML previews with temp/table-var DML left live, configurable traces, optional CLI.

Near term: stable v1.0 polish, richer cursor/WHILE handling, Compare refinements (whitespace / region-aware).

Later (v2+): multi-dialect support, optional connect-and-run inside BEGIN…ROLLBACK, dynamic SQL assist.

License

MIT
