Sveld

Sveld is a VS Code extension that lets you write .sveld files — Svelte components with a server-side data block — and renders them as live, interactive views directly inside VS Code.

No web server. No build pipeline. Just open a .sveld file and it renders.

How it works

A .sveld file is a standard Svelte component with one optional block: <script context="server">. This block runs in the VS Code extension host (full Node.js access), fetches data from any source, and injects it as props into the Svelte component rendered in the webview.

<script context="server">
  const { MongoClient } = require('mongodb')

  const client = new MongoClient('mongodb://localhost:27017')
  await client.connect()
  const users = await client.db('myapp').collection('users').find().toArray()
  await client.close()

  return { data: { users } }
</script>

<script>
  export let users = []
</script>

<ul>
  {#each users as user}
    <li>{user.name}</li>
  {/each}
</ul>

Features

Server-side data block

The <script context="server"> block runs in Node.js with full access to require(), process, URL, setTimeout, and any npm package. Use it to query databases, read files, call REST APIs, or run any Node.js code. Return { data: { ...props } } to inject values as Svelte props.

Actions

The server block can expose actions — async functions that run server-side when called from the component via the globally available sveldAction(name, payload).

• If an action returns a value, it resolves as a Promise in the component — no re-render.
• If an action returns nothing, the view fully re-renders with fresh data.

<script context="server">
  return {
    data: { items },
    actions: {
      async addItem({ name }) {
        await collection.insertOne({ name })
        // returns nothing → triggers re-render
      },
      async search({ query }) {
        return collection.find({ name: query }).toArray()
        // returns value → no re-render, resolves in component
      }
    }
  }
</script>

<script>
  export let items = []

  async function handleSearch() {
    const results = await sveldAction('search', { query: 'tea' })
    // results available here, no page re-render
  }
</script>

Auto package installation

Any package require()d in the server block is automatically installed into ~/.svd/node_modules on first use. No manual npm install needed.

<script context="server">
  const { MongoClient } = require('mongodb')  // auto-installed on first open
  const Chart = require('chart.js/auto')      // same
</script>

SCSS support

Svelte <style lang="scss"> blocks are compiled automatically via Dart Sass. Import shared stylesheets using @use or @import:

<style lang="scss">
  @use './components/theme.scss';

  .card {
    background: var(--bg-card);
    &:hover { border-color: var(--accent); }
  }
</style>

File watcher

Sveld tracks every file bundled into the component (Svelte files, imported JS, SCSS partials) using esbuild's metafile. Saving any of those files automatically re-renders the view — no manual refresh needed.

Environment variables (.env)

Sveld automatically loads .env files in two locations:

Local values override global ones. Variables are available as process.env.MY_VAR in the server block.

# ~/.svd/.env
MONGO_URI=mongodb://localhost:27017
MONGO_DB=myapp

Multi-panel focus broadcast

When multiple .sveld files are open, the extension broadcasts which panel is currently active to all other panels. Each panel can use this to highlight the active tab in a shared navigation header.

• onDidChangeViewState fires when a panel gains or loses focus.
• A focusChange message (with the active filename) is posted to every open sveld panel.
• When switching to a non-sveld editor, a 100ms debounce clears the highlight in all panels.

A typical use case is a shared Header.svelte component that highlights which panel is currently focused, even when viewed from another panel:

<!-- src/Header.svelte -->
<script>
  import { onMount } from 'svelte'

  const links = [
    { label: 'Home',  file: 'home.sveld' },
    { label: 'Stats', file: 'stats.sveld' },
  ];

  // __SVELD_FILE__ is injected by the extension — filename of the current panel (constant)
  const currentFile = typeof __SVELD_FILE__ !== 'undefined' ? __SVELD_FILE__ : '';
  // focusedFile updates via broadcast — may differ from currentFile
  let focusedFile = currentFile;

  onMount(() => {
    window.addEventListener('message', (e) => {
      if (e.data.type === 'focusChange') focusedFile = e.data.file;
    });
  });
</script>

<nav>
  {#each links as link}
    <button
      class:active={link.file === currentFile}
      class:focused={link.file === focusedFile}
      onclick={() => link.file !== currentFile && sveldOpen('./' + link.file)}
    >{link.label}</button>
  {/each}
</nav>

<style>
  .active  { color: #4ecdc4; }
  .focused { color: #ffb86c; } /* orange — visible in all panels, not just the focused one */
</style>

<!-- home.sveld -->
<script>
  import Header from './src/Header.svelte'
</script>

<Header />

Navigation between sveld files

Call sveldOpen('./path/to/other.sveld') (globally available in the webview) to open another .sveld file:

• If the target is already open in another column, it is focused there.
• Otherwise it opens beside the current panel.

Svelte component imports

Import regular .svelte components from the same directory. They are bundled by esbuild at render time and hot-reloaded when their source changes (tracked via the file watcher).

<script>
  import MyChart from './components/MyChart.svelte'
  export let data = []
</script>

<MyChart {data} />

Global webview functions

File format

<script context="server">
  // Node.js — runs in the extension host
  // Has access to require(), process.env, etc.
  // Packages are auto-installed from npm on first use
  // Must return { data: { ...props }, actions: { ...fns } }
</script>

<!-- Standard Svelte below -->
<script>
  export let myProp = []
</script>

<div>{myProp.length} items</div>

<style lang="scss">
  /* SCSS supported */
</style>

Installation

Install from the VS Code Marketplace, or via terminal:

code --install-extension CdricDessalles.sveld

Development

Build:

npm run build

Test the packaged extension locally (validates exactly what the marketplace ships):

npm run package              # builds + creates sveld-x.x.x.vsix
code --install-extension sveld-*.vsix

Reload VS Code after installing. This is the recommended way to validate before publishing.

Publish (requires VSCE_PAT env var, or use CI by pushing a version tag):

npx vsce publish -p $VSCE_PAT

Tech stack

Ideas & Roadmap

• Syntax highlighting — proper .sveld language grammar
• Prop reactivity — update props in-place after actions instead of full re-render
• Export to HTML — standalone static snapshot of any view

License

MIT
