Chevere Workflow

VS Code extension providing complete language server support for Chevere Workflow PHP definitions.

Features

Diagnostics: Validates job arguments against reflected PHP class signatures: missing required params, unknown args, type mismatches, response() chain errors, Chevere Parameter attribute constraint violations, withRunIf()/withRunIfNot() variable and response violations, and withDepends() missing dependency errors
Inlay hints: Shows parameter types before argument values and return types after response() calls
Hover: Displays full method signatures with parameter types, defaults, and required/optional status; hovering over variable('name') shows the variable's schema
Completion: Suggests available parameter names (required first) with snippet expansion; offers response() references to other jobs in the workflow
Job graph: Interactive Mermaid visualization of the workflow dependency graph, with zoom/pan controls, a raw Mermaid syntax tab, and a copy-to-clipboard button

Requirements

VS Code ^1.85.0
PHP executable accessible from your shell (or configured via settings)
A project using chevere/workflow with a composer.json

Extension Settings

Setting	Default	Description
`chevereWorkflow.enable`	`true`	Enable/disable the extension
`chevereWorkflow.phpExecutable`	`"php"`	Path to the PHP executable
`chevereWorkflow.composerJsonPath`	`""`	Path to `composer.json` (auto-detected if empty)
`chevereWorkflow.inlayHints.showParameterTypes`	`true`	Show parameter type hints
`chevereWorkflow.inlayHints.showResponseTypes`	`true`	Show response return type hints

Commands

Command	Description
`Chevere Workflow: Restart Server`	Restarts the language server
`Chevere Workflow: Show Job Graph`	Opens an interactive visualization of the current workflow
`Chevere Workflow: Install chevere/workflow`	Opens a terminal and runs `composer require chevere/workflow` in the workspace root (trusted workspaces only)

The Show Job Graph command is also available as a CodeLens button that appears above every workflow() call in the editor.

Project Structure

chevere-workflow-lsp/
├── client/src/extension.ts      # VS Code extension entry point
└── server/src/
    ├── server.ts                # LSP connection and handlers
    ├── parser.ts                # PHP AST parsing (php-parser)
    ├── diagnostics.ts           # Argument validation logic
    ├── reflector.ts             # PHP reflection wrapper
    ├── reflectScript.ts         # Embedded PHP reflection script
    ├── validateScript.ts        # Embedded PHP attribute validation script
    ├── validator.ts             # Attribute constraint validation executor
    ├── inlayHints.ts            # Inline type hints
    ├── hover.ts                 # Hover documentation
    ├── completion.ts            # Autocomplete suggestions
    ├── linter.ts                # PHP linter wrapper (lint violations)
    ├── lintScript.ts            # Embedded PHP linter script
    ├── phpExecutable.ts         # PHP executable sanitization/validation
    ├── tempDir.ts               # Per-process private temp directory
    ├── jobGraph.ts              # Workflow graph (Mermaid)
    └── mermaidScript.ts         # Embedded PHP Mermaid generator script

The repo is a npm workspace monorepo. The client package is the VS Code extension; the server package is the language server connected via Node.js IPC.

Dev Setup

Install dependencies:

npm install

Compile (one-shot):

npm run compile

Compile (watch mode):

npm run watch

Run the extension in VS Code:

Open the repo in VS Code and press F5 (or run Debug: Start Debugging). This launches an Extension Development Host with the extension loaded.

Package as .vsix:

npm run package

The generated .vsix file can be installed manually via Extensions: Install from VSIX... in VS Code.

License

This software is licensed under the Apache License, Version 2.0. See LICENSE for the full license text.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.
