Inklink — Markdown Mind Map Visualizer

Turn any Markdown file into a live, interactive mind map — right inside VS Code.

Inklink is a Markdown mind map extension for Visual Studio Code that instantly visualizes the structure of your .md files as navigable, color-coded mind maps. No export step. No separate tool. Just open a Markdown file and see its hierarchy come alive in a side panel.

Whether you are writing a product spec, reviewing an architecture decision record, drafting AI prompts, or navigating a large documentation tree — Inklink gives you the bird's-eye view that plain text cannot.

✨ Why Inklink?

🚀 Key Features

🗺️ Real-Time Markdown Mind Map

Every heading (#, ##, ###) and list item in your Markdown automatically becomes a node in the mind map. Edit the file — the map updates instantly. No manual refresh required.

🔄 Real-Time Synchronization

The mind map is live-synced with your editor buffer. It updates as you type, providing an instant visual preview of your document structure as it evolves. No manual refresh or save required.

🔗 Bidirectional Editor ↔ Map Navigation

• Double-click any node → your VS Code editor jumps to the exact line
• Click a line in the editor → the corresponding node highlights in the mind map
• The connection is always live: write on the left, think on the right

🧭 Multiple Layout Directions

Choose how your mind map flows:

• Two-Sided (Balanced) — branches spread left and right
• Left-to-Right — classic reading direction
• Right-to-Left — for RTL workflows or alternative perspectives

🔭 Lighthouse Minimap

A smart minimap in the bottom-right corner keeps you oriented on even the largest mind maps. The current viewport is highlighted with an inverted overlay so your position is always unmistakable — even when zoomed out to see thousands of nodes.

🔍 Canvas Search

Find any node by text directly on the mind map canvas. Navigate through results with keyboard shortcuts.

📤 Export Your Mind Map

Share your visual thinking with anyone:

• PNG — high-resolution image export
• SVG — scalable vector graphics
• Interactive HTML — a standalone file anyone can open in a browser, zoom, pan, expand, and collapse — no Inklink required

🎨 Theme-Aware Design

Inklink automatically matches your VS Code theme (light or dark). Color-coded branches maintain their vibrant light-mode colors in both themes, ensuring visual consistency and excellent readability against dark backgrounds.

🛡️ Auto-Save & Recovery

Your work is continuously saved in the background. If VS Code crashes or the panel is accidentally closed, your mind map state is preserved and restored on next launch.

⚙️ Expand, Collapse & Focus

• Expand All / Collapse All — control how much of the tree is visible
• Click a collapse indicator — fold or unfold individual branches
• Fit to Screen — instantly center and scale the map to fit your panel

📦 Getting Started

Open a Mind Map

1. Open any .md file in VS Code
2. Click the Inklink icon in the editor title bar, or
3. Right-click the file in the Explorer → Open Mindmap, or
4. Open the Command Palette (Cmd+Shift+P / Ctrl+Shift+P) → Inklink: Open Mindmap

The mind map opens in a side panel next to your editor — your Markdown source and its visual structure, side by side.

Supported Markdown Structure

# Project Title

## Phase 1
- Research
    gather competitive analysis data
- Design
    wireframes and user testing

## Phase 2

### Backend
- API Design
- Database Schema

### Frontend
- Component Library
- State Management

## Phase 3
- Launch
- Post-launch monitoring

Every heading and list item becomes a node. Indented text beneath a node becomes its descriptive label — giving you both structure and context without leaving Markdown.

⌨️ Keyboard Shortcuts

Note: Standard VS Code shortcuts like Cmd+S (Save), Cmd+F (Find), and Cmd+Z (Undo) work natively — Inklink does not override them.

🏗️ How It Works Under the Hood

Inklink runs as a VS Code Webview panel powered by React, D3.js, and TypeScript. Your Markdown is parsed into a tree structure using a custom heading + list parser, then rendered as an SVG mind map with D3's layout algorithms.

The extension communicates bidirectionally with VS Code's editor API:

• File watching — the mind map updates when the source file changes on disk
• Cursor sync — editor cursor position broadcasts to the mind map for live highlighting
• Line reveal — double-clicking a node sends the target line back to VS Code for navigation

All rendering happens locally. No data leaves your machine. No external API calls. No telemetry.

🔧 Requirements

• VS Code 1.85.0 or later
• No additional dependencies — everything is bundled

💡 Use Cases

• 📋 Product Specs — Visualize PRDs, user stories, and acceptance criteria written in Markdown
• 🏛️ Architecture Docs — Navigate ADRs, RFC documents, and system design specs
• 🤖 AI Prompt Engineering — See the structure of complex system prompts and agent instructions at a glance
• 📚 Documentation — Explore multi-section docs, tutorials, and knowledge bases as interactive trees
• 🎓 Study Notes — Organize lecture notes and research hierarchies visually
• 📝 Meeting Notes — Turn action items and agendas into browsable mind maps
• 🗓️ Project Planning — Map out milestones, phases, and task breakdowns

🌐 Also Available on the Web

Inklink is also available as a free web application at inklink.bychris.me with additional features like drag-and-drop file opening, local IndexedDB recovery, and a full markdown editor with find & replace.

The VS Code extension and the web app share the same rendering engine, layout algorithms, and design system — so your mind maps look identical everywhere.

🤝 Contributing

Inklink is open source. Contributions, bug reports, and feature requests are welcome on GitHub.

☕ Support

If Inklink has saved you time or helped you think more clearly, consider buying me a coffee. It keeps the project alive.

📄 License

MIT — see LICENSE for details.

Inklink — Visualize your thinking. Navigate your knowledge. All in Markdown.
