CodeRun AI Agent 🚀

CodeRun AI Agent (AI-AGENT) is a professional, multi-provider AI coding companion for Visual Studio Code. Operating as a state-of-the-art agentic loop, CodeRun acts as a decision-maker to read, write, and edit files, index codebases in a local SQLite database, and run terminal processes using VS Code's integrated terminal.

Whether you are running completely offline with local models (Ollama), leveraging official API keys (OpenAI, Anthropic, Gemini, Groq, OpenRouter), or routing custom endpoints (Cloudflare Workers AI, Aero Link), CodeRun delivers an exceptionally integrated and secure developer experience.

🌟 Key Highlights & Features

🤖 Multi-Provider Model Orchestration

• 8 Native Providers Supported: Ollama, OpenAI, Anthropic Claude, Google Gemini, Groq, OpenRouter, xAI (Grok), and OpenAI Compatible.
• Saved Provider Configurations: Save credentials (API keys, base URLs, default models) for multiple endpoints. Switch models on the fly in the middle of a chat session without resetting settings.
• Unified Model Dropdown: All models from your active and saved providers are dynamically retrieved and presented in a single, clean dropdown, grouped logically by provider.
• API Type Selection: Custom compatible providers support setting the underlying API Type (OpenAI Compatible, Anthropic Compatible, or Google Gemini Compatible) to correctly format request bodies, endpoint paths, and API headers.
• Cloudflare Workers AI Support: Dynamically parses Cloudflare base URLs to extract your Account ID and retrieve model lists using Cloudflare's search API, before cleanly returning to standard completions.

🖼️ Multimodal Vision & Image Support

• Drag, Pick & Clipboard Paste: Attach images via the attachment button or paste directly into the chat input box (Ctrl+V). Previews render instantly with Base64 encoding.
• Responsive Chat Window Sizing: Images in user chat bubbles display with responsive CSS sizing (max-width: 280px, max-height: 200px, object-fit: contain).
• Multi-Provider Vision Schemas: Automatically formats images into each provider's native API schema:
  • Ollama: Base64 string array (images: ["base64..."]).
  • OpenAI / OpenRouter / Groq / Compatible: OpenAI image_url content blocks.
  • Anthropic Claude: image source blocks (media_type, base64).
  • Google Gemini: inline_data parts (mime_type, data).
• Persistent Storage: Images are saved in localStorage and VS Code's globalState, preserving full conversation history.

💬 Streamlined Chat & Agent UI

• Sidebar Navigation: Clean UTF-8 sidebar navigation icons (☰ Toggle Threads, 💬 Chat Window, ⚙ Settings) for crisp cross-platform rendering.
• Streaming Content & Thinking: Real-time stream processing for thinking process blocks, final content, and tool execution.
• Interactive Collapsible Tool Cards: Status messages, step durations, and arguments expand and collapse cleanly in real time as the agent progresses.
• Direct Console Blocks: Suppresses redundant cards for shell integration to stream terminal outputs directly inside a dark console terminal box.
• Unified Embedded Permissions: Authorizations (Allow, Deny, Always Allow, Always Deny) are integrated directly inside the active tool card with horizontal scrolls, removing annoying overlay modals.
• Inline Diff Reviews: Inspect proposed file changes block-by-block directly in the chat window, showing green additions and red deletions. Click Accept or Reject right inside the card.
• Task Continuation: A single-click Continue Task button appears automatically when hitting execution limits to resume the agent's work loop.

🧠 Advanced Agent Loop

• Think → Plan → Act → Verify: Multi-iteration loop executing tool actions one at a time, verifying outputs, and learning repository styles.
• Parallel Tool Execution: Executes multiple independent tool calls concurrently (e.g. reading or writing multiple files) using Promise.all for high performance.
• Transparent Tool Aliasing: Declares explicit schemas and maps habit-based model tools (bash, execute_command, read, write, edit) to CodeRun's native implementations, providing full compatibility with Claude Code proxy environments (like Aero Link).
• Reasoning Models Support: Captures and extracts thoughts from reasoning models (like Gemma 4 and DeepSeek-R1) via thought, reasoning_content, and reasoning keys, rendering them in a dedicated collapsible Thought Process card.

↩️ Undo & Automatic Checkpoints

• Database-Backed Snapshots: CodeRun takes automatic snapshots of your files in a local SQLite database before any write, edit, or delete action.
• Single-Click Restore: An Undo button appears under assistant responses that modified your files. Click it to restore files instantly.
• Command Palette Integration: Run CodeRun: Undo Last Edit at any time to roll back changes.

📦 Compact Conversation & Context Management

• Deterministic Tool Compaction: Automatically compacts verbose file operations, directory listings, and tool outputs into concise, human-readable status one-liners (Read file, Wrote file, Patched file, Deleted file).
• Smart Terminal Output Compaction: Strips raw stdout output on successful terminal commands (since the LLM already knows the result) while preserving stdout/stderr output on command failures for accurate LLM error diagnosis.
• Zero-Loss Re-Compaction: Always re-compacts history from original messages to avoid summary-of-summary degradation, injecting compact-context-cp1, compact-context-cp2 checkpoints into prompt context.
• Full-Width Collapsible Timeline Checkpoint UI: Renders full-width collapsible checkpoint bubbles directly along the chronological conversation flow, featuring 4 inner sub-dropdowns: User Messages, Thinking, Response Summary, and Tool Executions.
• 0ms Instant Local Execution: Executes compaction 100% locally with zero API calls, zero network latency, and zero provider dependencies.
• Pinnable Session Info & Manual Compaction: Access detailed token breakdowns and trigger manual compaction anytime via the hoverable/pinnable Session Info card (📦 Compact Conversation).

⏱️ Workspace Activity Timeline & Context Separation

• Thread-Isolated Chat History: Full conversation dialogue, assistant responses, thinking traces, and reasoning tokens are strictly isolated per chat thread. Opening a New Chat or deleting a conversation starts with a clean dialogue history (messages: []).
• SQLite Workspace Activity Feed: CodeRun maintains a lightweight, chronological workspace activity feed in its local SQLite database (timeline_data), recording recent workspace events: task starts (▶), file creations (+), file edits (∼), file deletions (−), file reads (→), terminal executions ($), and tool results (✓).
• Cross-Chat Situational Awareness: The 6 most recent workspace activity events are injected as high-level metadata into the agent's background system prompt (## RECENT TIMELINE). This gives the AI immediate awareness of recently touched files, run commands, and active workspace tasks across sessions without bloating the prompt with full past chat transcripts.

📁 SQLite Project Knowledge Base

• SQLite-Powered Index: Uses sql.js to run a local SQLite database (index.db) in your global storage, keeping track of file metadata, chunk hashes, and project metrics.
• Symbol Outlines: The list_symbols tool parses files to outline functions, classes, and structs with line numbers.
• Incremental Indexing: Runs in the background, updating only changed files detected by file watchers.
• Fallback Search: find_in_files and search_files query the SQLite database for instant matches and fall back to filesystem scans if the database is indexing.

🖥️ Enhanced Terminal Execution

• Inline Collapsible Terminal Cards: Every terminal execution appears as its own independent collapsible card inside the conversation timeline — no more fixed terminal panel at the top of the chat.
• True Streaming Output: stdout/stderr is streamed incrementally (appended, not replaced) with live updates as the command runs.
• Automatic Shell Detection: The tool auto-detects PowerShell, Command Prompt (cmd), Git Bash, WSL, Bash, Zsh, and Fish — providing shell metadata directly to the LLM so it generates correct command syntax.
• ANSI Escape Cleaning: All ANSI escape sequences, OSC sequences, VS Code shell integration markers (]633;C, ]133;), color codes ([0m, [91m), and cursor control sequences are stripped before rendering — only human-readable output is shown.
• Reliable Fallback Execution: When VS Code shell integration is unavailable, commands are executed directly via child_process.execFile with real stdout, stderr, exit code, and duration capture — no more "check the terminal panel" messages.
• Structured Tool Results: The terminal tool returns a structured object { shell, command, stdout, stderr, exitCode, durationMs, success, workingDirectory } for both the LLM and the UI.
• Canonical Execution Status: Every terminal card derives all UI elements from a single canonical status enum: pending → running → success / error / timeout / cancelled. No contradictory displays (e.g., FAILED + ✓ Completed).
• Accurate Success Detection: Exit code 0 → SUCCESS. Exit code non-zero → FAILED. No exit code but no errors → SUCCESS (shows "Exit code unavailable"). Never displays "Exit code ?".
• Adaptive Scrolling: Small outputs grow naturally with no internal scrollbar. Large outputs get a scrollbar with a 320px max-height.

🪵 Real-Time Execution Traces & Visual Flow

• Dual View Sub-Nav ([Chats] / [Traces]): Seamlessly switch between the conversational chat interface and a dedicated visual execution trace inspector right below the model selector.
• Multi-Run Timeline Navigation: Horizontally scrollable Run [#1](https://github.com/nbsgr/coderun-agent/issues/1), Run [#2](https://github.com/nbsgr/coderun-agent/issues/2), ... tabs preserving scroll position upon selection, with immutable model badges reflecting the exact model used for each run.
• Card-Based Timeline Nodes:
  • User Input & Context Node: Displays user query, attached images, and workspace path.
  • LLM Decision & Reasoning Card: Tracks system prompt tokens, step reasoning, and decision intents.
  • Tool Execution Card: Inspect tool name, command, input arguments, execution duration, and formatted output.
  • Rich Markdown Final Response: Full GFM table rendering, headers, lists, code blocks, and formatted text.
  • Error Response Alert Node: Captures upstream provider 400/500 errors and stream failures with ✗ FAILED status cards and exact diagnostics.
• Live Parallel Event Streaming: Stream traces parallel to the agent loop in real time (trace_updated).
• Dual-Layer Persistent Storage: Automatically saves trace history per-session in VS Code globalStorage/traces/ and webview storage, with instant historical reconstruction for past sessions.
• One-Click Clipboard Export: Copy individual tool/LLM steps or export the complete run JSON (📋 Copy Run).

🔄 Tool Lifecycle State Sync

• Reliable Lifecycle Transitions: Every tool follows the exact lifecycle: PENDING → WAITING_FOR_PERMISSION → RUNNING → COMPLETED/FAILED/CANCELLED. No tool card remains stuck in RUNNING.
• Provider-Compatible Card Linking: Cards are stored under multiple key aliases (toolCallId, index key, toolName key), ensuring tool_result events find the correct card regardless of whether the LLM provider emits tool call IDs or not.
• Backwards DOM Fallback: When lookup keys fail, the DOM search iterates backwards to find the most recently created card — fixing issues where multiple calls of the same tool (e.g., two update_plan invocations) would update the wrong card.

🛠️ Supported Providers

🚀 Quick Start

1. Installation

Install "CodeRun AI Agent" via the Extensions view (Ctrl+Shift+X) in VS Code, or install it using the command-line interface:

code --install-extension Bala-Siva-Ganesh.ai-agent

2. Development Setup (From Source)

# Clone the repository
git clone https://github.com/nbsgr/coderun-agent.git
cd coderun-agent

# Install dependencies
npm install

# Launch Development Host
# Press F5 in VS Code to run the Extension Development Host window.

3. Basic Configuration

1. Open the CodeRun panel by clicking the chat icon in the Activity Bar.
2. Click the ⚙️ Settings button.
3. Select your desired Provider (e.g. Google Gemini, Ollama, OpenAI).
4. Enter the Base URL (or use defaults) and paste your API Key.
5. Click Refresh Models to fetch your model list.
6. Select a model and click Save Settings.

📖 Deep Dive: CodeRun Architecture

CodeRun's engine is split into isolated manager modules that govern the lifecycle of a task execution. The terminal execution pipeline has been significantly enhanced with inline collapsible cards, automatic shell detection, ANSI cleaning, structured results, and a canonical execution status enum ensuring consistent SUCCESS/FAILED/CANCELLED/TIMEOUT states across all UI elements. The tool lifecycle has been hardened so every tool reliably transitions through PENDING → RUNNING → COMPLETED/FAILED — no cards remain stuck.

src/
├── extension.js              ← VS Code activation, IPC message bridge, secrets, health checks
├── agentLoop.js              ← Core agentic loop (gathers context, plans steps, streams LLM output)
├── promptBuilder.js          ← Assembles system prompt with workspace, planning, and memory contexts
│
├── context/
│   ├── contextManager.js     ← Identifies request intent, extracts editor state & active file details
│   └── compactionManager.js  ← Pure local 0ms conversation compaction engine & checkpoint generator
├── execution/
│   └── executionTrace.js     ← Real-time trace engine (LLM calls, tools, errors, disk persistence)
├── planningManager.js        ← Generates step-by-step plans written to a database-backed plan file
├── verificationManager.js    ← Runs post-execution tests (build checks, syntax checks, output matches)
├── learningManager.js        ← Automates style guidelines discovery (indentation, framework syntax)
├── timelineManager.js        ← Logs chronological system events to timeline history
├── checkpointManager.js      ← Manages file backups, snapshot comparison, and rollback operations
├── diffManager.js            ← Stores diff patches for inline rendering in the webview
│
├── terminalManager.js        ← VS Code Integrated Terminal API with shell integration,
│                                auto shell detection (powershell/cmd/bash/zsh/fish/wsl),
│                                ANSI escape stripping, child_process fallback execution,
│                                and live output streaming through shell integration events
│
├── toolDefinitions.js        ← Declares JSON schemas (functions, parameters) sent to the LLM
├── toolRegistry.js           ← Maps tool calls to implementations and aliases custom proxy commands
├── tools.js                  ← 18 async generators: file I/O (read/write/edit/delete),
│                                directory (list/create/delete), search (files/content/symbols),
│                                terminal (run_terminal + aliases bash/execute_command),
│                                utility (datetime, web_request), planning (create/update_plan)
│
├── providerManager.js        ← Factory to instantiate the correct provider SDK
├── providerOllama.js / OpenAI.js / Anthropic.js / Gemini.js / Compatible.js ...
│
├── Dashboard.js / .css       ← Webview manager: dual-nav (Chats/Traces), multi-run tabs, settings
├── ChatSpace.js / .css       ← Chat space: collapsible tool cards, inline terminal cards with live
│                                streaming, permission dialogs, diff reviews, thought process
├── MarkdownRenderer.js       ← Client-side markdown processor with tables, code & syntax highlighting
├── webview-shared.js         ← Shared utilities (esc, truncate, stripAnsi) between Dashboard & ChatSpace
└── agentState.js             ← Formal finite state machine for the agent loop (idle→thinking→executing→completed)

⌨️ Keyboard Shortcuts

🛠️ Development & Building

Prerequisites

• Node.js >= 18.x
• VS Code >= 1.80.0

Setup

git clone https://github.com/nbsgr/coderun-agent.git
cd coderun-agent
npm install

Debugging

1. Open the project folder in VS Code.
2. Press F5 to open the Extension Development Host.
3. Click the AI-AGENT chat icon in the Activity Bar.

Packaging

npm install -g @vscode/vsce
vsce package

Install the generated .vsix:

code --install-extension ai-agent-1.3.2.vsix

📄 License

MIT

🔗 Official Links

• 🏪 VS Code Marketplace: Bala-Siva-Ganesh.ai-agent
• 🐙 GitHub Repository: nbsgr/coderun-agent
• 🐛 Issue Tracker: GitHub Issues
